Chapter 3: System Setup
Installing SO-DIMM DDR4 Memory Modules
1. Locate the SO-DIMM sockets on the mainboard.
1. There is no specific installation order when inserting the
memory module. Users can install the memory in either
DIMM 1 or DIMM 2 according to their requirements.
2. Note that the memory sockets are designed with fool-proof
measures. Do not force-plug the memory module(s) if they
are not oriented correctly.
Copyright © 2025 NEXCOM International Co., Ltd. All Rights Reserved.
2. Insert the memory module into the socket at an approximately 30 degrees
angle. The ejector tabs at the ends of the socket will automatically snap
into the locked position to hold the module in place. Repeatedly follow
the step above to insert the second memory module if required.
