Chapter 2: Jumpers and Connectors
Pin Definition
B43 GND_50
B45 PEG_TXP7
B47 GND_52
B49 GND_53
B51 PEG_TXN8
B53 GND_55
B55 PEG_TXN9
B57 GND_57
B59 PEG_TXN10
B61 GND_59
Copyright © 2025 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B44 GND_51
B46 PEG_TXN7
B48 PEG_PRSNT2_N
B50 PEG_TXP8
B52 GND_54
B54 PEG_TXP9
B56 GND_56
B58 PEG_TXP10
B60 GND_58
B62 PEG_TXP11
Pin Definition
B63 PEG_TXN11
B65 GND_61
B67 PEG_TXN12
B69 GND_63
B71 PEG_TXN13
B73 GND_65
B75 PEG_TXN14
B77 GND_67
B79 PEG_TXN15
B81 PEG_PRSNT2_2nd_Slot_N
25
Pin Definition
B64 GND_60
B66 PEG_TXP12
B68 GND_62
B70 PEG_TXP13
B72 GND_64
B74 PEG_TXP14
B76 GND_66
B78 PEG_TXP15
B80 GND_68
B82 PEG_SEL_X8_X16
