Chapter 2: Jumpers and Connectors
M.2 Key B Slot
Connector type: M.2 Key B 2280 (SATA)
Connector location: CN12
74
2
75
1
Pin
Definition
1
M2B_CONFIG_3
3
GND1
5
GND2
7
M2B_USB2_DP
9
M2B_USB2_DN
11
GND3
21
M2B_CONFIG_0
23
NC
25
NC
27
GND4
29
M2B_PER1N
31
M2B_PER1P
33
GND5
35
M2B_PET1N
37
M2B_PET1P
39
GND6
41
M2B_PER0P
Copyright © 2025 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
V3P3_M2B_1
4
V3P3_M2B_2
6
M2B_SSD_FULL_PWR_OFF_N
8
M2B_PLN_N
10
M2B_SATA_LED_N
20
NC
22
NC
24
NC
26
NC
28
NC
30
NC
32
NC
34
NC
36
NC
38
DEVSLP
40
NC
42
NC
Pin
Definition
43
M2B_PER0N
45
GND7
47
M2B_PET0N
49
M2B_PET0P
51
GND8
53
NC
55
NC
57
GND9
59
NC
61
NC
63
NC
65
NC
67
NC
69
M2B_CONFIG_1
71
GND10
73
GND11
75
M2B_CONFIG_2
17
Pin
Definition
44
NC
46
NC
48
NC
50
M2B_PCI_RST_N
52
NC
54
NC
56
M2B_SMDAT
58
M2B_SMCLK
60
NC
62
NC
64
NC
66
NC
68
M2B_SUSCLK
70
V3P3_M2B_3
72
V3P3_M2B_4
74
V3P3_M2B_5
NViS 6708 User Manual
