Chapter 2: Jumpers and Connectors
Audio Jacks
Connector type: Line In, Line Out, MIC
Connector location: HDA1
Line In
LIne Out
Mic
Pin
Definition
1
AGND_P
3
AGND_P
5
MIC_OUT_R_C
22
LINE_OUT_L_C
24
FRONT_JD
32
LINE-L_C
34
LINEIN1_JD
Copyright © 2025 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
MIC_OUT_L_C
4
MIC1_JD
23
AGND_G
25
LINE_OUT_R_C
33
AGND_B
35
LINE-R_C
14
NViS 6708 User Manual
