Appendix C: Installing the System in a Rack
a C: I
PPendIx nstallInG the
For Racks with a Depth Between 600~800mm
Before starting the installation procedure, check the package
contents of the slide rails; it should contain:
4 x M4*6mm, 2 x M5*15mm, and 6 x M5*10mm screws
Outer Sliding Rail Installation
1. The slide rail kit consists of an inner and outer rail. Before starting
the installation, detach the inner sliding rail from the outer one, and
separate the inner and outer sliding rails.
Copyright © 2025 NEXCOM International Co., Ltd. All Rights Reserved.
s
Outer sliding rail
}
Inner sliding rail
r
ystem In a aCk
2. Loosen the screws marked in the red dashed square in the image below
on the outer sliding rails, but do not completely remove them. Then,
remove the screws on both sides. (left and right sides).
