HTi
70
High temperature, ultra modulating
Heat pump
Installation and User manual
Manual ref.: 1898536
Edition n
25.17
o
* Concerns HTi
6-8 mono and HTi
70
8 tri models, only for Premium+ Pilot and DS170D Pilot.
70
70
HTi
6 kW mono
Ref. 155000
HTi
70
8 kW mono
Ref. 155010
70
HTi
8 kW tri
Ref. 155050
Made in
France
Advertisement
Table of Contents
Related Manuals for Intuis HTi70
Summary of Contents for Intuis HTi70
- Page 1 High temperature, ultra modulating Heat pump Installation and User manual 6 kW mono Ref. 155000 8 kW mono Ref. 155010 8 kW tri Ref. 155050 Made in France Manual ref.: 1898536 Edition n 25.17 * Concerns HTi 6-8 mono and HTi 8 tri models, only for Premium+ Pilot and DS170D Pilot.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 6.6.1 - Water inlet and outlet - Air intake sensor - Sensors installed on compressors 1 1 - SAFETY ............3 and 2 ..................................17 6.7 - Modifi cation..................17 2 -PLEASE READ IMMEDIATELY ......4 6.8 - Decommissioning ................17 2.1 - Conservation of documents ............4 6.8.1- Interim Decommissioning of Product ..............17 2.2 - Symbols used ..................4... -
Page 3: Safety
1 - SAFETY Danger resulting from improper qualifi cations Danger of death if the pressure relief valves are missing or defective • Any work carried out by an unqualifi ed person can result in damage to the installation or in A defective pressure relief valve may prove physical injury. -
Page 4: -Please Read Immediately
oriented to prevent water from leaking onto the 2 -PLEASE READ electrical components. IMMEDIATELY • This appliance must be installed in accordance with national electrical installation regulations. Check that the appliance is equipped with This technical installation manual forms part of the appliance which a properly sized and properly connected it refers to. -
Page 5: Certifi Cation "Origine France Garantie
Manufacturer’s identity 155050 AUER Réf : Certifi cation agency Rue de la République 80210 Feuquières en Vimeu intuis reference of the appliance Pompe à chaleur Appliance type Ser.n° : 155050-242400000 Serial number of the appliance Protection rating 400 V 3N~ 50/60 Hz Appliance electric data PED cat. -
Page 6: Delivery And Storage
3 - DELIVERY AND STORAGE 3.2.3 - Transporting manually 3.1 - Delivery terms and conditions The Heat pump can be transported manually. In general, the material is transported at the recipient’s own risk. The Heat pump must always be transported in a horizontal position, It is important to verify that all of the elements have been received including during installation. -
Page 7: Introduction
4 - INTRODUCTION 4.2 - Accessories (included) The components described below are delivered with the Heat Pump: 2-core sheathed cable linking the Heat Pump and the Pilot (lg 10 m) Hydraulic Fitting (Ref. 754206) (included a 1’’ filter valve, a safety valve assembly 1’’ , a hydraulic connection [ reduction F3/4 M1’’... -
Page 8: Installation
5 - INSTALLATION 5.1 - Standard confi guration 2 electrical supplies 230V single phase Pilot heat pump hydraulic connection • The Heat pump must be installed outside exclusively. • Avoid any obstruction of the airfl ow of the ventilator. Ensure that there is nothing blocking the exchanger’s air circulation. Ensure that the Heat pump is placed so that it is sheltered from dominant winds. -
Page 9: Placement
5.2 - Placement The Heat Pump is designed to be installed outdoors exclusively, while respecting a minimum of free space around the appliance in an area free from excessive levels of dust. It should never be placed in an enclosed space. The Heat Pump is designed to operate in rainy weather conditions, although it can be installed under a well-ventilated shelter (With an opening large enough to allow suffi cient air fl ow for intake and exhaust). -
Page 10: Security Area In Front Of A Wall
5.2.3.2 - Security area in front of a wall This area must be respected if the heat pump is against a wall and close to the opening of a building. Distances from the security perimeter (mm) 6 kW 8 kW 1000 1000 1000... -
Page 11: Setting Up
5.3 - Setting up The Heat pump must be installed on a hard and stable base, which is suffi ciently raised from ground level to avoid risks of damage in case of fl ooding or snow. (Refer to leafl et no. 1899193 supplied in the accessories box that comes as standard with the heat pump). •... -
Page 12: Hydraulic Installation
5.4 - Hydraulic installation 5.4.1 - Hydraulic connections on the installation In order to ensure that fl uids can circulate properly, it is advisable to check that the sizing of piping in the circuit is appropriate between the Heat Pump and the Pilot. All piping should be thermally insulated, especially the connecting pipes from the Pilot to the Heat Pump. -
Page 13: Hydraulic Connection Between Heat Pump And Pilot
5.4.2 - Hydraulic connection between Heat 5.5 - Connecting to the power supply pump and pilot A sufficient flow rate should be ensured so that the range of 5.5.1 - General recommendations temperature between the outlet and inlet of the Heat Pump does Ensure that the power supply is suffi cient to supply both the Heat not exceed 5°C when the Heat Pump is operating at full power (take pump and the electrical back-up if necessary, taking into account... -
Page 14: Accessing The Connection Terminals
Connecting terminals 5.5.4 - Connection to the power supply The terminal strips are spring-loaded «Cage Clamps». The HTi Heat pump is CE-marked. It is compliant with French standard NF C15-100 as well as European standards EN 61000-3-3 For Handling, use the following : and EN 61000-3-11, among others. -
Page 15: Three-Phase Connection
5.5.4.2 - Three-phase connection • A phase controller relay HTi three-phase 8 kW heat pump. In order to prevent a phase fault or bad sequence -which could cause compressor damage- a phase controller relay is installed. It prohibits the power supply to the heat pump if phases are reversed. In case of incorrect wiring : Proper wiring Incorrect wiring... -
Page 16: Maintenance And Troubleshooting
The HTi Heat pump uses R290 refrigerant fl uid. Given the fl ammable 6 - MAINTENANCE AND nature of this fl uid, any work on the refrigerant circuit must be carried out using suitable equipment which complies with the current rules TROUBLESHOOTING and regulations in eff ect. -
Page 17: Sensor Data Curve Charts
6.6 - Sensor data curve charts 6.7 - Modifi cation Any modifi cation of the device is prohibited. Any replacement of 6.6.1 - Water inlet and outlet - Air intake sensor - components must be done by a professional with original parts Sensors installed on compressors 1 and 2 from the manufacturer. -
Page 18: List Of Spare Parts
7 - LIST OF SPARE PARTS 6 & 8 kW HEAT PUMPS MANUAL... - Page 19 Reference number Rep. Designation 155000 155010 155050 6 mono 8 mono 8 tri B4994445 B4994445 B4994445 Compressor replacement kit B4994909 B4994910 B4994910 Condenser kit B1473042 B1473043 B1473043 Evaporator B4994304 B4994305 B4994305 4-way valve kit B4994306 B4994306 B4994306 Pressure reducing kit B1473040 B1473040 B1473040...
-
Page 20: Warranty
8 - WARRANTY 8.2.2 - Cases (not limited to) for exclusion from warranty 8.2.2.1 - Heating circuit water 8.1 - Warranty coverage Cases (not limited) for exclusion from warranty: The warranty covers the HTi Heat pump and the HTi Pilot - Not rinsing the heating circuit - Using rain or well-water components for a period of two (2) years, starting from the date... -
Page 21: Accessories
8.2.2.6 - Accessories The warranty does not cover faults or defects resulting from: - Installation of accessories which do not comply with our recommendations. - The use of accessories which do not come from the manufacturer of the appliance. 8.2.2.7 -Maintenance Cases (not limited) for exclusion from warranty: - Not respecting the maintenance instructions provided in the installer manual. -
Page 22: Appendix
APPENDIX A1 - Technical specifi cations A1.1 - General characteristics 155000 155010 155050 6 kW mono 8 kW mono 8 kW tri Electrical supply 230 V single-phase 230 V single-phase 400 V three-phase Maximum power consumption 3,6 kVA 3,6 kVA 3,6 kVA Maximum current needed 15 A... -
Page 23: A2 - Eu Declaration
A2 - EU declaration A4 - Treatment of the water in the heating circuit This device complies with international electrical safety standards IEC 60335-1, IEC 60335-2-40. The CE marking present on the device attests to its conformity with the following Community Directives, It is MANDATORY to read the additional of which it meets the essential requirements: document concerning the quality of... -
Page 24: A5 - Dimensions
- Protect the installation against corrosion with a corrosion inhibitor, Corrosion inhibitor : example: SENTINEL X100. Or against corrosion and freezing - protects against the formation of limescale with an inhibitor with an anti-freeze additive. Example : - prevents «pinhole» type corrosion SENTINEL X500 or SENTINEL R600. -
Page 25: A5.2 - Hti 70 8 Kw Heat Pump
A5.2 - HTi 8 kW Heat pump 1 - Heat pump outlet 2 - Heat pump inlet 3 - Communication bus 4 - Electrical supply 6 & 8 kW HEAT PUMPS MANUAL... -
Page 26: A6 - Product Technical Information Sheet
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 27: A6.2 - Hti
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 28: A6.3 - Hti 70 8 Kw Tri Heat Pump
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 29: A7 - Internal Wiring Diagram
A7 - Internal wiring diagram A7.1 - HTi 6 & 8 kW mono Heat pump TwOUT - Water outlet temperature sensor - Low pressure sensor TwIN - Water inlet temperature sensor HP1 - Compressor 1 high pressure switch Tévap - Condenser outlet temperature sensor - Fuse 5x20 - 4 A Tair - Air intake temperature sensor... -
Page 30: A7.2 - Hti 70 8 Kw Tri Heat Pump
A7.2 - HTi 8 kW tri Heat pump TwOUT - Water outlet temperature sensor - Low pressure sensor TwIN - Water inlet temperature sensor HP1 - Compressor 1 high pressure switch Tévap - Condenser outlet temperature sensor - Fuse 5x20 - 4 A Tair - Air intake temperature sensor - Fuse 10x38 - 20 A... -
Page 31: Notes / Maintenance
NOTES / MAINTENANCE Refrigerant collected Date Technician Work carried out Refrigerant loaded 6 & 8 kW HEAT PUMPS MANUAL... - Page 32 Industrial and development site Rue de la République CS 40029 80210 Feuquières-en-Vimeu Customer service 0)9 78 45 10 26 +33 ( service-consommateur@intuis.fr service-client@intuis.fr...
