- Page 1 High temperature, ultra modulating Heat pump Installation and User manual 6 kW mono /2 Ref. 155300 8 kW mono /2 Ref. 155310 8 kW tri /2 Ref. 155350 Made in France Manual ref.: 1899274 Edition n 25.09...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1 - SAFETY ............3 6.8 - Decommissioning ................17 6.8.1- Interim Decommissioning of Product ..............17 6.8.2- Final decommissioning of the product ............17 2 -PLEASE READ IMMEDIATELY ......4 6.9 - Recycling and Disposal ..............17 2.1 - Conservation of documents ............4 6.9.1- Disposal of refrigerant ...................17 2.2 - Symbols used ..................4 2.3 - Abbreviations and acronyms ............4... -
Page 3: Safety
1 - SAFETY Danger resulting from improper qualifi cations Danger of death if the pressure relief valves are missing or defective • Any work carried out by an unqualifi ed person can result in damage to the installation or in A defective pressure relief valve may prove physical injury. -
Page 4: -Please Read Immediately
2 -PLEASE READ REFRIGERANT CIRCUIT IMMEDIATELY • Any intervention on the refrigeration circuit must be made by a qualified person who This technical installation manual forms part of the appliance which it refers to. In order for the warranty to be valid, the instructions must holds a Category 1 certifi cate of fi tness. -
Page 5: Rating Plate
Manufacturer’s identity 155350 AUER Réf : Certifi cation agency Rue de la République 80210 Feuquières en Vimeu intuis reference of the appliance Pompe à chaleur - Réversible Appliance type Ser.n° : 155350-242100000 Serial number of the appliance Protection rating 400 V tri ~ 50/60 Hz Appliance electric data PED cat. -
Page 6: Delivery And Storage
3 - DELIVERY AND STORAGE 3.2.3 - Transporting manually 3.1 - Delivery terms and conditions The heat pump can be transported manually. In general, the material is transported at the recipient’s own risk. The heat pump must always be transported in a horizontal position, It is important to verify that all of the elements have been received including during installation. -
Page 7: Introduction
4 - INTRODUCTION 1. Compressor 2. Pressure reducer 3. Evaporator 4. Condenser 5. Ventilator 6. Heating inlet / outlet 7. Condensates drainage 4.1 - Operation 4.3 - Accessories available to order The Heat pump is a closed and pressurised system in which the 2-core sheathed cable (Ref. -
Page 8: Installation
5 - INSTALLATION 5.1 - Standard confi guration 2 electrical supplies 230V single phase Pilot heat pump Hydraulic connection 5.2 - Placement The heat pump is designed for outdoor installation only. It must remain perfectly accessible to allow easy inspection and maintenance. The fan intake and discharge must not be obstructed in any way. -
Page 9: Noise Levels
5.2.1 - Noise levels Depending on the installation conditions, the noise levels may be diff erent, in particular if the walls closest to the Heat Pump cause a reverberation and amplifi cation of noise. The diagrams below show diff erent installation examples for diff erent placements. Placed on the ground or on a terrace... -
Page 10: Security Area In Front Of A Wall
5.2.2.2 - Security area in front of a wall This area must be respected if the heat pump is against a wall and close to the opening of a building. Distances from the security perimeter (mm) 8 kW mono /2 6 kW mono /2 8 kW tri /2 1000... -
Page 11: Setting Up
5.3 - Setting up The Heat pump must be installed on a hard and stable base, which is suffi ciently raised from ground level to avoid risks of damage in case of fl ooding or snow. The heat pump is supplied with an accessory kit comprising four fi xing feet, two lifting straps and instructions. Please refer to the instructions in the kit for the correct procedure for installing the heat pump. -
Page 12: Hydraulic Installation
5.4 - Hydraulic installation 5.4.1 - Hydraulic connections on the installation In order to ensure that fl uids can circulate properly, it is advisable to check that the sizing of piping in the circuit is appropriate between the Heat Pump and the Pilot. All piping should be thermally insulated, especially the connecting pipes from the Pilot to the Heat Pump. -
Page 13: Hydraulic Connection Between Heat Pump And Pilot
5.4.2 - Hydraulic connection between Heat The rules and regulations in the country of pump and pilot installation MUST be respected (standard A sufficient flow rate should be ensured so that the range of C15-100). temperature between the outlet and inlet of the Heat Pump does •... -
Page 14: Accessing The Connection Terminals
5.5.2 - Accessing the connection terminals 5.5.4.1 - Single-phase connection 1 : Remove the 2 screws 1 : Remove the two screws 2 : Slide the panel downwards 2 : Slide upwards and pull forwards 3 : Pull the panel forwards 5.5.3 - Recommendations for connecting the Power supply system to the power supply... -
Page 15: Three-Phase Connection
5.5.4.2 - Three-phase connection • A phase controller relay HTi three-phase 8 kW heat pump. In order to prevent a phase fault or bad sequence -which could cause compressor damage- a phase controller relay is installed. It prohibits the power supply to the heat pump if phases are reversed. Proper wiring Incorrect wiring In case of incorrect wiring :... -
Page 16: Maintenance And Troubleshooting
6 - MAINTENANCE AND Any work on the refrigerant circuit must be undertaken by a qualifi ed professional with a category 1 certifi cate of aptitude. 1. It is forbidden to release gas from the refrigerant circuit into the atmosphere, and TROUBLESHOOTING it is obligatory to recover the refrigerant before undertaking any work on the circuit. -
Page 17: Sensor Data Curve Charts
6.6 - Sensor data curve charts 6.7 - Modifi cation Any modifi cation of the device is prohibited. Any replacement of 6.6.1 - Water inlet and outlet - Air intake sensor - components must be done by a professional with original parts Sensors installed on compressors 1 and 2 from the manufacturer. -
Page 18: List Of Spare Parts
7 - LIST OF SPARE PARTS 8 kW tri /2 6 & 8 kW HEAT PUMPS MANUAL... - Page 19 Reference number Reference number 155300 155310 155350 155300 155310 155350 Rep. Designation Rep. Designation 6 kW 8 kW 8 kW 6 kW 8 kW 8 kW mono /2 mono /2 tri /2 mono /2 mono /2 tri /2 B4994445 B4994445 B4994445 Compressor replacement kit 13-b...
-
Page 20: Warranty
8 - WARRANTY 8.2.2 - Cases (not limited to) for exclusion from warranty 8.2.2.1 - Heating circuit water 8.1 - Warranty coverage Cases (not limited) for exclusion from warranty: - Not rinsing the heating circuit The warranty covers the HTi Heat pump and the HTi Pilot - Using rain or well-water... -
Page 21: Appendix
APPENDIX A1 - Technical specifi cations A1.1 - General characteristics 155300 155310 155350 6 kW mono /2 8 kW mono /2 8 kW tri /2 Electrical supply 230 V single-phase 230 V single-phase 400 V three-phase Maximum power consumption 3,6 kVA 3,6 kVA 3,6 kVA Maximum current needed... -
Page 22: A1.2 - Performances
A1.2 - Performances A1.2.1 - Heating mode 155300 - HTi 6 kW mono /2 155310 - HTi 8 kW mono /2 155350 - HTi 8 kW tri /2 Water temperature Water temperature Water temperature 30/35 40/45 47/55 55/65 30/35 40/45 47/55 55/65 30/35... -
Page 23: A2 - Eu Declaration
A4 - Treatment of the water in the A2 - EU declaration heating circuit This device complies with international electrical safety standards IEC 60335-1, IEC 60335-2-40. The CE marking present on the device It is MANDATORY to read the additional attests to its conformity with the following Community Directives, of which it meets the essential requirements: document concerning the quality of... -
Page 24: A5 - Dimensions
- Protect the installation against corrosion with a corrosion inhibitor, Corrosion inhibitor : example: SENTINEL X100. Or against corrosion and freezing - protects against the formation of limescale with an inhibitor with an anti-freeze additive. Example : - prevents «pinhole» type corrosion SENTINEL X500 or SENTINEL R600. -
Page 25: A5.2 - Hti 70 8 Kw Heat Pump
A5.2 - HTi 8 kW Heat pump 6 & 8 kW HEAT PUMPS MANUAL... -
Page 26: A6 - Product Technical Information Sheet
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 27: A6.2 - Hti
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 28: A6.3 - Hti 70 8 Kw Tri /2 Heat Pump
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 29: A7.1 - Hti 70 6 & 8 Kw Single-Phase Heat Pump
A7 - Internal wiring diagram A7.1 - HTi 6 & 8 kW single-phase Heat pump TwOUT - Water outlet temperature sensor - Low pressure sensor TwIN - Water inlet temperature sensor HP1 - Compressor 1 high pressure switch Tévap - Condenser outlet temperature sensor - Fuse 5x20 - 4 A Tair - Air intake temperature sensor... -
Page 30: A7.2 - Hti 70 8 Kw Three-Phase Heat Pump
A7.2 - HTi 8 kW three-phase Heat pump TwOUT - Water outlet temperature sensor - Low pressure sensor TwIN - Water inlet temperature sensor HP1 - Compressor 1 high pressure switch Tévap - Condenser outlet temperature sensor - Fuse 5x20 - 4 A Tair - Air intake temperature sensor - Fuse 10x38 - 20 A... -
Page 31: Notes / Maintenance
NOTES / MAINTENANCE Refrigerant collected Date Technician Work carried out Refrigerant loaded 6 & 8 kW HEAT PUMPS MANUAL... - Page 32 Industrial and development site Rue de la République CS 40029 80210 Feuquières-en-Vimeu Customer service 0)9 78 45 10 26 +33 ( service-consommateur@intuis.fr service-client@intuis.fr...
