Summary of Contents for Intuis HRC70
- Page 1 High temperature Heat Pumps from 17 to 25 kW Installation and user manual 17 mono /3 Ref. 151430 17 tri /3 Ref. 151435 20 tri /3 Ref. 151445 25 tri /3 Ref. 151450 Made in France Manual ref. : 1898302 Edition n°...
-
Page 2: Table Of Contents
CONTENTS 1 - PLEASE READ IMMEDIATELY ....... 4 5.3 - Maintenance of the Heat Pump ...........20 5.4 - Maintenance of the electrical components ........20 1.1 - Important information ...............4 5.5 - Errors which are not signalled by error message or alert ..21 1.2 - Safety advice and instructions ............4 5.6 - Compressor start-up faults .............22 1.3 - Symbols used ..................5... - Page 3 A9 - Electricity provider information form .........45 NOTES / MAINTENANCE ........47 HEAT PUMPS 17 - 20 - 25 kW MANUAL...
-
Page 4: Please Read Immediately
1 - PLEASE READ IMMEDIATELY The high temperature Heat Pump absorbs the 1.1 - Important information calories present in exterior air, and transforms These installation and operating instructions them into useful energy which is then transferred form part of the appliances which they refer to. to the heating water for your home. -
Page 5: Symbols Used
falls below -20°C, the installation no longer heats The HRC Heat Pump uses R290 refrigerant fl uid. using the Heat Pump, but using the back-up. Given the flammable nature of the fluid, any work on the refrigerant circuit must be done with •... -
Page 6: Rating Plate
Manufacturer’s identity AUER 151435 Rue de la République Réf : Certifi cation agency 80210 Feuquières en Vimeu intuis reference of the appliance Pompe à chaleur Appliance type Ser.n° : 151435-232300000 Serial number of the appliance Protection rating 400V tri ~ 50Hz Appliance electric data PED cat. -
Page 7: Delivery Terms And Conditions
1.5 - Delivery terms and conditions 2 - INTRODUCTION In general, the material is transported at the recipient’s own risk. 2.1 - Standard confi gurations It is important to verify that all of the elements have been received and that no damage has been sustained during transport upon receipt of the appliance and before beginning the installation procedures. -
Page 8: Accessories (Included)
The capacitor ( ), a plated heat exchanger which is hydraulically 3 - INSTALLATION linked to the heating installation ( ), via the Pilot, enables to heat the water in the heating circuit, and in turn enables the heating of the building. -
Page 9: Seaside Installation
3.1.1.2 - Heat Pump installation site Minimum distances to respect for proper installation of the Heat Pump: (mm) : Mini Mini Mini Mini 3.1.1.1 - Seaside installation Generally speaking, the components of our products are treated to resist corrosion, but traces may nevertheless appear, aff ecting the aesthetics without compromising the operation of the appliance. -
Page 10: Condensates Drainage
3.1.1.3 - Condensates drainage Always make sure the heat exchanger When the appliance is operating in frost protection mode, the fi ns are protected when handling the condensed water must be drained off . In order for the condensates appliance. to drain properly, the drainage trough and hole must be clean and free of all debris (leaves, grass, etc...). -
Page 11: Heater Cable For External Condensates Drainage
3.1.1.4 - Heater cable for external condensates drainage The Heat Pump allows for the addition of an external heater cable to prevent freezing of the condensates drainage circuit. The heater cable (optional Ref.751004) is connected to the electrical box on the terminals marked HG on the electronics board. It must be installed in accordance with the instructions supplied with the cable, in or around the condensates drainage pipe, outside the Heat Pump. -
Page 12: Safe Area
3.1.2 - Safe area The heat pump contains a fl ammable refrigerant. In case of leak, the refrigerant could accumulate near the ground (higher density than air). or spread through openings in the building. In order to limit the risk of a toxic, suff ocating, explosive or dangerous atmosphere, a safety perimeter must be established around the machine. -
Page 13: Hydraulic Installation
3.2 - Hydraulic installation The Heat Pump is equipped with a hydraulic 3.2.1 - Hydraulic connections on the pressure relief valve set at 2.5 bar. A service installation pressure below this value should be maintained. In order to ensure that fl uids can circulate properly, it is advisable to check that the sizing of piping in the circuit is appropriate between the Heat Pump and the Pilot. -
Page 14: Hydraulic Connections : Heat Pump Circuit
3.2.2 - Hydraulic connections : 3.2.3 - Heat Pump and Pilot pressure-relief valves Heat Pump circuit A sufficient flow rate should be ensured so that the range of The Heat Pump and the Pilot are both equipped with pressure- temperature between the outlet and inlet of the Heat Pump does relief valves. -
Page 15: Heat Pump Water Inlet Fi Lter (Supplied)
3.3 - Electrical control connections 3.2.5 - Heat Pump water inlet fi lter (supplied) 3.3.1 - Connecting to the Heat Pump control A fi lter 1’’1/4 must be installed on the water inlet piping on the Heat Pump: 3.3.1.1 - 2-core sheathed cable •... -
Page 16: Connecting To The Power Supply
Terminal strips 3.4 - Connecting to the power supply The terminal strips are spring-loaded «Cage Clamps». For handling, use the following : Ensure that the power supply is suffi cient to supply both the Heat - for 2,5 mm² control terminals or 4 mm² - Pump and the electrical back-up if necessary, taking into account 6 mm²... - Page 17 The HRC Heat Pump is CE-marked. It is compliant with French standard NF C15-100 as well as European standards EN 61000-3-3 and EN 61000-3-11, among others. It is equipped with a progressive start-up, which limits the current at start-up to 45 A in single-phase, and 60 A in three-phase. The power supply cable should be sized carefully according to the following factors: - Maximum current required...
-
Page 18: Hrc Heat Pump : 230 V Single-Phase Connection
3.4.2.1 - HRC Heat Pump : 230 V single- 3.4.3 - Electrical protection for the compressors phase connection The HRC Heat Pump is equipped with a progressive start-up device to limit the intensity of the current when the motor starts up, in compliance with the NF C-15-100 standard: 45 A per phase in single-phase and 60 A per phase in three-phase. -
Page 19: Set-Up
5 - MAINTENANCE AND 4 - SET-UP TROUBLESHOOTING • All work carried out on the hydraulic circuits and the electrical installations must be carried out in compliance with regulations in eff ect in the country of installation, by a qualifi ed professional. •In order to ensure the best performance •... -
Page 20: Maintenance Of The Heating Circuit
5.2.2 - Maintenance of the heating circuit 5.4 - Maintenance of the electrical components • Release any trapped air in the HRC Pilot. • Check that the entire circuit is watertight, including the pressure- relief valves. • Always disconnect the appliance from •... -
Page 21: Errors Which Are Not Signalled By Error Message Or Alert
5.5 - Errors which are not signalled by error message or alert Errors not displayed on the screen Possible causes Solutions • Check values of PAR 209 and 215, and place it in winter mode and then auto. • The installation is in summer mode. •... -
Page 22: Compressor Start-Up Faults
5.6 - Compressor start-up faults Single-phase starter for the HRC 17 kW single-phase Heat Pump Green Led Red Led Potential causes Actions to be taken • Normal operation • Check the power supply voltage on the Heat Pump : it must Flashing •... -
Page 23: Sensor Data Curve Charts
5.8.2 - Exterior sensor 5.8 - Sensor data curve charts Temp. Resist. R Temp. Resist. R Temp. Resist. R Temp. Resist. R 5.8.1 - Water inlet and outlet HRC Heat Pump (°C) (KOhms) (°C) (KOhms) (°C) (KOhms) (°C) (KOhms) - Air intake sensor - Sensors installed on 171,800 61,930 24,947... -
Page 24: Spare Parts
6 - SPARE PARTS 6.1 - HRC Heat Pump HP circuit LP circuit HEAT PUMPS 17 - 20 - 25 kW - V3 MANUAL... - Page 25 Reference Rep. Description 17 kW 17 kW 20 kW 25 kW mono /3 tri /3 tri /3 tri /3 B4995123 B4995134 B4995127 B4995127 Compressor 1 replacement kit B4995124 B4995135 B4995135 B4995128 Compressor 2 replacement kit B1472868 B1472868 B1472868 B1472877 Plated heat exchanger B1472866 B1472866 B1472866...
-
Page 26: Electrical Boxes
6.2 - Electrical boxes 17 kW single-phase Rep. Reference Description B4994719 Heat Pump C9+ electronics board B1244295 Starter CSS-25U -E- B1244468 Capacitor 50MF-COMP-ZH06 B1243847 30 A three-phase contactor B1244037 Three-phase starter B1243147 4 A - 5x20 fuse B1943752 Phase controller B1244469 Capacitor 45MF-COMP-ZH09 Reference points on schematic cabling diagram... -
Page 27: Warranty
7.1.2.2 - Handling 7 - WARRANTY Cases (not limited) for exclusion from warranty: - Any damage sustained by impacts or falls during handling after The warranty covers the HRC Heat Pump and the HRC Pilot delivery from the factory. - Deterioration in the condition of the appliance after handling where components for a period of two (2) years, starting from the date the appliance was activated, if the warranty form was sent back the instructions in the manual have not been followed. -
Page 28: Appendices
APPENDICES A1 - Dimensions HEAT PUMPS 17 - 20 - 25 kW - V3 MANUAL... -
Page 29: A2 - Technical Specifi Cations
A2 - Technical specifi cations A2.1 - General specifi cations 17 mono 17 tri 20 tri 25 tri Maximum temperature 70°C 70°C 70°C 70°C R290 refrigerant fl uid 0,900 kg 0,900 kg 0,900 kg 0,900 kg Low pressure : 17 bar Low pressure : 17 bar Low pressure : 17 bar Low pressure : 17 bar... -
Page 30: A2.2 - Performances
A2.2 - Performances 17kW single-phase 17kW three-phase 20kW three-phase 25kW three-phase Water temperature Water temperature Water temperature Water temperature 30/35 40/45 47/55 55/65 30/35 40/45 47/55 55/65 30/35 40/45 47/55 55/65 30/35 40/45 47/55 55/65 MAX heating capacity* 20,50 20,00 19,50 18,50 20,50 20,00 19,50 18,50 24,00 23,00 22,00 21,00 30,00 29,00 28,00 26,50 Heating capacity nominal** 20 °C... -
Page 31: A3 - Eu Declaration
A3 - EU declaration A5 - Sizing the expansion vessel This device complies with international electrical safety standards - For a heating installation with radiators: IEC 60335-1, IEC 60335-2-40. The CE marking present on the The expansion vessel equipping the boiler may be suffi cient. device attests to its conformity with the following Community Always check that the capacity of the existing expansion vessel Directives, of which it meets the essential requirements:... -
Page 32: A6 - Treatment Of The Water In The Heating Circuit
- Protect the installation against corrosion with a corrosion A6 - Treatment of the water in the inhibitor, example: SENTINEL X100. Or against corrosion heating circuit and freezing with an inhibitor with an anti-freeze additive. Example : SENTINEL X500 or SENTINEL R600. •... - Page 33 When using a concentrated protect which needs to be diluted with water, mix the water+anti- freeze+inhibitor mixture together prior to inserting it into the installation. RENDERING THE WARRANTY NULL AND VOID All deterioration of the appliance due to an inappropriate quality of water and/or the presence of corrosion in the absence of treatment products as described above, and/or an improper purging of air of the installation will render the warranty to be null and void.
-
Page 34: A7 - Product Performances Tables
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 35: A7.2 - Hrc 70 Heat Pump 17 Kw Three-Phase
3500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 36: A7.3 - Hrc 70 Heat Pump 20 Kw Three-Phase
4500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 37: A7.4 - Hrc 70 Heat Pump 25 Kw Three-Phase
4500 Coordonnées de contact / Contact details intuis, rue de la République 80210 Feuquières-en-Vimeu Les précautions particulières qui doivent être prises lors du montage, l'installation et l'entretien, sont décrites dans la notice d'installation et d'utilisation. All specific precautions for assembly, installation and maintenance are described in the operating and installation instructions. Read and follow the operating and installation instructions . -
Page 38: A8 - Internal Wiring Diagram
A8 - Internal wiring diagram A8.1 - HRC 17 kW single-phase Heat Pump TwOUT : Water outlet temperature sensor TwIN : Water inlet temperature sensor Tair : Air intake temperature sensor TCP1 : Compressor 1 temperature sensor TCP2 : Compressor 2 temperature sensor : Compressor 1 high pressure - pressure switch : Compressor 2 high pressure - pressure switch : Low pressure - pressure switch... - Page 39 HEAT PUMPS 17 - 20 - 25 kW MANUAL...
-
Page 40: A8.2 - Hrc 70 17 Kw And 20 Kw Three-Phase Heat Pumps
A8.2 - HRC 17 kW and 20 kW three-phase Heat pumps TwOUT : Water outlet temperature sensor TwIN : Water inlet temperature sensor Tair : Air intake temperature sensor TCP1 : Compressor 1 temperature sensor TCP2 : Compressor 2 temperature sensor : Compressor 1 high pressure - pressure switch : Compressor 2 high pressure - pressure switch : Low pressure - pressure switch... - Page 41 HEAT PUMPS 17 - 20 - 25 kW MANUAL...
-
Page 42: A8.3 - Hrc 70 25 Kw Three-Phase Heat Pump
A8.3 - HRC 25 kW three-phase Heat Pump TwOUT : Water outlet temperature sensor TwIN : Water inlet temperature sensor Tair : Air intake temperature sensor TCP1 : Compressor 1 temperature sensor TCP2 : Compressor 2 temperature sensor : Compressor 1 high pressure - pressure switch : Compressor 2 high pressure - pressure switch : Low pressure - pressure switch : Compressor 1 start-up control... - Page 43 HEAT PUMPS 17 - 20 - 25 kW MANUAL...
- Page 44 HEAT PUMPS 17 - 20 - 25 kW - V3 MANUAL...
- Page 45 A9 - Electricity provider information form This form is to given to the electricity provider for all preliminary evaluation for the installation of an HRC Heat Pump in case of an insuffi cient power grid. This table contains information on both electrical and technical data about the HRC Heat Pump. This technical data is provided in the table §...
- Page 46 HEAT PUMPS 17 - 20 - 25 kW - V3 MANUAL...
-
Page 47: Notes / Maintenance
NOTES / MAINTENANCE Refrigerant collected Date Technician Work carried out Refrigerant loaded HEAT PUMPS 17 - 20 - 25 kW MANUAL... - Page 48 Industrial and development site Rue de la République CS 40029 80210 Feuquières-en-Vimeu Customer service 0)9 78 45 10 26 +33 ( service-consommateur@intuis.fr service-client@intuis.fr...
