- Page 1 Wind Calm Patio Manual assembly...
- Page 2 To download this user guide in your language, visit our website: www.create-store.com/uk Para descargar el manual en su idioma, visite nuestra web: www.create-store.com/es Para baixar o manual no seu idiomas, visite nosso site: www.create-store.com/pt Pour télécharger le manuel dans votre langue, visitez notre site Web: www.create-store.com/fr...
- Page 3 INDEX Parts list with light Step 1. Wood roof Step 1. concrete roof Step 1. False ceiling Step 2. Driver connection Step 3. Anchoring the motor to the ceiling Step 4. Assembly of the blades Step 5. Placement of the trim Step 6.
- Page 4 PARTS LIST WITH LIGHT (1) EXPANSION SCREWS (2) WOOD SCREWS MOUNTING BRACKET DRIVER REMOTE CONTROL BLADES LAMP COVER TRIM LED PLATE ENGINE SUPPORT SCREWS + WASHERS FOR WATERPROOF COVER THE BLADES SCREWS FOR SCREWS FOR SPLICE TERMINALS BALANCING KIT SUPPORT + ENGINE TRIM + ENGINE ATTENTION! Before starting the as- sembly, remember to disconnect the...
- Page 5 STEP 1. WOOD ROOF PARTS AND TOOLS EQUIPMENT NOT INCLUDED (2) WOOD SCREWS Mark with a pencil the 4 holes of the piece If necessary, depending on the type of A in the roof. roof, you will need to use a drill to make the hole in the wood.
- Page 6 STEP 1. CONCRETE ROOF PARTS AND TOOLS EQUIPMENT NOT INCLUDED (1) EXPANSION SCREWS disassemble the part E separating it into pieces. Ø8 mm Mark 2 parallel holes with a pencil using Using a drill, drill the two corresponding part K as a guide. holes with a Ø8 mm drill bit.
- Page 7 Position the assembly on the ceiling by Insert in order the part D2, D3 and then the matching its holes with the screws, leaving nut D4. the cables protruding through the central hole. Tighten the part D4 with a #10 spanner until Make sure that the assembly is securely you feel that it is well fixed.
- Page 8 STEP 1. FALSE CEILING PARTS AND TOOLS EQUIPMENT NOT INCLUDED FIXING SCREWS WITH SPRING LEVER Mark 2 parallel holes with a pencil using Using a drill, drill the two corresponding part K as a guide. holes. Insert the fixing screws into the holes and Fit part K into part A.
- Page 9 STEP 2. DRIVER CONNECTION PARTS AND TOOLS Insert the part hook A in a hole in the part I so that the motor is hanging and facilitate the connection of the cables. Join the connections of the part I with those of the piece B, each with its corresponding color. ENGLISH...
- Page 10 Check that central Select and connect all ground wires, including the one for structure is well placed. your installation. Once connected, place the Once connected, place the Connect the PHASE cable piece N screwing it in until piece N screwing it in until of the driver (AC-N) to the it is secure.
- Page 11 STEP 3. ANCHORING THE MOTOR TO THE CEILING Use 2 screws L and screw them, not too tightly, into the par- Remove the piece from the allel holes in the part A. hook I and fit it into the piece A without pinching any wires.
- Page 12 STEP 4. ASSEMBLY OF THE BLADES Includes a spare screw With the motor well placed, Place the first blade AND holding it with washers and we will begin the assembly screws J with the help of the screwdriver, without tightening of the blades E.
- Page 13 STEP 5. PLACEMENT OF THE TRIM To place the part H Pass the fan wires through the center hole squaring the 2 holes with those of the center bracket. Screw in the screws L in the two large holes of the piece H without pressing too much. Then turn the piece H to the right so that it is perfectly seated and aligned with the third hole.
- Page 14 STEP 6. LED BOARD CONNECTION Connect the wires of the part F to those of the fan joining the con- nections, each one with the same color. Then attach the part F to the fan through the magnets so that it stays in place. ENGLISH...
- Page 15 STEP 7. ATTACHING THE LAMP COVER Place the piece G. on the fan and secure it by turning clockwise. Don't forget to check that the part G it stays well attached. Once verified, you will be able to connect the electricity and enjoy your new fan with light. ENGLISH...
- Page 16 WALL CONTROLLER INSTALLATION Through our store you can buy the wall controller separately. Follow the instructions below for assembly. PARTS LIST Motor Output LED Output AC_N AC_L Controller Clamping bracket Screws Driver Command MOUNTING THE WALL CONTROLLER WITH LIGHT BRACKET FIXING AND CONTROLLER MOUNTING Use a switch close to the fan to which you are installing the controller.
- Page 17 CONTROLLER CONNECTION TO FAN 1. To access the controller of your ceiling fan you must remove the two side screws as shown in the image. Once you access the driver, disconnect all wiring and remove the driver from the fan motor. 2.
- Page 18 BLADE BALANCING KIT Your ceiling fan may have blade swinging issues when it is running due to irregularities in the blades or brackets. Also, incorrect mounting of the system or crooked bearings could cause additional problems. The following procedure is recommended to remedy these problems: 1.
