Quick start guide

for model LS5145
Install the telephone base
Install the telephone base as shown below.
DSL filter (not included)
for DSL users
Telephone wall jack
Electrical outlet
not controlled by
a wall switch
Power adapter
Telephone
line cord
Telephone base
NOTES:
1. Use only the power adapter and battery
supplied with your VTech telephone.
2. For complete feature instructions, please refer
to your user's manual.
LS5145 QSG 082707.indd 1

Battery installation and charging

Install the battery as shown below. For optimal
performance, charge the handset battery for at least
16 hours before use.
1. Press the tab and 2. Insert the plug as
slide the battery indicated. Make sure
compartment cover it is plugged securely
downwards. and matches the color-
coded label inside the
battery compartment.
3. Place the battery 4. Align the cover flat
with the label against the battery
THIS SIDE UP facing compartment, then
up and the wires slide it upwards until it
inside the battery clicks into place.
compartment.
5. Charge the
handset by placing
it in the telephone
base. The handset
charge light on the
handset will be on
when charging.
Charge light
Pairing your first
Bluetooth cell phone
To pair and connect your first Bluetooth cell
phone:
1. P r e s s C E L L o n t h e
telephone base.
Cellular operation
2. Press the YES softkey.
requires Bluetooth
connection.
Set up Cellular?
YES
3. Set your cell phone to search
Set up Cellular
for or add new devices, then
Set your Cellular to
search for devices,
press the NEXT softkey.
then press NEXT
NEXT
4. Once your cell phone finds
Set up Cellular
your VTech LS5145, select
VTech LS5145
in Discoverable Mode
it and then enter the PIN
PIN=0000
0000 on your cell phone.
STOP
5. W h e n t h e p a i r i n g i s
Set up Cellular
completed, press the YES
Pairing complete
Connect to
softkey on the telephone
Cellular ?
base.
YES
Cellular setup
completed
Pairing your first

Bluetooth headset

To pair and connect your first Bluetooth headset:
1. Press the MENU softkey on
the telephone base.
2. Press the UP and DOWN Main Menu
Voice Mail
N a v K e y s t o h i g h l i g h t
Intercom
Bluetooth, then press the
Bluetooth
SELECT softkey.
Bluetooth
3. Press the UP and DOWN
NO
Set up Cellular
NavKeys to highlight Set
Set up Headset
up Headset, then press the
Active Devices
SELECT softkey.
4. S e t y o u r h e a d s e t i n
Set up Headset
discoverable mode, then
press the NEXT softkey.
5. Once the telephone base
Headsets Found
finds your headset, select
Mary's Headset
HELP
it and then press the PAIR
softkey.
FIND
6. Enter your headset's PIN
Set up Headset
on the telephone base, then
0000
NO
press the DONE softkey.
The default PIN for most
DONE
headsets is 0000.
7. W h e n t h e p a i r i n g i s
Set up Headset
completed, press the YES
softkey on the telephone
base.
YES
SELECT
SELECT
Set your Headset in
Discoverable mode,
then press NEXT
NEXT
INFO
PAIr
Enter PIN:
HELP ErASE
Pairing complete
Connect to
Headset ?
NO
Headset setup
completed
