Quick start guide (Canada edition)
CS6124/CS6124-11/CS6124-2/
CS6124-21
Introduction
This quick start guide provides you with the basic installation
and use instructions. A limited set of features are described in
abbreviated form.
Please refer to the user's manual for complete installation and
operation instructions.

Telephone base and charger installation

Install the telephone base and charger as shown below.
Telephone
wall jack
A DSL filter
(not included)
is required if
you have DSL
high-speed
Internet service
Telephone
line cord
Use only the power adapter(s) and battery(ies) supplied with
this product.

Battery installation and charging

Install the battery as shown below. Once you have installed the
battery, you may be able to make and receive short calls. For
best performance, charge the handset battery continuously for at
least 6 hours.
 Plug the battery connector
securely into the socket.
3 Slide the battery
compartment cover towards
the center of the handset
until it clicks into place.
Electrical outlet
(not controlled by
a wall switch)
Telephone base
power adapter
Telephone base
2 Place the battery with the
wires inside the battery
compartment.
4 Charge the handset in the
telephone base or charger.
Charge light
remains on
when charging.

Charger
adapter
Charger

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS6124 and is the answer not in the manual?

Questions and answers

Related Manuals for VTech CS6124

Summary of Contents for VTech CS6124

  • Page 1: Telephone Base And Charger Installation

    A limited set of features are described in abbreviated form. Please refer to the user’s manual for complete installation and operation instructions. Telephone base and charger installation Install the telephone base and charger as shown below. Telephone wall jack A DSL filter (not included)

  • Page 2: Handset Overview

    Skip to the next message. /PLaY/STOP Play messages. Stop message playback. /aNS ON/OFF Turn the answering system on or off. / /VOLUMe Adjust the volume during playback. Adjust the telephone base ringer volume when the telephone is not in use.

  • Page 3: Using The Menu

    CaNCeL or charger. redial The telephone stores the five most recently dialed numbers. When there are already five entries, the oldest entry is deleted to make room for the new entry. To review and dial a number from the redial list: Press reDIaL/ not in use.
  • Page 4 The directory can store up to 30 entries. Each handset directory is independent (for models CS6124-2 and CS6124-21 only). Any additions, deletions or edits made on one handset are not reflected on the other handset. To add a directory entry:...

  • Page 5: Call Log

    • Call log entries are shared by all system handsets (for models CS6124-2 and CS6124-21 only). Any deletions made on one handset are reflected on the other handset. The handset displays XX missed calls when there are calls •...

  • Page 6: About Answering System And Voicemail

    Your telephone has separate indicators for two different types of voice messages: those left on the built-in answering system and those left at your telephone service provider’s voicemail. Each alerts you to new messages differently.

  • Page 7: Play Messages

    Hang up or press 8 to end the call. IMPOrTaNT! If you have difficulty with your telephone, please refer to the user’s manual for a full set of installation and operation instructions. For customer service, visit our website at www.vtechcanada.com or call  (800) 26-3.
