OMNI-700
User Guide
USA
1804 Owen Court,
Suite 104, Mansfield,
TX 76063
Tel: +1 817 533-8130
sales-us@poynting.tech
Version 1.0
Europe
Kronstadler Straße 4,
81677 München
Germany
Tel: +49 89 2080 265 38
Mob.: +49 176 529 733 50
sales-europe@poynting.tech
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Poynting OMNI-707
Summary of Contents for Poynting OMNI-707
- Page 1 Landmarks Ave Suite 104, Mansfield, 81677 München Samrand, 0157 Germany TX 76063 South Africa Tel: +1 817 533-8130 Tel: +49 89 2080 265 38 Tel: +27 12 657 0050 sales-us@poynting.tech Mob.: +49 176 529 733 50 info@poynting.tech sales-europe@poynting.tech Version 1.0...
- Page 2 UG-OMNI-700...
- Page 3 Index Packing Check List Introduction Antenna Mounting Precautions Cable Routing Safety Note: Please ensure that you are using the latest version of this User Guide, which can be downloaded from www.poynting.tech Version 1.0...
- Page 4 Packing Check List Item Description Quantity OMNI-700 Series Antenna Only Wall Knock-in Screws Pipe Clamp Adhesive Disc L-Bracket M4 stainless steel machine screw and washer UG-OMNI-700...
- Page 5 Appearance of Components Antenna Unit* Wall Knock-in Screw Pipe Clamp Adhesive Disc L-Bracket M4 machine screw and M4 flat washer *Antenna appearance and connections may vary depending on model Version 1.0...
- Page 6 2. Introduction This User Guide provides information on the installation instructions of the Omni- directional antenna (OMNI-700 series). Tools which may be required 6mm Masonry drill bit Impact drilling machine Screwdriver- cross slot/Philips & flat Hammer UG-OMNI-700...
- Page 7 For both pole and wall mount options, attach the L-Bracket to the antenna first using the provided M4 screws and washers. Antenna Configuration 1 Pole mount with L-Bracket and pipe clamp Exploded View Version 1.0...
- Page 8 Antenna Configuration 2 Wall mount with L-Bracket and knock-in screws Use the L-bracket as a template to drill holes Antenna Configuration 3 Surface mount with adhesive disc Use adhesive disc as template for drilling a cable hole UG-OMNI-700...
-
Page 9: Cable Routing
3. Antenna Mounting Precautions Place the antenna at the highest • point and ensure that there aren't any surrounding obstructions to the antenna. In order to avoid communication • interference, ensure that the antenna is placed at least 0.5m away from other antennas and metal objects. - Page 10 Avoid running cables through • components or sharp apertures that may cause excessive chafing. Doing so may erode the jacket and break signal continuity. Also, avoid kinking, pinching, or twisting a cable during a run. • Use cable ties to secure the antenna cables.
- Page 11 When installing your antenna, remember: • 1. Do not install near power lines as they can electrocute you. 2. Do not install on a wet or windy day or when there is lighting or thunder in the area. 3. Wear shoes with rubber soles and heels, protective clothing (long sleeve shirt or jacket) and rubber gloves.
