OMNI-703
Use r G uide
USA
1804 Owen Court,
Suite 104, Mansfield,
TX 76063
Tel: +1 817 533-8130
sales-us@poynting.tech
Version 3.0
www.ime.de
Euro pe
Kronstadler Straße 4,
81677 München
Germany
Tel: +49 89 2080 265 38
Mob.: +49 176 529 733 50
sales-europe@poynting.tech
Advertisement
Related Manuals for Poynting OMNI-703
Summary of Contents for Poynting OMNI-703
- Page 1 OMNI-703 www.ime.de Use r G uide So uth Afric a Euro pe Unit 4, N1 Industrial Park Kronstadler Straße 4, 1804 Owen Court, Landmarks Ave Suite 104, Mansfield, 81677 München Samrand, 0157 Germany TX 76063 South Africa Tel: +1 817 533-8130...
- Page 2 www.ime.de PCL-A-OMNI-0703...
- Page 3 Index Packing Check List Introduction www.ime.de Antenna Mounting Precautions Cable Routing Safety Note: Please ensure that you are using the latest version of this User Guide, which can be downloaded from www.poynting.tech Version 3.0...
- Page 4 Packing Check List Item Description Quantity A-OMNI-0703 Antenna Only www.ime.de Wall Knock-in Screws Pipe Clamp Adhesive Disc L-Bracket M4 stainless steel machine screw and washer PCL-A-OMNI-0703...
- Page 5 Appearance of Components Ante nna Unit www.ime.de Wa ll Kno c k- in Sc re w Pipe C la m p Adhe sive Disc L - Bra c ke t M4 m a c hine sc re w a nd M4 fla t wa she r Version 3.0...
- Page 6 2. Introduction This User Guide provides information on the installation instructions of the Omni- directional antenna (A-OMNI-0703). www.ime.de T o o ls whic h m a y b e re q uire d 6mm Masonry drill bit Impact drilling machine Screwdriver- cross slot/Philips &...
- Page 7 For both pole and wall mount options, attach the L-Bracket to the antenna first using the provided M4 screws and washers. www.ime.de Ante nna C o nfig ura tio n 1 Pole mount with L-Bracket and pipe clamp Exploded View Version 3.0...
- Page 8 Ante nna C o nfig ura tio n 2 Wall mount with L-Bracket and knock-in screws Use the L-bracket as a template to drill holes www.ime.de Ante nna C o nfig ura tio n 3 Surface mount with adhesive disc Use adhesive disc as template for drilling a cable hole PCL-A-OMNI-0703...
-
Page 9: Cable Routing
3. Antenna Mounting Precautions Place the antenna at the highest • point and ensure that there aren't any surrounding obstructions to the antenna. In order to avoid communication • www.ime.de interference, ensure that the antenna is placed at least 0.5m away from other antennas and metal objects. - Page 10 Avoid running cables through • components or sharp apertures that may cause excessive chafing. Doing so may erode the jacket and break signal continuity. Also, avoid kinking, pinching, or twisting a cable during a run. www.ime.de • Use cable ties to secure the antenna cables.
- Page 11 When installing your antenna, remember: • 1. Do not install near power lines as they can electrocute you. 2. Do not install on a wet or windy day or when there is lighting or thunder in the area. www.ime.de 3. Wear shoes with rubber soles and heels, protective clothing (long sleeve shirt or jacket) and rubber gloves.
