Congratulations on your latest Target purchase. Now what? Don't start sweating over the box of parts. This will be easy. We did the hard work for you. All you need to do is follow our simple instructions and you'll be on your way to transforming your room in no time.
table of contents introduction hardware parts list how to use the cam lock system assembly 7-15 QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number ready when calling.
Parts shown are the base cabinet of your model. Please note, most parts are labeled with a sticker or have a letter stamped on a raw edge. Parts List This piece is paperboard construction. It is not made from ITEM PART NUMBER DESCRIPTION wood but is required for assembly of your unit.
step (2) x4 (6) x12 cam bolt wood dowel (8) x1 wall anchor kit 1. Screw-in cam bolts must be screwed down flush. 2. Refer to page 6 for instructions on how to use the cam lock system.
Page 8
step Proper orientation of CAM LOCK finished edge (1) x2 (6) x2 (2) x2 cam lock wood dowel cam bolt 1. Screw-in cam bolts must be screwed down flush. 2. Refer to page 6 for instructions on how to use the cam lock system.
Page 9
step Proper orientation of CAM LOCK finished edge (2) x2 (6) x2 (1) x2 cam bolt cam lock wood dowel 1. Screw-in cam bolts must be screwed down flush. 2. Refer to page 6 for instructions on how to use the cam lock system.
Page 10
step Proper orientation of CAM LOCK (6) x4 (1) x4 cam lock wood dowel 1. Refer to page 6 for instructions on how to use the cam lock system.
Page 11
step finished edge UNLOCK LOCK 1. Refer to page 6 for instructions on how to use the cam lock system.
Page 12
step finished edge finished edge (3) x4 confirmat screw 1. Finished edges will face up.
Page 13
step finished edge UNLOCK LOCK 1. Refer to page 6 for instructions on how to use the cam lock system.
Page 14
step IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. WARNING Please make sure that the Back Panel is attached securely. All nails must be driven into the parts straight and centered. Failure to do so could cause instability, product collapse, and/or serious injury.
Page 15
step (5) x2 (4) x12 metal base #8x7/16" pan head screw...
Page 16
step IMPORTANT! THIS UNIT MUST BE SECURE TO A WALL TO HELP PREVENT TIP OVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT. For Masonry, Concrete, or hole other wall materials: Consult your local hardware store stud for appropriate anchors to securely option 2...
MAXIMUM LOADS This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Warning: Risk of injury to persons - do not place a television on this furniture. 30 lbs.
