O P E R A T O R ' S
M A N U A L
LAND PLANES
LP-48L
LP-60L
LP10L_16330_05/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP-48L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tufline LP-48L

  • Page 1 O P E R A T O R ' S M A N U A L LAND PLANES LP-48L LP-60L LP10L_16330_05/18...
  • Page 2: Introduction Ii

    TO THE DEALER: Assembly and proper installation of this product is the responsibility of the Monroe Tufline dealer. Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists in the Owner’s/Operator’s Manual are completed before releasing equipment to the owner.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........ii SPECIFICATIONS / GENERAL INFORMATION .
  • Page 4: Specifications / General Information

    SPECIFICATIONS LP-48L LP-60L 3-Point Hitch Limited Category 1 Limited Category 1 (Quick Hitch Compatible) (Quick Hitch Compatible) Working Width 48" 60" Overall Width 53" 65" Overall Height 32" 32" Overall Length 45" 45" Tractor HP Range 18-40 HP 18-40 HP...
  • Page 5: Safety Decals 2

    SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH Replace Decals Immediately If Damaged! Check that all safety decals are installed and in good condition. Replacement Part numbers are listed below.
  • Page 6: Safety Rules

    SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Safety is a primary concern in the design and Wear sturdy, rough-soled work shoes and protec- manufacture of our products. Unfortunately, our tive equipment for eyes, hair, hands, hearing, efforts to provide safe equipment can be wiped out and head;...
  • Page 7: Maintenance

    SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! OPERATION • Do not stop, start, or change directions suddenly on slopes. • Never go underneath equipment (lowered to the ground or raised) unless it is properly blocked • Always operate down slopes; never across the and secured.
  • Page 8 SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! MAINTENANCE(cont’d) area while performing adjustments, service, or • When performing maintenance or repairs maintenance. make sure the equipment is in the lowered • Tighten all bolts, nuts, and screws to torque position and properly blacked and secured to chart specifications, page 12.
  • Page 9: Dealer Instructions 6

    DEALER INSTRUCTIONS Pre-Assembly after proper adjustment is made. ____ Check that all safety decals are installed Top Link Mast Assembly and in good condition. Replace if damaged. ____ Check all bolts to be sure they are tight. Reference Figure 2 (Pg. 10). ____ Check that all cotter pins and safety pins 1.
  • Page 10: Operation 7

    OPERATION levers can cause equipment to drop or rotate Safety is a primary concern in the design and unexpectedly and cause severe injury or death. manufacture of our products. Unfortunately, our efforts to provide safe equipment can be wiped • Service work does not require going under- out by an operator’s single careless act.
  • Page 11 Adjusting Land Plane Connecting Land Plane to Tractor Adjust the 3-point top link so that both blades touch The land plane is compatible with tractors equipped the ground at the same time. In most cases this will with Category 1, 3-point hitch systems that use give the desired results.
  • Page 12: Owner Service

    OWNER SERVICE WARNING WARNING • NEVER GO UNDERNEATH EQUIPMENT. • Keep all persons away from operator control Never place any part of the body underneath area while performing adjustments, service, or equipment or between moveable parts even maintenance. when the engine has been turned off. Hydraulic •...
  • Page 13: Parts Catalog 10

    PARTS CATALOG Figure 2 Parts Catalog 10...
  • Page 14 PARTS CATALOG (cont'd) Ref.# Part # Description Qty. 16326 LP-48L FRAME WELDMENT 16327 LP-60L FRAME WELDMENT 14991 A-FRAME 2" LH 14990 A-FRAME 2" RH 10701 48" CUTTING EDGE 10702 60" CUTTING EDGE 16328 STRUT 10699 PLOW BOLT, 5/8" X 1 3/4" GR. 5...
  • Page 15: Bolt Size And Bolt Torque Chart 12

    Bolt Size Chart SAE Torque Chart Bolt Size and Bolt Torque Chart 12...
  • Page 16 PART NO. 16330 © 2018 Monroe Tufline Manufacturing, Inc. All Rights Reserved...
