  • Page 1 O P E R A T O R ' S M A N U A L Double Roller Culti-Packers DCP-8 DCP-10 DCP-12 DCP-16 DCP_06/18...
  • Page 2: Introduction Ii

    TO THE DEALER: Assembly and proper installation of this product is the responsibility of the Monroe Tufline dealer. Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists in the Owner’s/Operator’s Manual are completed before releasing equipment to the owner.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..........ii SPECIFICATIONS / GENERAL INFORMATION .
  • Page 4: Specifications / General Information

    SPECIFICATIONS Cultipacker DCP-8 DCP-10 DCP-12 DCP-18 Type Hitch Clevis Clevis Clevis Clevis Type Width Tractor HP 40-80 HP 40-80 HP 40-80 HP 40-80 HP Range Approximate 4025 lbs 4650 lbs 5200 lbs 5730 lbs Operating Weight GENERAL INFORMATION The purpose of this manual is to assist you your particular situation.
  • Page 5: Safety Rules

    SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Safety is a primary concern in the design and Wear sturdy, rough-soled work shoes and protec- manufacture of our products. Unfortunately, our tive equipment for eyes, hair, hands, hearing, efforts to provide safe equipment can be wiped out and head;...
  • Page 6 SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! OPERATION • Do not stop, start, or change directions suddenly on slopes. • Never go underneath equipment (lowered to the ground or raised) unless it is properly blocked • Always operate down slopes; never across the and secured.
  • Page 7 SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! MAINTENANCE(cont’d) area while performing adjustments, service, or • When performing maintenance or repairs maintenance. make sure the equipment is in the lowered • Tighten all bolts, nuts, and screws to torque position and properly blacked and secured to chart specifications, page 11.
  • Page 8: Dealer Instructions

    ____ Show customer the safe, proper proce- ____ Complete the Warranty Registration dures to be used when mounting, dismounting, located on the Monroe Tufline website. and storing equipment. ____ For mounted units, add ballast in front tires, and/or front tractor weight to enhance front end stability.
  • Page 9: Operation 6

    OPERATION Safety is a primary concern in the design and levers can cause equipment to drop or rotate manufacture of our products. Unfortunately, our unexpectedly and cause severe injury or death. efforts to provide safe equipment can be wiped • Service work does not require going under- out by an operator’s single careless act.
  • Page 10: Owner Service

    OWNER SERVICE WARNING WARNING • NEVER GO UNDERNEATH EQUIPMENT. • Keep all persons away from operator control Never place any part of the body underneath area while performing adjustments, service, or equipment or between moveable parts even maintenance. when the engine has been turned off. Hydraulic •...
  • Page 11: Parts Catalog 8

    Parts Catalog 8...
  • Page 12 *MS = Model Specific 9 Parts Catalog...
  • Page 13 Parts Catalog 10...
  • Page 14: Bolt Size And Bolt Torque Chart

    Options and Bolt Torque Chart SAE Torque Chart 11 Bolt Size and Bolt Torque Chart...
  • Page 15: Notes 12

    NOTES Notes 12...
  • Page 16 PART NO. 16487 © 2018 Monroe Tufline Manufacturing, Inc. All Rights Reserved...
