Wood-Mizer
Sawmill
Safety, Setup, Operation
& Maintenance Manual
LT80AHD
rev. A3.01
Safety is our #1 concern! Read and understand
!
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
June 2002
Form #1045
