Summary of Contents for AEG XCD6847IB
- Page 1 EN User Manual | Hob XCD6847IB aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................11 5. BEFORE FIRST USE..................13 6. -
Page 3: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. - Page 4 • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use a steam cleaner to clean the appliance. •...
-
Page 5: Safety Instructions
means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. - Page 6 • Use the correct electricity mains cable. • Set the cooking zone to “off” after each • Do not let the electricity mains cable use. tangle. • Do not put cutlery or saucepan lids on the • Make sure that a shock protection is cooking zones.
-
Page 7: Installation
• Be careful not to let objects or cookware use abrasive products, abrasive cleaning fall on the appliance. The surface can be pads, solvents or metal objects, unless damaged. otherwise specified. • Do not activate the cooking zones with 2.5 Service empty cookware or without cookware. -
Page 8: Attaching The Seal
3.3 Attaching the seal Follow the hob connection diagram and the window switch connection diagram (if applicable) presented in the installation booklet and / or the labels under the hob. Only for selected countries In case of exhaust installation a window switch might be required (consult an authorised technician). -
Page 9: Connection Cable
INTEGRATED INSTALLATION Find the video tutorial "How to install your AEG Extractor Hob" by typing out the full name indicated in the graphic below. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG Extractor Hob Filter housing assembly Before the first use make sure to insert the... - Page 10 3. Connect the ends of black and brown CAUTION! cables. 4. Apply a new wire end sleeve on the Connections via contact plugs are shared wire's end (special tool required). forbidden. 5. Connect the ends of two blue cables. 6. Apply a new wire end sleeve on the CAUTION! shared wire's end (special tool required).
-
Page 11: Product Description
4. PRODUCT DESCRIPTION 4.1 Product overview Grid Cabinet back wall fitting Filter Tube Filter housing Adapter Connector 4.2 Cooking surface layout Induction cooking zone Control panel Hood ENGLISH... -
Page 12: Control Panel Layout
4.3 Control panel layout Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Timer To set the function. To increase or decrease the time. Timer display To show the time in minutes. -
Page 13: Display Indicators
Sensor Function Description field Hob control bar To set a heat setting. 4.4 Display indicators Indicator Description There is a malfunction. + digit OptiHeat Control (3 step Residual heat indicator): continue cooking / keep warm / resid‐ ual heat. 5. BEFORE FIRST USE 4. -
Page 14: Using The Cooking Zones
If you remove cookware from an activated cooking zone and set it aside temporarily, the indicators above the corresponding control bar will start blinking. If you do not place the cookware back on the activated cooking zone within 120 seconds, the cooking zone will automatically deactivate. -
Page 15: Timer Options
directly in the bottom of the cookware. The Minute Minder glass ceramic is heated by the heat of the cookware. You can use this function when the hob is activated but the cooking zones do not The indicators appear when a cooking zone operate. - Page 16 When you use the hob for the first time, the function is usually activated by default. You can activate the function while the hob is on and none of the cooking zones are active, or at any point during the cooking session. If you activate the function while the hob is off, none of the cooking zones operate and there is no residual heat visible on...
- Page 17 Hood Residual heat level (hob is off) Residual heat level (hob is Boiling Frying mode The function can operate uninterrupted for a maximum of 10 minutes. After that time the fan speed setting automatically changes to 3. If you deactivate the hob while AUTO is You can activate the function again, if running, the function will be remembered needed.
-
Page 18: Menu Structure
cycle is over, the fan switches off automatically. Sym‐ Setting Possible options To deactivate the function while it is running: Auto Breeze On / Off (--) Press AUTO or 0 on the hood control bar. Alarm / error histo‐ The list of recent The hood fan deactivates. -
Page 19: Child Safety Device
7.4 Child Safety Device Heat setting The hob deactivates This function prevents an accidental after operation of the hob and the hood. 1 - 2 6 hours To activate the function: press . Do not 3 - 4 5 hours set any heat setting / hood setting. -
Page 20: Hints And Tips
8. HINTS AND TIPS – Cookware with a diameter smaller WARNING! than the size of a given cooking zone receives only part of the power Refer to Safety chapters. generated by the cooking zone which results in slower heating. 8.1 Cookware –... -
Page 21: Noises During Operation
8.2 Noises during operation • rhythmic sound: cookware is detected. 8.3 Öko Timer (Eco Timer) To save energy, the heater of the cooking The noises are normal and do not zone deactivates before the count down timer indicate any malfunction. Cookware sounds. -
Page 22: Care And Cleaning
8.5 Hints and Tips for the hood each cooking session. The speed increases gradually. You can also adjust • The grid covering the hood is made of the speed of the fan manually. aluminium and stainless steel . You can put pots on it while the hood is not operating. - Page 23 2. Lift the grid and clean the hood area WARNING! carefully with a moist cloth or sponge and a mild cleaning agent. An oversaturated filter can pose a risk of 3. Wipe away the excess liquid gathered on fire. the bottom of the hood cavity using a sponge or a dry cloth.
-
Page 24: Cleaning The Filter Housing
the odour filtration. You can use a soft sponge, a soft cloth, or a non-abrasive cleaning brush to remove food remains, if necessary. You can also wash the filter in a dishwasher at 65-70 °C (using a program longer than 90 min), without detergents and without dishes in the same load. - Page 25 Problem Possible cause Remedy The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. You did not set the heat setting for Activate the hob again and set the 60 seconds.
- Page 26 Problem Possible cause Remedy Heating up takes a long time. Cookware is too small and receives For optimal heat transfer use cook‐ only a part of the power generated ware with bottom diameter similar to by the cooking zone. the size of the cooking zone (i.e. the maximum cookware diameter value in "Technical data"...
-
Page 27: Technical Data
11. TECHNICAL DATA 11.1 Rating plate Model XCD6847IB PNC 949 598 334 00 Typ 66 D4A 01 AA 220 - 240 V / 400 V 2N, 50 Hz Induction 7.2 kW Made in: Germany Ser.Nr....7.2 kW 11.2 Cooking zones specification... - Page 28 12.4 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Hood Product Information Sheet according to (EU) No 65/2014 Supplier’s name or trade mark Model identifier XCD6847IB Annual Energy Consumption - AEChood 28.8 kWh/a Energy Efficiency Class Fluid Dynamic Efficiency - FDEhood 32.4...
-
Page 29: Environmental Concerns
Measured power consumption off mode - Po 0.49 Measured power consumption in standby mode - Ps Additional Information according to (EU) No 66/2014 Time increase factor - f Energy Efficiency Index - EEIhood 41.4 Measured air flow rate at best efficiency point - QBEP 259.2 m³/h Measured air pressure at best efficiency point - PBEP... - Page 32 867385176-B-282024...
