34942G/35940G/35941G/35944G
Gas hob
Table de cuisson
Kochmulde
Gaskookplaat
Piano di cottura
Operating and Installation Instructions GB
Notice d'utilisation et d'encastrement FR/BE
Gebrauchs- und Einbauanweisung
BE
Gebruiksaanwijzing
en Installatievoorschrift
NL/BE
Istruzioni per l'uso e l'installazione
IT
Advertisement
Table of Contents
Related Manuals for AEG 34942G
Summary of Contents for AEG 34942G
- Page 1 34942G/35940G/35941G/35944G Gas hob Table de cuisson Kochmulde Gaskookplaat Piano di cottura Operating and Installation Instructions GB Notice d’utilisation et d’encastrement FR/BE Gebrauchs- und Einbauanweisung Gebruiksaanwijzing en Installatievoorschrift NL/BE Istruzioni per l’uso e l’installazione...
-
Page 2: Important Safety Information
ENGLISH Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 350 350 Installation This hob must be installed by qualified personnel, according to the manufacturer’s instructions and to the relevant British Standards. -
Page 3: Environmental Information
When in use a gas cooking hob will produce heat and moisture in the room in which it has been installed. Ensure there is a continuous air supply, keeping air vents in good condition or installing a cooker hood with a venting hose. When using the hob for a long period of time, the ventilation should be improved, by opening a window or increasing the extractor speed. -
Page 4: Table Of Contents
Contents Important Safety Information ... 2 Instructions for the User... 6 Description of the Hob ... 6 Operation ...7 Maintenance and Cleaning ... 8 The Hob Top ... 8 Pan Supports ... 8 The Burners ... 8 Something Not Working? ... 9 Service and Spare Parts ... - Page 5 Guide to Use the instructions The following symbols will be found in the text to guide you throughout the Instructions: Safety Instructions Step by step instructions for an operation Hints and Tips This appliance is manufactured according to the following EEC directives: 73/23 EEC - 90/683 EEC - 93/68 EEC - 89/336 EEC - 90/396 EEC, current edition.
-
Page 6: Instructions For The User
Description of the Hob (Mod. 34942 G) 1. Hob Top 2. Rapid Burner 3. Semi-rapid Burners 4. Double-crown Burner 5. Auxiliary Burner 6. Control knob for back left burner (semi-rapid) 7. Control knob for back right burner (semi-rapid) 8. Control knob for ront right burner (auxiliary) 9. -
Page 7: Operation
Take care when frying food in hot oil or fat, as the overheated splashes could easily ignite If the control knobs become difficult to turn, please contact your local AEG Service Force Centre. ), then push it down to ignite the burner. minimum... -
Page 8: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. The Hob Top Regularly wipe over the hob top using a soft cloth well wrung out in warm water to which a little washing up liquid has been added. -
Page 9: Something Not Working
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local AEG Service Force Centre. SYMPTOM There is no spark when lighting the gas The gas ring burns unevenly If after all these checks, your hob still does not operate correctly, contact your local AEG Service Force Centre. -
Page 10: Service And Spare Parts
4. The model and the serial number (see rating label on the back of this instruction booklet) 5. Date of purchase CUSTOMER CARE For general enquiries concerning your AEG appliance and for further information on AEG products, contact our Customer Care Department by letter or telephone as follows: Customer Care Department... -
Page 11: Guarantee Conditions
3. Should guarantee repairs be necessary the purchaser must inform the nearest AEG Service Force Centre (manufacturer’s service or authorised agent). AEG reserves the right to stipulate the place of the repair (i.e. the customer’s home, place of installation or AEG workshop). -
Page 12: Instructions For The Installer
Instructions for the Installer Engineers technical data OVERALL DIMENSIONS Width: CUT OUT DIMENSIONS SUPPLY CONNECTIONS Gas: IGNITION HT SPARK HEAT INPUT Rear Left Burner (semi rapid) Front Left Burner (rapid) Central Burner (double-crown) Rear Right Burner (semi rapid) Front Right Burner (auxiliary) APPLIANCE CLASS APPLIANCE CATEGORY... - Page 13 BURNER TYPE OF GAS POSITION NOMINAL THERMAL POWER NATURAL GAS 20 mbar NOMINAL FLOW VALUE = RATE 37.78 MJ/m NOZZLE REFERENCE Ws - 50.7 MJ/ m 1/100 mm NOMINAL THERMAL LPG GAS POWER 28-30/37 mbar NOMINAL FLOW VALUE = RATE 49.92 MJ/Kg NOZZLE REFERENCE 1/100 mm...
-
Page 14: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). Detailed recommendations are contained in the following British Standards Codes Of Practice: B.S. 6172/ B.S. 5440, Par. 2 and B.S. 6891 Current Editions. -
Page 15: Installation
CLEARANCES REQUIRED WHEN FITTING THE GAS HOB WITHOUT A COOKER HOOD ABOVE 700 mm 400 mm FO 2027* Installation IMPORTANT This hob must be installed by qualified personnel to the relevant British Standards. Any gas installation must be carried out by a CORGI registered installer. -
Page 16: Gas Connection
Installation FO 0264 A) End of shaft with nut B) Washer C) Elbow this book be ignored. On the end of the shaft, which includes the GJ 1/2" threaded elbow, adjustment is fixed so that the washer is fitted between the components as shown in the diagram. -
Page 17: Cut Out Size
Cut Out Size The dimensions of the cut-out are given in the diagram. FO 2407 Building In Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface. -
Page 18: Building Over A Kitchen Unit With Door
Building in ON/OFF SWITCH FLEX OUTLET FO 0763 Building over a kitchen unit with door Proper arrangements must be taken in designing the furniture unit, in order to avoid any contact with the bottom of the hob which can be heated when it is operated. The recommended solution is shown in diagram 3. -
Page 19: Fitting The Hob To The Worktop
Fitting the hob to the worktop Before fitting the hob into the cut out, a sealing gasket supplied with the hob must be fitted to the edge of the cut out. It is essential that no gaps are left in this seal in order to prevent spillage near the hob seeping into the cabinet below. -
Page 20: Electrical Connections
Electrical connections Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS HOB MUST BE EARTHED. The manufacturer declines any liability should these safety measures not be observed. -
Page 21: Permanent Connection
Permanent Connection In the case of a permanent connection, it is necessary that you install a double pole switch between the hob and the electricity supply (mains), with a minimum gap of 3 mm. between the switch contacts and of a type suitable for the required load in compliance with the current electric regulations. -
Page 22: Fault Finding
Fault Finding Preliminary Electrical Systems Check START Isolate appliance and carry out: A: Earth Continuity check. Has inlet fuse blown? Inlet wiring faulty. Rectify any fault. Isolate appliance and carry out: B: Insulation check. Rectify any fault including replacing fuses as necessary. Carry out: Carry out: D: Resistance to... - Page 23 A. EARTH CONTINUITY CHECK Appliance must be electrically disconnected - meter set on 1 scale and adjust zero if necessary. — Test leads from any appliance earth point to earth pin on plug. Resistance should be less than 0.1 for continuity and all contacts are clean and tight. B.
-
Page 24: Ignition System / Gas Ignition
Fault finding Ignition System / Gas Ignition Ignitor does not spark Check plug top fuse and replace if necessary Check polarity and earth continuity of supply point Check earth continuity of appliance Check continuity from 'N' on the mains connector block and "O" on the ignitor unit Check continuity from 'L' on the mains connector block and the... -
Page 25: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. 1) Turn the gas tap to the MAX position and ignite. 2) Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 26: Servicing
Conversion from Natural Gas to LPG It is important to note that this model is designed for use with natural gas but can be converted for use with butane or propane gas providing the correct injectors are fitted and the gas rate is adjusted to suit. Method 1) Ensure that the gas taps are in the 'OFF' position 2) Isolate the hob from the electricity supply...
