- Page 1 EN User Manual | Hob XCD6847AB aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5. BEFORE FIRST USE..................12 6. -
Page 3: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. - Page 4 • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use water spray and steam to clean the appliance. •...
-
Page 5: Safety Instructions
means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. - Page 6 • Use the correct electricity mains cable. • Set the cooking zone to “off” after each • Do not let the electricity mains cable use. tangle. • Do not put cutlery or saucepan lids on the • Make sure that a shock protection is cooking zones.
-
Page 7: Installation
• Be careful not to let objects or cookware abrasive cleaning pads, solvents or metal fall on the appliance. The surface can be objects, unless otherwise specified. damaged. 2.5 Service • Do not activate the cooking zones with empty cookware or without cookware. •... -
Page 8: Connection Cable
The window switch has to be installed by an authorised technician. Refer to the installation booklet. Find the video tutorial "How to install your AEG Extractor Hob" by typing out the full name indicated in the graphic below. min. min. - Page 9 2. Remove a part of the insulation of the WARNING! brown, black and blue cable ends. 3. Connect the ends of black and brown All electrical connections must be made cables. by a qualified electrician. 4. Apply a new wire end sleeve on the shared wire's end (special tool required).
-
Page 10: Product Description
4. PRODUCT DESCRIPTION 4.1 Product overview Grid Cabinet back wall fitting Filter Tube Filter housing Adapter Connector 4.2 Cooking surface layout Induction cooking zone Control panel Hood ENGLISH... -
Page 11: Control Panel Layout
4.3 Control panel layout Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Timer To set the function. To increase or decrease the time. Timer display To show the time in minutes. -
Page 12: Display Indicators
Sensor Function Description field Hob control bar To set a heat setting. 4.4 Display indicators Indicator Description There is a malfunction. + digit OptiHeat Control (3 step Residual heat indicator): continue cooking / keep warm / resid‐ ual heat. 5. BEFORE FIRST USE 4. -
Page 13: Using The Cooking Zones
If you remove cookware from an activated cooking zone and set it aside temporarily, the indicators above the corresponding control bar will start blinking. If you do not place the cookware back on the activated cooking zone within 120 seconds, the cooking zone will automatically deactivate. - Page 14 directly in the bottom of the cookware. The Minute Minder glass ceramic is heated by the heat of the cookware. You can use this function when the hob is activated but the cooking zones do not The indicators appear when a cooking zone operate.
-
Page 15: Manual Mode
If you activate the function while the hob is off, none of the cooking zones operate and there is no residual heat visible on the control panel, the function will switch off by itself after a few seconds. 1. Press and hold to activate the hob. -
Page 16: Menu Structure
• Once the timer finishes counting down, the Auto Breeze hood stops operating. • It is possible to set the hood timer while The function automatically sets the hood fan AUTO is on. If AUTO deactivates the hood to continue running after you finish cooking before the set time runs out, the timer will and switch off the hob. -
Page 17: Additional Functions
To exit the menu: press Sym‐ Setting Possible options OffSound Control Alarm / error histo‐ The list of recent You can activate / deactivate the sounds in alarms / errors. the Menu > User settings. To enter user settings: press and hold for 3 seconds. -
Page 18: Child Safety Device
The heat setting is lowered to 1. The speed of To deactivate the function: press . Do the hood fan decreases to 1. not set any heat setting / hood setting. Press 2. To deactivate the function: press and hold for 3 seconds, until the indicator The previous heat setting / fan speed setting above the symbol disappears. -
Page 19: Noises During Operation
• correct: cast iron, steel, enamelled steel, sizes to fit most common cookware types. For stainless steel, multi-layer bottom (with a more information visit our website. correct marking from a manufacturer). • not correct: aluminium, copper, brass, glass, ceramic, porcelain. Cookware is suitable for an induction hob •... -
Page 20: Care And Cleaning
cooking zone with the medium heat setting uses less than a half of its power. The data in the table is for guidance only. Heat setting Use to: Time Hints (min) Keep cooked food warm. as neces‐ Put a lid on the cookware. sary 1 - 2 Hollandaise sauce;... -
Page 21: Cleaning The Hood
9.3 Cleaning the hood • Always use a scraper recommended for hobs with a glass surface. Use the scraper Grid only as an additional tool for cleaning the glass after the standard cleaning The grid guides the air into the hood. procedure. - Page 22 9.4 Cleaning the hood filter The 2-in-1 long life carbon filter combines the filtration of grease and odour in one unit. The filter consists of two elements located on the left and right side of the filter housing. Each element is made up of the grease filter and the long life carbon filter.
-
Page 23: Cleaning The Filter Housing
b. Place the filter housing back inside shelf. Make sure to use a non-fan oven the hood cavity. function. Alternatively, you can leave the filter to dry overnight at room temperature. The filter needs to be fully Cleaning the filter housing dried before reassembly. - Page 24 Problem Possible cause Remedy You can hear a constant beep The electrical connection is incor‐ Disconnect the hob from the electrical noise. rect. supply. Ask a qualified electrician to check the installation. You cannot select the maximum The other zones consume the maxi‐ Reduce the heat setting of the other heat setting for one of the cook‐...
-
Page 25: Technical Data
Make sure, you operated the hob correctly. If not the servicing by a service 11. TECHNICAL DATA 11.1 Rating plate Model XCD6847AB PNC 949 598 147 00 Typ 66 D4A 01 AA 220 - 240 V / 400 V 2N, 50 Hz Induction 7.2 kW... -
Page 26: Cooking Zones Specification
For optimal heat transfer and cooking results use cookware with bottom diameter similar to 12. ENERGY EFFICIENCY 12.1 Product Information according to EU Ecodesign Regulation for Hob Model identification XCD6847AB Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cooking zones (Ø) - Page 27 12.4 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Hood Product Information Sheet according to (EU) No 65/2014 Supplier’s name or trade mark Model identifier XCD6847AB Annual Energy Consumption - AEChood 28.8 kWh/a Energy Efficiency Class Fluid Dynamic Efficiency - FDEhood 32.4...
-
Page 28: Environmental Concerns
Appliance tested according to: IEC / EN • When you start cooking, set the hood fan 61591, IEC / EN 60704-1, IEC / EN at a low speed level. Once the cooking is 60704-2-13, IEC / EN 50564. finished, keep the hood running for a few minutes. - Page 32 867379417-B-342024...
