- Page 1 EN User Manual | Hob XUB6745CB aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................11 5. BEFORE FIRST USE..................13 6. -
Page 3: General Safety
• Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. - Page 4 • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • Do not use the appliance before installing it in the built-in structure. • Do not use water spray and steam to clean the appliance. •...
-
Page 5: Safety Instructions
means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. - Page 6 • Use the correct electricity mains cable. • Set the cooking zone to “off” after each • Do not let the electricity mains cable use. tangle. • Do not put cutlery or saucepan lids on the • Make sure that a shock protection is cooking zones.
-
Page 7: Installation
• Be careful not to let objects or cookware abrasive cleaning pads, solvents or metal fall on the appliance. The surface can be objects, unless otherwise specified. damaged. 2.5 Service • Do not activate the cooking zones with empty cookware or without cookware. •... - Page 8 On-top installation 1. Clean the worktop around the cut out area. 2. Attach the supplied 2x6 mm seal stripe to the lower edge of the hob, along the outer edge of the glass ceramic. Do not stretch it. Make sure that the ends of the seal min.
-
Page 9: Connection Cable
Find the video tutorial "How to install your INTEGRATED INSTALLATION AEG Extractor Hob 70 cm" by typing out the full name indicated in the graphic below. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG Extractor Hob 70 cm Filter housing assembly The appliance must be used at all times with all the filters included in the scope of delivery. - Page 10 3. Connect the ends of black and brown CAUTION! cables. 4. Apply a new wire end sleeve on the Connections via contact plugs are shared wire's end (special tool required). forbidden. 5. Connect the ends of two blue cables. 6. Apply a new wire end sleeve on the CAUTION! shared wire's end (special tool required).
-
Page 11: Product Description
4. PRODUCT DESCRIPTION 4.1 Product overview Grid Grease filter housing Air duct adapter Grease filter (non-removable) Air duct fitting for the back wall Long life carbon filter Drip tray (under the hood system) 4.2 Cooking surface layout Induction cooking zone Control panel Hood ENGLISH... -
Page 12: Control Panel Layout
4.3 Control panel layout 1 12 Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Description field On / Off To activate and deactivate the appliance. Pause To activate and deactivate the function. Timer To set the function. -
Page 13: Before First Use
5. BEFORE FIRST USE 4. Press to exit. WARNING! Power levels Refer to Safety chapters. Refer to “Technical data” chapter. 5.1 Power limitation CAUTION! Power limitation defines how much power is Make sure that the selected power fits used by the hob in total, within the limits of the house installation fuses. -
Page 14: Heat Setting
the area marking. If the cookware is located To deactivate the function: change the heat between the two centres, Bridge function will setting. not be activated. 6.6 OptiHeat Control (3 step Residual heat indicator) WARNING! As long as the indicator is visible, there is a risk of burns from residual heat. -
Page 15: Minute Minder
setting. Change the heat settings of the 3. Press to start the timer or wait 3 cooking zones manually, if necessary. seconds. The timer begins to count down. • The hood extractor is always available as To change the time: select the cooking zone an electrical load. -
Page 16: Menu Structure
A signal sounds and an indicator above the When you use the hob for the first time, the symbol appears. function is activated by default. 3. Place cookware on the hob and select a When the function operates, the indicator heat setting level. -
Page 17: Additional Functions
between the settings press on the front timer. To change the setting value press Refer to "Menu structure". on the front timer. When the sounds are off you can still hear the sound when: To exit the menu: press • you touch OffSound Control •... -
Page 18: Child Safety Device
7.4 Child Safety Device indicator above the symbol disappears. You can operate the hob. When you deactivate This function prevents an accidental the hob with the function operates again. operation of the hob and the hood. 7.5 Bridge To activate the function: press . -
Page 19: Noises During Operation
8.2 Noises during operation diameter value in "Technical data" > "Cooking zones specification"). – Cookware with a diameter smaller than the size of a given cooking zone The noises are normal and do not receives only part of the power indicate any malfunction. -
Page 20: Care And Cleaning
Heat setting Use to: Time Hints (min) 1 - 2 Hollandaise sauce; melt: butter, choco‐ 5 - 25 Mix from time to time. late, gelatine. Solidify: fluffy omelettes, baked eggs. 10 - 40 Cook with a lid on. 2 - 3 Simmer rice and milk-based dishes, 25 - 50 Add at least twice as much liquid as... -
Page 21: Cleaning The Hob
9.2 Cleaning the hob 2. Move the drip tray vertically downwards. Be careful not to spill the water. • Remove immediately: melted plastic, plastic foil, salt, sugar and food with sugar, otherwise, the dirt can cause damage to the hob. Take care to avoid burns. Use a special hob scraper on the glass surface at an acute angle and move the blade on the surface. - Page 22 WARNING! Oversaturated filters can pose a risk of fire. Disassembling / reassembling the filters The filters and the grease filter housing are located right under the grid in the centre of the hob. Remove them carefully as they might be slippery due to accumulated grease. The grease filters collect grease, oil, and food remains and prevent them from getting...
-
Page 23: Troubleshooting
b. Place the grease filter housing back The counter restarts. inside. c. Place the grid back on. Cleaning the long life carbon filters 1. Wash the filters carefully in warm water Cleaning the grease filters and the without any cleaning agents. Detergents grease filter housing can damage the carbon filtration. - Page 24 Problem Possible cause Remedy The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. You did not set the heat setting for Activate the hob again and set the 60 seconds.
-
Page 25: Technical Data
Authorised Service Centres are in the Service Centre. Give the data from the rating guarantee booklet. plate. Make sure, you operated the hob correctly. If not the servicing by a service 11. TECHNICAL DATA 11.1 Rating plate Model XUB6745CB PNC 949 598 151 00 ENGLISH... -
Page 26: Cooking Zones Specification
For optimal heat transfer and cooking results use cookware with bottom diameter similar to 12. ENERGY EFFICIENCY 12.1 Product Information according to EU Ecodesign Regulation for Hob Model identification XUB6745CB Type of hob Built-In Hob Number of cooking zones Heating technology Induction Diameter of circular cooking zones (Ø) - Page 27 12.4 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Hood Product Information Sheet according to (EU) No 65/2014 Supplier’s name or trade mark Model identifier XUB6745CB Annual Energy Consumption - AEChood 32.7 kWh/a Energy Efficiency Class Fluid Dynamic Efficiency - FDEhood 32.0...
-
Page 28: Environmental Concerns
Energy Efficiency Index - EEIhood 42.6 Measured air flow rate at best efficiency point - QBEP 286.7 m³/h Measured air pressure at best efficiency point - PBEP Maximum air flow - Qmax 650.0 m³/h Measured electric power input at best efficiency point - WBEP 111.9 Nominal power of the lighting system - WL Average illumination of the lighting system on the cooking surface - Emiddle... - Page 32 867379419-B-302024...
