BIS-411M
Bistable relay with
„memory" contact position
Do not dispose of this device in the trash along with other waste! According to the Law on
Waste, electro coming from households free of charge and can give any amount to up to
that end point of collecti on, as well as to store the occasion of the purchase of new equip-
ment (in accordance with the principle of old-for-new, regardless of brand). Electro thrown
in the trash or abandoned in nature, pose a threat to the environment and human health.
Purpose
Electronic bistable pulse relay BIS-411M allows switching on or
off the lighting or other device from several different points by
parallel connected, momentary (bell) control switches.
Functioning
The receiver is switched on after a current pulse caused by pres-
sing any momentary (bell) button connected to the relay. After
the next pulse, the receiver will be switched off.
The relay has the feature of the so-called „memory" of the con-
tact position, which means when the power supply is switched
back on, the relay will be restored to the state it was in when the
power supply was switched off.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
24 V
- 1 -
Advertisement
Related Manuals for F&F BIS-411M 24 V
Summary of Contents for F&F BIS-411M 24 V
- Page 1 F&F Filipowski L.P. Konstantynowska 79/81, 95-200 Pabianice, POLAND phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71 www.fif.com.pl; e-mail: biuro@fif.com.pl BIS-411M 24 V Bistable relay with „memory” contact position Do not dispose of this device in the trash along with other waste! According to the Law on Waste, electro coming from households free of charge and can give any amount to up to that end point of collecti on, as well as to store the occasion of the purchase of new equip- ment (in accordance with the principle of old-for-new, regardless of brand).
- Page 2 Mounting 1. Disconnect the power supply. 2. Fix the relay on a rail in the control box. 3. Connect the power wires to terminals 1-3, any polarity for AC voltage and for DC voltage: connect „+” to terminal 3, „–” to terminal 1.
- Page 3 BIS-411M 24 V is not compatible with backlit buttons. relay power supply 9÷30 V AC/DC control input output – break contact (passive) input – COM power supply contact output – closing contact (active) Technical data power supply 9÷30 V AC/DC contact separated 1×NO/NC maximum load current (AC-1) 16 A...
- Page 4 Power table Table for loads supplied with 230 V AC: tungsten halogen fluorescent energy-saving 2000 W 1250 W 1000 W 500 W 250 W The above data are indicative and will heavily depend on the design of a specific receiver (that is especially important for LED bulbs, energy-saving lamps, electronic transformers and pulse power supply units), switching frequency and operating conditions.
