BIS-411M-LED
Bistable relay with
„memory" contact position
Do not dispose of this device in the trash along with other waste! According to the Law on
Waste, electro coming from households free of charge and can give any amount to up to
that end point of collecti on, as well as to store the occasion of the purchase of new equip-
ment (in accordance with the principle of old-for-new, regardless of brand). Electro thrown
in the trash or abandoned in nature, pose a threat to the environment and human health.
Purpose
Electronic bistable pulse relay BIS-411M-LED allows switching on
or off the lighting or other device from several different points by
parallel connected, momentary (bell) control switches.
Functioning
The receiver is switched on after a current pulse caused by pres-
sing any momentary (bell) button connected to the relay. After
the next pulse, the receiver will be switched off.
The relay has the feature of the so-called „memory" of the con-
tact position, which means when the power supply is switched
back on, the relay will be restored to the state it was in when the
power supply was switched off.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
24 V
- 1 -
Advertisement
Related Manuals for F&F BIS-411M-LED 24 V
Summary of Contents for F&F BIS-411M-LED 24 V
- Page 1 F&F Filipowski L.P. Konstantynowska 79/81, 95-200 Pabianice, POLAND phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71 www.fif.com.pl; e-mail: biuro@fif.com.pl BIS-411M-LED 24 V Bistable relay with „memory” contact position Do not dispose of this device in the trash along with other waste! According to the Law on Waste, electro coming from households free of charge and can give any amount to up to that end point of collecti on, as well as to store the occasion of the purchase of new equip- ment (in accordance with the principle of old-for-new, regardless of brand).
- Page 2 The „LED” version of the relay is equipped with a contact designed to cooperate with receivers with high starting current, such as: LED fluorescent lamps, ESL fluorescent lamps, electronic transformers, discharge lamps, etc. Mounting 1. Disconnect the power supply. 2. Fix the relay on a rail in the control box. 3.
-
Page 3: Wiring Diagram
Wiring diagram relay power supply 9÷30 V AC/DC control input 11-12 NO contact (active) - 3 -... -
Page 4: Power Table
Technical data power supply 9÷30 V AC/DC contact separated 1×NO maximum load current (AC-1) 16 A (120 A/20 ms) activation delay 0.1÷0.2 s power indication green LED signalling activation red LED power consumption standby 0.15 W 0.6 W terminal 2.5 mm² screw terminals tightening torque 0.4 Nm working temperature... -
Page 5: Warranty
Warranty The F&F products are covered by a warranty of the 24 months from the date of purchase. Effective only with proof of purchase. Contact your dealer or directly with us. CE declaration F&F Filipowski L.P. declares that the device is in conformity with the essential requirements of The Low Voltage Directive (LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC) Directive 2014/30/UE.
