- Page 1 INSTRUCTIONS FOR USE Built-in Ceramic hob E6332BSCE...
- Page 2 Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and specifications are subject to change without prior notice for product improvement. Consult with your dealer or manufacturer for details. The diagram above is just for reference. Please take the appearance of the actual product as the standard.
-
Page 3: Table Of Contents
Content SAFETY INSTRUCTIONS ............... 4 SAFETY WARNINGS ..............5 2.1. Installation ................5 2.2. Operation and maintenance ............6 PRODUCT OVERVIEW ..............9 3.1. Top View................9 3.2. Control Panel ................ 9 OPERATION INSTRUCTIONS............10 4.1. Touch Controls ..............10 4.2. -
Page 4: Safety Instructions
1. SAFETY INSTRUCTIONS Intended use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation. If you find any damage, please contact the retailer or dealer. -
Page 5: Safety Warnings
2. SAFETY WARNINGS Your safety is important to us. Please read this information before using your cooktop. 2.1. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. •... -
Page 6: Operation And Maintenance
• WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock, for hob surfaces of glass-ceramic or similar material which protect live parts. • Metallic objects such as knives, forks, spoons, and lids should not be placed on the hob surface since they can get hot. - Page 7 Cut Hazard • The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted. Use with extreme care and always store safely and out of reach of children. • Failure to use caution could result in injury or cuts. Important safety instructions •...
-
Page 8: Specifications
For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. SPECIFICATIONS Cooking Hob E6332BSCE Cooking Zones 3 Zones Supply Voltage 220-240V~ 50Hz or 60Hz Installed Electric Power 5200-6200W Product Size D×W×H(mm) -
Page 9: Product Overview
3. PRODUCT OVERVIEW 3.1. Top View 1. Max. 1200 W zone 2. Max. 1800 W zone 3. Max. 1050/ 1950 / 2700 W zone 4. Glass plate 5. ON / OFF 6. Control panel 3.2. Control Panel Time regulating controls Key lock Power regulating controls Treble... -
Page 10: Working Principle
Working Principle This ceramic cooker hob directly employs resistance wire heating and adjust the output power by the power regulation with the touch controls. Before Using Your New Ceramic Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. •... -
Page 11: How To Use
4.3. How to Use Start Cooking After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceramic hob has entered the stat of standby mode. Touch the ON/OFF control. all the indicators show “-”. 2. -
Page 12: Locking The Controls
Locking the Controls • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the ON/OFF control are disabled To lock the controls The digital will show “Lo”... -
Page 13: Timer Control
Touching the treble zone control once time, the section (C) works. The cooking zone indicator show “ ” and “ ” alternately. Deactivate the Treble zone If the 3-rd cooking zone works in section(B), touching the two times, it will return to section (A) and the treble zone is deactivated. If the 3# cooking zone works in section(C), touching the one time, it will return to section (A) and the treble zone is deactivated. - Page 14 Touch the timer control, the timer indicator will flash. Set the time by touching the “ “ or “ “ control of the timer. Touching the “ ” and “ ” together, the timer is cancelled, and the “--” will show in the minute display. When the time is set, it will begin to count down immediately.
- Page 15 5. When cooking timer expires, the corresponding cooking zone will be switched off automatically; The display will show “H” which means hot. NOTE 1. The red dot next to power level indicator will illuminate indicating that zone is selected. 2. If you want to change the time after the timer is set, you must start from step 1. Setting the Timer to Turn More than One Cooking Zones Of Set more zones zone.
-
Page 16: Over Temperature Protection
Over-Temperature Protection A temperature sensor equipped can monitor the temperature inside the ceramic hob. When an excessive temperature is monitored, the ceramic hob will stop operation automatically. Residual Heat Warning When the hob has been operating for some time, there will be some residual heat. The letter “... -
Page 17: Heat Settings
For Stir-frying Choose a ceramic compatible flat-based wok or a large frying pan. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook the food in several smaller batches. Preheat the pan briefly and add two tablespoons of oil. Cook any meat first, put it aside and keep warm. -
Page 18: Product Installation
6. PRODUCT INSTALLATION Selection of Installation Equipment Cut out the work surface according to the sizes shown in the drawing. For installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impregnated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate. -
Page 19: Before Locating The Fixing Brackets
WARNING: Ensuring Adequate Ventilation Make sure the ceramic hob is well ventilated and that air inlet and outlet are not blocked. To avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 25mm from the bottom of the hob. -
Page 20: Connecting The Hob To The Mains Power Supply
Adjust the bracket position to suit for different tabletop thickness. Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop after installation (see picture). CAUTIONS 1. The ceramic cooker hob must be installed by qualified personnel or technicians. We have professionals at your service. -
Page 21: Cleaning And Maintenance
• If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. • If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts. -
Page 22: Troubleshooting
8. TROUBLESHOOTING Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below to save your time and money that may cost for calling to the service center. - Page 23 Failure code Problem Solution Wait for the temperature of ceramic plate High temperature of ceramic plate return to normal. sensor. Touch “ON/OFF” button to restart unit. Temperature sensor of the NTC failure --open circuit. Replace the display board. Temperature sensor of the NTC failure --short circuit Supply voltage is below the rated Please inspect whether power supply is...
-
Page 24: Disposal And Recycling
9. DISPOSAL AND RECYCLING Important instructions for environment Compliance with the WEEE Directive and Disposing of the Waster Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waster electrical and electronic equipment (WEEE). This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life.
