- Page 1 Instruction Manual / Installation Manual Induction hob HI6311BSCE...
- Page 2 Content 1. Foreword ....................4 1.1 Safety Warnings ................4 1.2 Installation ..................4 1.2.1 Electrical Shock Hazard ............4 1.2.2 Cut Hazard ..............4 1.2.3 Important safety instructions ..........4 1.3 Operation and maintenance ............... 6 1.3.1 Electrical Shock Hazard ............6 1.3.2 Health Hazard ..............
- Page 3 9.6 Cautions ..................22 9.7 Connecting the hob to the mains power supply ........23...
- Page 4 1. Foreword 1.1 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. 1.2 Installation 1.2.1 Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. •...
- Page 5 • Children should be supervised to ensure that they do not play with the appliance. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
- Page 6 appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents. 1.3 Operation and maintenance 1.3.1 Electrical Shock Hazard • Do not cook on a broken or cracked cooktop.
- Page 7 1.3.5 Important safety instructions • Never leave the appliance unattended when in use. Boilover causes smoking and greasy spillovers that may ignite. • Never use your appliance as a work or storage surface. • Never leave any objects or utensils on the appliance. •...
- Page 8 Congratulations on the purchase of your new Induction Hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.
- Page 9 Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your Induction hob. 2.5 Technical Specification Cooking Hob HI6311BSCE Cooking Zones 3 Zones Supply Voltage 220-240V~ 50Hz or 60Hz...
- Page 10 Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Use pans whose diameter is as large as the graphic of the zone selected. Using a pot a slightly wider energy will be used at its maximum efficiency.
- Page 11 If the display flashes alternately with the heat setting This means that: • you have not placed a pan on the correct cooking zone or, • the pan you’re using is not suitable for induction cooking or, • the pan is too small or not properly centered on the cooking zone. No heating takes place unless there is a suitable pan on the cooking zone.
- Page 12 Touching the boost control , the zone indicator show “P” and the power reach Max. Cancel the Boost function Touching the "Boost" control or the “-” button to cancel the Boost function, then the cooking zone will revert to its original setting.
- Page 13 a) Using the Timer as a Minute Minder If you are not selecting any cooking zone Make sure the cooktop is turned on. Note: you can use the minute minder at least one zone shall be active. Touch timer control. The minder indicator will start flashing and “10”...
- Page 14 Touching the “-” and “+” together, the timer is cancelled, and the “00” will show in the minute display. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds.
- Page 15 To switch to another level Short press the “Boost” key. There are 6 power levels, from “7.2” to “2.5”. The timer indicator will show one of them. “7.2” : the maximum power is 7.2 kW. “6.5” : the maximum power is 6.5 kW. “5.5”...
- Page 16 the cooking liquid. It is the key to delicious soups and tender stews because the flavours develop without overcooking the food. You should also cook egg-based and flour thickened sauces below boiling point. • Some tasks, including cooking rice by the absorption method, may require a setting higher than the lowest setting to ensure the food is cooked properly in the time recommended.
- Page 17 • bringing soup to the boil • boiling water 6. Care and Cleaning What? How? Important! Everyday soiling on 1. Switch the power to the cooktop off. • When the power to the cooktop is switched glass (fingerprints, 2. Apply a cooktop cleaner while the glass off, there will be no ‘hot surface’...
- Page 18 The touch controls are There may be a slight film of Make sure the touch control area is dry and difficult to operate. water over the controls or you use the ball of your finger when touching the may be using the tip of your controls.
- Page 19 Ceramic plate temperature sensor failure-- open circuit. Check the connection or replace the ceramic Ceramic plate temperature sensor failure- - plate temperature sensor. short circuit. Ceramic plate temperature sensor failure Wait for the temperature of ceramic plate High temperature of ceramic plate sensor. return to normal.
- Page 20 Push “ON/OFF” button to restart unit. Heating zones of the same The power board and the Check the connection. side ( Such as the first and display board connected the second zone ) would failure; display “u” . The display board of Replace the display board.
- Page 21 A(mm) B(mm) C(mm) 50 min. 20 min. Air intake Air exit 5mm WARNING: Ensuring Adequate Ventilation Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not blocked. In order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the hob.
- Page 22 in all active [phase] conductors if the local wiring rules allow for this variation of the requirements). • The isolating switch will be easily accessible to the customer with the hob installed. • You consult local building authorities and by-laws if in doubt regarding installation. •...
- Page 23 9.7 Connecting the hob to the mains power supply This hob must be connected to the mains power supply only by a suitably qualified person. Before connecting the hob to the mains power supply, check that: 1. The domestic wiring system is suitable for the power drawn by the hob. 2.
- Page 24 The symbol on the product, or in its packaging, indicates that this product may not be treated as household wasted, Instead, it should be taken to the appropriate waste collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by the inappropriate waste handling of this product.
