INSTRUCTIONS FOR USE
Induction hob
HI6352BSCE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HI6352BSCE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hisense HI6352BSCE

Summary of Contents for Hisense HI6352BSCE

  • Page 1 INSTRUCTIONS FOR USE Induction hob HI6352BSCE...
  • Page 2 Warning notices: Before using this product, please read this manual carefully and keep it for future reference. The design and specifications are subject to change without prior notice for product improvement. Consult with your dealer or manufacturer for details. The diagram above is just for reference. Please take the appearance of the actual product as the standard.

  • Page 3: Table Of Contents

    CONTENTS SAFETY INSTRUCTIONS ..............4 SAFETY WARNINGS ..............5 Installation ................... 5 2.1. Operation and Maintenance ............. 6 2.2. PRODUCT OVERVIEW ..............9 Top View ..................9 3.1. Control Panel ................9 3.2. OPERATION INSTRUCTIONS............10 Touch Controls ................10 4.1.

  • Page 4: Safety Instructions

    1. SAFETY INSTRUCTIONS Intended Use The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. Please check the packaging and appliance on arrival to make sure everything is intact to ensure safe operation.

  • Page 5: Safety Warnings

    2. SAFETY WARNINGS Your safety is important to us. Please read this information before using your cooktop. 2.1. Installation Electrical Shock Hazard • Disconnect the appliance from the mains before carrying out any work or maintenance on it. • Connection to a properly earthed mains supply is essential and mandatory. •...

  • Page 6: Operation And Maintenance

    • WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock, for hob surfaces of glass-ceramic or similar material which protect live parts • Metallic objects such as knives, forks, spoons, and lids should not be placed on the hob surface since they can get hot.
  • Page 7 Cut Hazard • The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted. Use with extreme care and always store safely and out of reach of children. • Failure to use caution could result in injury or cuts. •...
  • Page 8 For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. SPECIFICATIONS Cooking Hob HI6352BSCE Cooking Zones 3 Zones Supply Voltage 220-240V~ 50Hz or 60Hz Installed Electric Power 7400W Product Size D×W×H(mm)

  • Page 9: Product Overview

    3. PRODUCT OVERVIEW 3.1. Top View 1. Zone: 2200 / 3300 W (P) 2. Zone: 2200 / 3300 W (P) 3. Zone: 2800 / 3700 W (P) 4. Zone: 3300 / 3700 W (P) 5. Control panel 6. Glass plate 3.2.

  • Page 10: Operation Instructions

    Working Theory Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up. Iron pot magnetic circuit ceramic glass plate...

  • Page 11: Pan Dimension

    • If you do not have a magnet: Put some water in the pan you want to check. does not flash in the display and the water is heating, the pan is suitable. • Cookware made from the following materials is not suitable: pure stainless steel, aluminium or copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.

  • Page 12: How To Use

    The base diameter of induction cookware Cooking zone Minimum (mm) Maximum (mm) 1 and 2 flex induction 220 x 380 4.4. How to Use Start Cooking • Touch the ON/OFF button. After switching on, a signal tone sounds and “ - " is displayed on the control elements for selecting the heating zones , which means that the induction hob is in standby mode.
  • Page 13 Finish Cooking • Move the slider of the corresponding cooking zone all the way to the left, make sure that the display shows “0”, after 3s the hob is switched off and the display shows “-”. Power down • Turn the whole cooktop off by touching the ON/OFF control. •...
  • Page 14 NOTE • The function can work in all cooking zones. • The cooking zone returns to its original setting after 10 minutes. • The flex cooking zone returns to its original setting after 5 minutes. • If the boost function of the 1st cooking zone is activated, start the 2nd cooking zone and the 1st cooking zone vice versa.
  • Page 15 Locking the Controls • You can lock the controls to prevent unintentional use (e.g., if children accidentally switch on the cooking zones). • When the controls are locked, all controls except the ON/OFF button are deactivated. To lock the controls The digital will show “Lo”...
  • Page 16 Pause 1. When the cooking zones are in operation, touch the “ II ” button, all displays show “ ‘ ' ” and heating at level 2. At this moment, only the “ II ” and “ " controls can be operated. 2.
  • Page 17 Confirmation Disconfirmation Blinking with sound Press the flashing cooking zone boost 1. No pot is displayed after 6 seconds key to confirm the transfer 10 seconds later, turn off the blinking and prompt sound RF bunner is working at LR cooking Operate the RF slide.
  • Page 18 There are three levels of power, respectively 2-5-9, and the position of the pot is front, center and rear. The pot is on LF (left front) cooking zone - After the pot is recognized, the power level will change to 2 and display will show Move the pot in the middle of Flex zone - After the pot is recognized, the power level will change to 5 and display will...
  • Page 19 Default Working Times Auto shut down is a safety protection function for your induction hob. It shut down automatically if ever you forget to turn off your hob. The default working times for various power levels are shown in the below table: Power level pause Default working timer (hour)

  • Page 20: Quick Start Guide

    To switch to another level 1. Short press the “child lock” key . There are 6 power levels, from “7,4” to “2,5”. The LR indicator will show one of them: • “74”: the maximum power is 7,4 kW, • “60”: the maximum power is 6,0 kW, •...
  • Page 21 For Stir-frying Choose an induction compatible flat-based wok or a large frying pan. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook the food in several smaller batches. Preheat the pan briefly and add two tablespoons of oil. Cook any meat first, put it aside and keep warm.

  • Page 22: Product Installation

    6. PRODUCT INSTALLATION Selection of Installation Equipment Cut out the work surface according to the sizes shown in the drawing. For installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impregnated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate.
  • Page 23 Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not blocked. To avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 15mm from the bottom of the hob.
  • Page 24 Before Locating the Fixing Brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Adjusting the Bracket Position Fix the hob on the work surface by insert 4 brackets on the bottom of hob (see picture) before installation.
  • Page 25 Connecting the Hob to the Mains Power Supply This hob must be connected to the mains power supply only by a suitably qualified person. Before connecting the hob to the mains power supply, check that: The domestic wiring system is suitable for the power drawn by the hob. The voltage corresponds to the value given in the rating plate.
  • Page 26 Flush-mount Installation Into The Worktop Appliances without faceted edges or decorative frames, are suitable for flush mounting. Installing the appliance The appliance may only be installed into a temperature- and water-resistant countertop, such as a countertop made of (natural) stone (marble, granite), or solid wood (the edges along the cut-out have to be sealed).
  • Page 27 Stone countertop 1. Countertop 6 mm 2. Appliance 3. Slot Given the margin of error (tolerance) for the glass ceramic plate of the appliance, and the cutout in the countertop, the slot is adjustable (min.2 mm). Ceramic, wooden, or glass countertop 1.
  • Page 28 60cm WARNING! If the oven is installed under a flush-mounted cooking hob, then the worktop thickness should be at least 40 mm.

  • Page 29: Cleaning And Maintenance

    7. CLEANING AND MAINTENANCE What? How? Important! • When the power to the cooktop is switched of, there will be no ‘hot surface’ indication, but the cooking Switch the power to the cooktop of. Everyday soiling on zone may still be hot! Take extreme glass (fingerprints, Apply a cooktop cleaner while the glass care.

  • Page 30: Troubleshooting

    8. TROUBLESHOOTING Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below to save your time and money that may cost for calling to the service center. Problem Possible causes What to do...
  • Page 31 Failure Display and Inspection The induction hob is equipped with a self-diagnostic function. With this test the technician can check the function of several components without disassembling or dismounting the hob from the working surface. Troubleshooting Problem Possible causes What to do! E1、E2、E7 Temperature sensor failure.
  • Page 32 Specific Failure & Solution Failure Problem Solution A Solution B Check to see if plug is secured tightly in outlet No power supplied. and that outlet is working. The accessorial power board and the display The LED does not Check the connection. board connected come on when unit is failure.

  • Page 33: Disposal And Recycling

    9. DISPOSAL AND RECYCLING Important instructions for environment Compliance with the WEEE Directive and Disposing of the Waster Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waster electrical and electronic equipment (WEEE). This symbol indicates that this product shall not be disposed with other household wastes at the end of its service life.
