- Page 1 we keep you running UPS • AVR • Generators Inverters • EV Chargers • Racks LiON RT (1-3kVA) On-Line Lithium UPS Manual (EN)
- Page 2 PFO.9 3/1 10K~30K Online UPS...
- Page 3 PRIME PRO User Manual Uninterruptible Power Supply System 1 phase In / 1 phase Out 6-10 kVA ONLINE UPS Βόλου 7, 183 46 Μοσχάτο +30 210 9590080 www.tescom-ups.gr Volou 7, 18 346, Moschato, Greece info@tescom-ups.gr...
-
Page 4: Table Of Contents
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Table of Contents Safety Information ................1 UPS safety information ............... 1 Battery safety information ..............1 Product Overview ................. 3 Specifications ..................3 Front panel features ................ -
Page 5: Safety Information
Only use tools with insulated grips and handles Wear insulated shoes and gloves Do not put the metal tools or parts on the batteries E. Before disconnecting the terminals from the batteries, cut off all the loads to the batteries first. info@tescom-ups.gr +30 210 95 900 80... - Page 6 USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Do not dispose of the batteries with fire. The batteries may explode. Do not open or mutilate batteries. Released electrolyte inside is harmful to the skin and eyes, and maybe toxic.
-
Page 7: Product Overview
(50 / 60 ± 0.1) Hz (50 / 60 ± 0.1) Hz Total voltage harmonic Total voltage harmonic ≤ 2% (linear load); ≤ 5% (non-linear load) ≤ 2% (linear load); ≤ 5% (non-linear load) distortion distortion info@tescom-ups.gr +30 210 95 900 80... -
Page 8: Front Panel Features
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Batteries Battery type Lithium iron phosphate Battery DC voltage 25.6 V 51.2V 48 V 76.8V 48 V Inbuilt battery 3.2V / 12 Ah 3.2V / 12 Ah 3.2V / 12 Ah Quantity... -
Page 9: Rear Panel Features
3kVARTXL 3 kVA Long backup model 2.2 Front panel features 2.3 Rear panel features a. 1kVAPSRT (25.6 V) &1kVAPHRT（51.2V)）& 1kVAPHRT (48 V) rear panel b. 2kVAPSRT (51.2 V) & 3kVAPSRT (76.8 V) rear panel info@tescom-ups.gr +30 210 95 900 80... -
Page 10: Installation
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT c. 3kVAPHRT(48V) & 3kVAPHRT (51.2 V) rear panel d. 2kVAHRT (48 V) & 2kVAPHRT (51.2 V)rear panel ① AC input socket ⑥ RS232 port ②... -
Page 11: Installation Information
Wiring by a qualified electrician is required. Ensure input cables and output cables are connected correctly and firmly. info@tescom-ups.gr +30 210 95 900 80... -
Page 12: Installation And Output Connection
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT If install a leakage current protective switch, please install it on output cable. For 1-3K series long backup model units, you may need to prepare wires for terminals based on the following table. -
Page 13: Network Functions
Note: RS232 interface is set as below: Bit rate: 2400 bps Byte: 8bit Completion code: 1 bit Bit pattern: None >USB port ： ： Pins Indication date+ date- info@tescom-ups.gr +30 210 95 900 80... -
Page 14: Epo Port（Optional
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT 4.2 EPO port （ （ optional ） ） EPO is the short for Emergency Power Off. EPO port is on the rear panel of the UPS. It’s green. Users can cut off the output of UPS immediately by operating EPO port in case of emergency. -
Page 15: Operation
2 seconds, when press the key for some time again, it will turn to output status. In setting mode: Press for more than half a second (less than 2 seconds): Select the setting option. info@tescom-ups.gr +30 210 95 900 80... -
Page 16: Display Interface
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Not in setting mode: Press the key for more than 2 seconds: Function settings interface. FUNCTION SETTINGSkey In setting mode: Press the key for more than half a second (less than 2 seconds): go to the function setting options. -
Page 17: Ups On/Off Operation
ON, it means there is bypass output when power on. Press the ON key for more than half a second to start the UPS, then it will start the inverter. Once started, the UPS will perform a self-test function. When the self-test info@tescom-ups.gr +30 210 95 900 80... - Page 18 USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT finishes, it will turn to online mode. > Turn on the UPS by battery without mains power When main power is disconnected, press the ON key for more than half a second to start UPS.
-
Page 19: Ups Settings
10: Low voltage of battery is 10Vdc 10.2: Low voltage of battery is 10.2Vdc 10.5: Low voltage of battery is 10.5Vdc dEF (default): EOD voltage automatically varies with loads, including 21.5 hours discharge protection info@tescom-ups.gr +30 210 95 900 80... -
Page 20: Bypass Mode Setting
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Bypass mode setting LCD display Settings Enable or disable Bypass function. You may choose the following two options: ON: Bypass enable OFF (default): Bypass disable AUO setting LCD display Settings... - Page 21 "$# &$$# Input: Display the voltage and frequency of the input. As the following graphics show, the input voltage is 220V, input !"# frequency is 50Hz. 'E * H I %"# !"# "$# &$$# info@tescom-ups.gr +30 210 95 900 80...
-
Page 22: Operationmode
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT %"# !"# "$# &$$# Battery: Display the voltage and capacity of the battery. As !"# the following graphics shows, the battery voltage is 24V, the capacity of battery is 100% (the capacity of battery is approximately reckoned according to the battery voltage). - Page 23 Under CUCF mode, the loading capacity will drop to 70% of the original capacity. The output frequency is fixed at the set value, and it doesn’t vary with utility change. And the UPS can not be set to bypass mode in this mode. info@tescom-ups.gr +30 210 95 900 80...
-
Page 24: Fault Messages
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Faultmode When UPS has a failure, the buzzer beeps and the UPS turns to fault mode. UPS cuts off the output and LCD displays fault codes. - Page 25 Working mode displays Long Flash Flash mains power mode FAULT and the beep always always overload corresponding codes Warning for battery Working mode displays 2 beeps / overload bAT, load icon flash flashes flash / info@tescom-ups.gr +30 210 95 900 80...
- Page 26 USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT /sec Protect operation for Working mode displays Long Flash Flash battery mode FAULT and the beep always always overload corresponding codes Working mode displays Warning for bypass byPASS, load icon beep / 2...
- Page 27 The second ● ● digital tube ● ● from right to ● ● ● left ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● info@tescom-ups.gr +30 210 95 900 80...
-
Page 28: Fault Messages
USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Display EEPROM Low battery Median abnormal value abnormal abnormal ● ● ● ● ● ● ● The third ● ● digital tube ● ●... -
Page 29: Troubleshooting
Be sure there is no any fault or buzzer alarm continually, the Output short-circuit internal short circuit of the loads. fault code is 45-49 And then restart the UPS. If the problem persists, contact the supplier. info@tescom-ups.gr +30 210 95 900 80... - Page 30 USER MANUAL LiON RT (1-3kVA) • ON-LINE LITHIUM UPS • 1 PHASE IN / 1 PHASE OUT Check the load level and disconnect the non-critical equipment, recount the Fault icon display, audible total capacity of your load and reduce buzzer alarm continually, the Overload the load to the UPS.
