SIDE MOUNT TIE AND BELT RACKS
TOOLS REQUIRED:
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
WATCH TUTORIALS OF OUR
PRODUCTS BEING INSTALLED
WWW.REV-A-SHELF.COM/VIDEOS
#2
3
32
No.
A
B
M6.3 x 11 Euro Screw
C
#8 x 3/4" Pan Head Screw
STEP 1
Disengage slide assembly from
Unit (A) by fully extending the
slide. Press the release lever on
the slide and pull unit away.
BRC Series
PARTS LIST
Description
Qty.
Unit
1
2
2
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
A
BRC Series
B
C
TRC Series
TRC Series
I-TRC-BRC-1224
