HEAVY DUTY APPLIANCE LIFT
TOOLS REQUIRED:
3
mm
10
mm
#2
ESTIMATED ASSEMBLY TIME:
30–45 MIN
CARE AND MAINTENANCE:
• Clean with a damp cloth and
wipe parts dry
• Lubricate pivot points as
needed
Parts List
No.
Description
A
10 g x 16 mm Wood Screws
B
10 g x 13 mm Wood Screws
C
Side-Mounting Brackets (L & R)
D
Shelf
A.
INSTALLATION INSTRUCTIONS: HEAVY DUTY APPLIANCE LIFT
Qty
16
12
2
1
B.
WARNING
This is a spring loaded
product that can cause
severe harm if not handled
properly during installation.
C.
LEFT & RIGHT
D.
I-MLWHSHELF-0118
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rev-A-Shelf ML-450SC-WS-1
Summary of Contents for Rev-A-Shelf ML-450SC-WS-1
- Page 1 HEAVY DUTY APPLIANCE LIFT TOOLS REQUIRED: WARNING This is a spring loaded product that can cause severe harm if not handled properly during installation. ESTIMATED ASSEMBLY TIME: 30–45 MIN CARE AND MAINTENANCE: • Clean with a damp cloth and Parts List wipe parts dry •...
- Page 2 Customer Service: 800-6 appliances. SHELF MOUNTING WORKSHEET FIGURE B This worksheet is for installing Rev-A-Shelf’s maple or walnut UNDERSIDE OF shelves to their appropriate mixer MIXER LIFT SHELF lift mechanisms. MOUNTING THE APPLIANCE LIFT SHELF Note: Mixer Lift mechanism and screws packaged separately.
- Page 3 he slotted holes on the mounting plates. Insert (6) #10 x 1/2” wood 327 mm crews into the pre-drilled holes, but do not fully tighten. See Fig A). STEP 3 Adjust shelf side edges so they are FIGURE C STEP 2 over the 90-degree bend of the mounting plate and tighten screws (See Fig C).
- Page 4 ADJUSTING APPLIANCE LIFT SPRING TENSION (REFER TO FIGURES E & F) STEP 6 This appliance lift is equipped FIGURE E with (3) adjustable spring tension settings for 0-9 kg, 9- 13 kg, and 13-27 kg. The unit is shipped with the spring settings set to the middle setting.
