- Page 1 All manuals and user guides at all-guides.com A W R I T T E N G U I D E TO U P C YC L I N G A Beovox CX100...
- Page 2 All manuals and user guides at all-guides.com I N T R O D U C T I O N This is a guide on how to upcycle a Beovox CX100 loudspeaker using a BeoCreate 4-Channel amplifier and a Raspberry Pi.
-
Page 3: Yo U W I L L A L S O N E E D
All manuals and user guides at all-guides.com YO U W I L L A L S O N E E D : Recommended power supply 18-24V, about 90W (link to come) Recommended power plug mounting hole diameter: Ø8mm (link to come) Files for 3D printing You will need to two 3D printed parts ·... - Page 4 All manuals and user guides at all-guides.com TA K I N G A PA R T T H E C X 1 0 0 STEP ONE...
- Page 5 All manuals and user guides at all-guides.com From the front of the speaker, remove the From the reverse side unscrew the back fabric covers. plate.
- Page 6 All manuals and user guides at all-guides.com Remove the dampening material. Cut all of the wires connecting the drivers to the back plate.
- Page 7 All manuals and user guides at all-guides.com N O T E Evaluate the state of the speaker drivers and make sure they are in good condition. If the speaker foams are damaged a repair is needed. You can either: a) refoam yourself (refoaming kits and instructions are available here: (link to come))
- Page 8 All manuals and user guides at all-guides.com C R E AT I N G A N E W P O W E R C O N N E C T I O N STEP TWO...
- Page 9 All manuals and user guides at all-guides.com Remove the original plastic speaker Screw the power plug into the 3D printed connector with a saw. Make sure to cut puck. through the wider end, upon which you will be later placing the 3D printed puck.
- Page 10 All manuals and user guides at all-guides.com Apply glue to the 3D printed holder. Strip the insulated wires you reserved for Make sure to cover all the inner walls with a the power connector, so that approximately su cient amount of glue and attach it to 1cm of wire is exposed.
- Page 11 All manuals and user guides at all-guides.com Check the polarity of the power supply (which is +/-) and identify the corresponding pin on the power plug. Solder both wires to the power plug pins.
- Page 12 All manuals and user guides at all-guides.com A S S E M B L E T H E PA R T S STEP THREE...
- Page 13 All manuals and user guides at all-guides.com Strip the wires coming from the drivers, so Place the Raspberry Pi upon the BeoCreate that again approximately 1 cm of wire is 4-Channel Amplifier. exposed.
- Page 14 All manuals and user guides at all-guides.com Install spacers to three corners of topside of Screw the 4CA to the frame. Don’t use the Pi using the supplied nuts as seen in the screws in the holes that will be covered by pictures (there are both nuts and screws in the spacers the box).
- Page 15 All manuals and user guides at all-guides.com Install the Pi onto the 4CA. The spacers Fit in the cut wires into the Amplifier. won’t a x the Pi to the 4CA, but just pre- For details check the illustration on the vent it from flexing and touching any com- next page.
- Page 16 All manuals and user guides at all-guides.com A M P L I F I E R O U T P U T S W I R E S F R O M P O W E R C O N N E C T O R T O P B O T T O M T W E E T E R...
- Page 17 All manuals and user guides at all-guides.com C L O S I N G U P STEP FOUR...
- Page 18 All manuals and user guides at all-guides.com Connect the power supply. Plug the power supply into a wall socket.
- Page 19 All manuals and user guides at all-guides.com Make sure a red light turns on on the Unplug the power supply from the wall Raspberry Pi. socket to further proceed with the up-cycling.
- Page 20 All manuals and user guides at all-guides.com Now prepare the SD card, by downloading Insert the SD card into the Raspberry Pi. its relevant software: www.hifiberry.com/build/documentation/beocreate/ beocreate-how-to-start/...
- Page 21 All manuals and user guides at all-guides.com Reinsert the dampening material and place Screw on the back plate. the electronics on the top compartment of the speaker.
- Page 22 All manuals and user guides at all-guides.com E N J OY Your speaker is now physically upcycled. You can find the software installation here: www.bang-olufsen.com/recreate/setup/...
