Summary of Contents for Bang & Olufsen Beovox CX50
- Page 1 A W R I T T E N G U I D E TO S E T U P A , Stereo Beovox CX50...
- Page 2 PA R T S T O O L S · Upcycled Beovox CX50 · Soldering iron · A factory Beovox CX50 · Screwdrivers · 2x mini XLR 4pin plug · Electric drill · Insulated wires ·...
- Page 3 M A K I N G T H E X L R C O N N E C T I O N F O R T H E U P C YC L E D B E O V OX C X 5 0 STEP ONE...
- Page 4 Begin by unscrewing the back plate of the Remove the 4CA and disconnect the power CX50 containing the amplifier. wires to avoid any damage whilst working on the back plate.
- Page 5 Drill a 11 mm hole in the desired location of Screw on the XLR female connector. the back plate.
- Page 6 Prepare four 20cm insolated wire and strip Prepare to solder on the four wires to the both ends of each so that approximately XLR plug installed earlier. A detailed dia- 1cm of wire is exposed. gram is located on the next page.
- Page 7 X L R C O N N E C T I O N S T O T H E 4 C A W O O F E R T W E E T E R...
- Page 8 Connect the previously soldered wires and Scew on the back plate and proceed to the power wire to the amplifier. A detailed next step. diagram is located on the next page.
- Page 9 A M P L I F I E R O U T P U T S W I R E S F R O M P O W E R C O N N E C T O R R I G H T L E F T R I G H T L E F T...
- Page 10 P R E PA R E T H E X L R C O N N E C T I O N O F T H E FA C TO R Y B E O V O X C X 5 0 . STEP TWO...
- Page 11 Unscrew the back plate of the factory Cut the wires connected to the back plate. CX50.
- Page 12 Drill a 11 mm hole in the desired location of Screw on the female XLR plug. the back plate.
- Page 13 Strip the ends of the speaker wires, so that Solder on the four wires to the XLR plug approximately 1cm of wire is exposed. installed earlier. A detailed diagram is locat- ed on page 7...
- Page 14 Place the sound dampening material as Close up the back plate with the two shown above. screws.
- Page 15 Connect the two CX50’s with a male to male 4pin mini XLR cable and proceed to connect a device.
- Page 16 E N J OY Your CX50’s are now set up to play in Stereo. You can find additional guides here: https://www.hifiberry.com/beocreate...
