- Page 1 Classic VT Base Classic VT Model Height Adjustable Desk Assembly Guide And User Manual NUMBER OF PEOPLE ASSEMBLY TIME PLEASE ASSEMBLE 15 MINUTES ON THE CARPET...
- Page 2 WARNINGS This desk can only be used with the electric control system provided (This product must be powered on). All personnel responsible for the installation and maintenance of this table should read the instructions carefully. Transportation Please handle with care and avoid products falling. Assembly Check package contents for completeness or damage before assembly.
-
Page 3: Technical Specifications
TECHNICAL SPECIFICATIONS Classic VT Base Models Classic-VT-3SEG 46" - 72" Metal Desk Top Dimensions 48inc-72inc Height Range 26.4" - 45.8" 22.6inc-48.7inc Rated Load 1000N 1000N Standard Color BU / MS Black / White / Gray 1.26 in/sec 32mm/s Max.Speed 38mm/s Number of Motors 57 lbs. - Page 4 PARTS LIST - BOX 1 Classic VT Frame M6*14 Machine screw Big adjustable stiffener M6*10 Machine screw ST5*20 Wood screw Small adjustable stiffener ST5*16 Wood screw Foot PDQ cable clip Column Cable clip 4mm Allen wrench Handset Power cord Control Box Conrtol box 1.3m cable Attention: The installation method of Classic-VT-2SEG is the same as that of Classic-VT-3SEG.
-
Page 5: Assembly Guide
ASSEMBLY GUIDE M6*10 machine screw Wrench 04 / 10... - Page 6 ASSEMBLY GUIDE M6*14 screws Wrench 05 / 10...
- Page 7 ASSEMBLY GUIDE ST5*16 wood screw X 27 ST5*20 wood screw Screwdriver 06 / 10...
- Page 8 ASSEMBLY GUIDE 07 / 10...
-
Page 9: Troubleshooting
INSTRUCTIONS Make sure no obstacles are in the desk's path. Make sure the desktop is not touching any walls. Make sure all cords are appropriate length to accommodate the change in height. IMPORTANT: You must RESET the desk prior to use. RESET PROCEDURE: Press and hold the DOWN button on the Handset (part 7) until the desk reaches its lowest height. - Page 10 INSTRUCTIONS SETTING THE LED RETRACTED HEIGHT (some models) Press the DOWN button on the Handset (part 7) until the base reaches its lowest position. Measure the distance from floor to the top surface of the desktop. If the number on the LED display does NOT match your measurement, follow these steps: Press and hold the DOWN button until the LED display reads “RST".
-
Page 11: Handset Lock
INSTRUCTIONS HANDSET LOCK (some models) To lock the handset: Press and hold the "M" button (about 8 seconds) until the LED display switches to “S-” and then to "LOC”. Release the button. To unlock the handset: Press and hold the “M” button (about 8 seconds) until the LED switches from “LOC” to the height display. Release the button. CHANGING INCHES TO CENTIMETERS (some models) Press the DOWN button on the Handset (part 7) until the base reaches its lowest position.
