SoundTube Rockustics Monument Series Install Instructions

Please read the following instructions carefully before
installing your SoundTube Rockustics Monument Series
speaker. If you have any questions regarding installation
that are not answered in the following directions, please
contact your local sound contractor, or the SoundTube
technical support team.
Basic Wiring
(Diagram A) Locate speaker wire on the underside of the
rock. If necessary, strip the wire ends and trim the wire to
the appropriate length. Use the supplied silicone wire nut
to connect the positive (red) leads of the speaker and
input wires. Repeat this step with the negative (black) leads.
SoundTube recommends using 14ga or heavier Direct
Burial cable for the connection between the amplifier and
speakers.
NOTE: The provided wire nuts are meant for permanent
installation use only. If you are temporarily wiring the
speakers, do not use these wire nuts. In the event you
have used wire nuts, and need to re-wire your system, do
not attempt to unscrew the nuts. Instead, clip the wires
below the nut, and follow the steps in the
section with a new pair of waterproof wire nuts (available
at most hardware stores).
Optimizing Speaker Placement for
Best Sound
All SoundTube speakers can generate a high SPL (sound
pressure level). Be ready to rock, but be considerate of
your neighbors! Maximum acoustic performance should
be an important factor in determining speaker placement.
Here is how to achieve it:
Contact: SoundTube, 855.663.5600 / 913.663.5600 / sales@soundtube.com
Rockustics Monument Series
1) Establish where the most likely or average listening
2) The speakers should be placed at or close to the
3) The actual distance between the listening position
4) Be sure to confirm amp power matches the power
Basic Wiring
Optimizing Aesthetics with
Speaker Placement
All SoundTube products are designed with a boost in
high frequency response to accommodate for placement
near plants and other landscaping features. Feel free to
position the product within or around your landscaping.
Rockustics Monument series products are designed to
stand out from their surroundings.
Diagram A
position will be.
same distance from that point.
and the location of the speakers is not critical. How
ever, keep in mind that as the distance between
listening area and speaker is increased, there will be
a noticeable decrease in perceived volume.
rating on the speaker. Over-driving the speaker can
lead to permanent damage that is not covered under
warranty.
INSTALL INSTRUCTIONS
© 2024 SoundTube. Rev. 07.24.2024
