Quick Guide for the V-Tap VoIP 3

The V-Tap VoIP 3 is a device that can capture VoIP telephony from a network

and store this data onto an SD card and/or send this data to a server, which can

be a

Call Recorder Apresa

The V-Tap VoIP is a normal 2-port switch that can filter the network traffic and

pass the packets to the built-in microcontroller (internal mirroring).

The V-Tap VoIP 3 unit itself must hold as many channel-licenses as the number of

VoIP phones to be recorded simultaneously.

NOTE1: The SD card must be formatted with the FAT32 file system. Cards above 32 GB (up to 2 TB)

are not tested and must be formatted as FAT32 first, before inserting them into the V-Tap.

NOTE2: The port named LAN can be used to connect a Power over Ethernet (PoE) supply.

The V-Tap itself does not generate PoE.

• V-Tap VoIP 3 unit

• USB adapter

• USB cable

• LAN cable

• SD card

• 1 year Support & Update license (S&U)

• This Quick Guide

• Manual:

https://www.vidicode.com/download/v-tap-voip3-manual-en/

• V-Archive PC software:

V3.00

or the

V-Archive software

BOX CONTENT & DOWNLOADS

https://www.vidicode.com/download/v-archive/

running on a PC.

1/4

Need help?

Do you have a question about the V-Tap VoIP 3 and is the answer not in the manual?

Page 1 Quick Guide for the V-Tap VoIP 3 The V-Tap VoIP 3 is a device that can capture VoIP telephony from a network and store this data onto an SD card and/or send this data to a server, which can be a...
Page 2 Quick Guide for the V-Tap VoIP 3 HARDWARE INSTALLATION • By default, the V-Tap VoIP 3 functions as a normal 2-port switch. • Connect the local network plus VoIP traffic to the LAN port. • Connect the VoIP PBX or trunk to the PHONE1 port.
Page 3 Quick Guide for the V-Tap VoIP 3 PC REQUIREMENTS FOR THE V-ARCHIVE SOFTWARE Windows Vista/7/8/10 , Intel Pentium >2GHz , 4GByte RAM , >100 MB free disk space. V-ARCHIVE SOFTWARE INSTALLATION • In the case that no CD is supplied, you can download V-Archive from here: www.vidicode.com/download/v-archive/...
Page 4 Quick Guide for the V-Tap VoIP 3 CHECKLIST FOR TUNNEL CONNECTION A connection between V-Tap and PC software (or Apresa) is needed to get the recorded data automatically into a user accessible database. The following checklist can be used to setup this Tunnel connection: 1) Install the Hardware and be sure that the phone’s VoIP data passes the V-Tap VoIP.
