Installation instructions
8Ft Swing Frame 2 Seat OSS082
Sheet 1 of 3 Rev 00
4
12
13
6
7
Details for fixing log legs to the topbar
For ease of assembly join two
logs to the bracket to create an
A-frame and then stand in the
ground holes.
5
2
1
3
11
10
9
8
Details for Ground Shoe
Insert the logs into the ground fixings 200mm only.
The bottom of the log should line up with the top
airation holes.
Attach the ground fixings before placing logs into
ground holes.
200mm
X ON THIS END OF LOG
