Migatronic Omega Yard 300 Mounting Instructions

Monteringsvejledning, Beskyttelsesbøjle Omega Yard 300
Mounting Instructions, Protective frame Omega Yard 300
Montierungsanleitung, Schutzbügel Omega Yard 300
78861506
1 x 27150049
1
Anchor block
1 x 40310625
2
Allen screw M6x25
1 x 24612045
3
Bracket
2 x 40855016
4
PT screw 5x14
4 x 25550003
5
Insulating bush
4 x 41511507
6
Washer 1/4
4 x 40060635
7
Socket button screw
4 x 26150042
8
Brake disc
1 x 43716202
9
Cable clamp ø17
1 x 43716208
10
Cable clamp ø12
1 x 40010620
11
Set screw M6 x 20
1 x 41210605
12
Locking screw M6
1 x 40060616
13
Flange head Allen M6x16
1 x 70610607
Handle / slide
54110310
