Specifications and assembly instructions
SPECIFICATIONS
INFRARED SAUNA JI130
Model
Dimensions
Number of
persons
Wood
Glass
Hinges
Control
Operating time
Temperature
Ventilation
Connectivity
Lighting
Heaters
Connection
Weight
JI130
1300x1050x1900 mm
2
Pine, heat treated, 48 mm
Transparent, tempered, 8 mm
INOX
Control panel with buttons
Up to 90 min
Up to 65 °C
Yes
USB, Bluetooth, Radio, App
LED RGB starry sky
1750 W
Schuko socket 230 V, 50 Hz,
16 A fuse
146 kg
Advertisement
Related Manuals for JJspa JI130
Summary of Contents for JJspa JI130
- Page 1 INFRARED SAUNA JI130 Specifications and assembly instructions SPECIFICATIONS Model JI130 Dimensions 1300x1050x1900 mm Number of persons Wood Pine, heat treated, 48 mm Glass Transparent, tempered, 8 mm Hinges INOX Control Control panel with buttons Operating time Up to 90 min Temperature Up to 65 °C...
- Page 2 COMPONENTS 1 Cover plate 7 Back plate 2 Ceiling panel 8 Right side 3 Left side 9 Control panel 4 Front panel with glass 10 Bench 5 Handles 11 Bottom 6 Hinge RECOMMENDED TOOLS Screwdriver Meter Screwdriver Screws Water scale Imbus key Knife Ladder...
- Page 3 ASSEMBLY STEPS 1. Bottom 2. Back side 3. Left side 4. Bench 5. Right side 6. Ceiling panel 7. Front panel with glass 8. Cover plate 9. Handle...
- Page 4 Installing the outer buckle Connecting electrical components Connect the power cable 2. Connect the blue UTP cable 3. Connect the power cables under the bench (for saunas from the control panel to the between the control unit and with lower and floor heaters). sauna control unit.
