Specifications and assembly instructions
SPECIFICATIONS
FINNISH SAUNA JFP220
Model
Dimensions
Number of
persons
Wood
Glass
Hinges
Control
Operating time Up to 90 min
Temperature
Ventilation
Connectivity
Lighting
Oven
Connection
Weight
JFP220
2200x1800x2000 mm
6
Finnish pine, 48 mm
Transparent, tempered, 8 mm
Stainless Steel
Touch control panel
Up to 90 °C
Yes
Bluetooth, Radio, App
LED RGB starry sky
6 kW, with thermostat, timer and
volcanic stone
Three-phase 400 V, 50 Hz and 3 x
16A fuse
295 kg
Advertisement
Related Manuals for JJspa JFP220
Summary of Contents for JJspa JFP220
- Page 1 FINNISH SAUNA JFP220 Specifications and assembly instructions SPECIFICATIONS Model JFP220 Dimensions 2200x1800x2000 mm Number of persons Wood Finnish pine, 48 mm Glass Transparent, tempered, 8 mm Hinges Stainless Steel Control Touch control panel Operating time Up to 90 min Temperature Up to 90 °C...
-
Page 2: Recommended Tools
COMPONENTS 1 Cover plate 10 Right side 2 Ceiling panel 11 Control panel 3 Left side 12 Upper bench 4 Front panel with glass 13 Bench holders 5 Left upper bench 14 Front side of the upper bench 6 Bottom plate 15 Lower bench 7 Bench side 16 Front side of the lower bench... -
Page 3: Assembly Steps
ASSEMBLY STEPS 1. Back plate 2. Right side 3. Left side 4. Bottom 5. Bench holders 6. The front side of the lower bench 7. Bench 8. The front side of the upper bench 9. Upper bench... - Page 4 10. Bench side 11. Left upper bench 12. Front panel with glass *check instructions below *after installing the ceiling, connect the electrical components as described in the paragraph "Connecting the electrical components" 13. Handle 14. Ceiling plate 15. Cover plate 16 Stove frame and stove...
- Page 5 Composition of the front side with glasses 1. Carefully place the side glasses on 2. Move the glass over the edge so 3. Fasten the side parts of the the raised base and insert the lower that it looks about 1 cm out from frame with the supplied screws.
- Page 6 Installation of hinges, handle and cover Install the hinges - the soft parts 2.Install the handle 3. Install the cover plate must be next to the glass, on the inside of the hinges CONNECTING THE STOVE TO THE ELECTRICAL NETWORK...
