SPECIFICATIONS
COMBINATION SAUNA JC200
Specification and assembly instructions
Model
JC200
Dimensions
2000x1500x2005 mm
No. of persons
5
Wood
Hemlock, 50 mm
Glass
Transparent, tempered, 8 mm
Hinges
INOX
Control
Control panel with buttons
Operating time
Do 90 min
Temperature
IR up to 65 °C, finnish up to 90 °C
Ventilation
Yes
Connectivity
USB, Bluetooth, radio, app
Lighting
LED RGB starry night
Heaters
2450 W
6 kW, with thermostat, timer and
Stove
volcanic stone
Single-phase source: Schuko
socket 230 V, 50Hz, 16 A fuse
Plug in
Three-phase source: Euro socket
400 V, 50Hz, 3x 16 A fuse
Weight
305 kg
Advertisement
Related Manuals for JJspa JC200
Summary of Contents for JJspa JC200
- Page 1 COMBINATION SAUNA JC200 Specification and assembly instructions SPECIFICATIONS Model JC200 Dimensions 2000x1500x2005 mm No. of persons Wood Hemlock, 50 mm Glass Transparent, tempered, 8 mm Hinges INOX Control Control panel with buttons Operating time Do 90 min Temperature IR up to 65 °C, finnish up to 90 °C...
-
Page 2: Recommended Tools
COMPONENTS 1 Cover plate 7 Right side 2 Ceiling panel 8 Control panel 3 Left side 9 Upper bench 4 Front side 10 Lower bench 5 Handle 11 Bottom 6 Backplate 12 Stove RECOMMENDED TOOLS Screwdriver Meter Screwdriver Screws Water scale Hex key Knife Ladder... -
Page 3: Assembly Steps
ASSEMBLY STEPS 1. Back plate 2. Left side 3. Upper bench 4. Lower bench 5. Right side 6. Bottom 7. Heater 8. Front panel 9. Handle... - Page 4 10 Ceiling panel 11 Cover panel 12 Assembled sauna Installing the outer buckle Connecting electrical components Connect the power cable 3. Connect the power cables 2. Connect the blue UTP cable under the bench (for saunas between the control unit and from the control panel to the with lower and floor heaters).
- Page 5 CONNECTION TO THE ELECTRICAL NETWORK...
