Specifications and assembly instructions
SPECIFICATIONS
FINNISH SAUNA JF180
Model
Dimensions
Number of
persons
Wood
Glass
Hinges
Control
Operating time
Temperature
Ventilation
Connectivity
Lighting
Stove
Connection
Weight
JF180
1800x1400x2005 mm
5
Hemlock, 48 mm
Transparent, tempered, 8 mm
INOX
Control panel with buttons
Up to 90 min
Up to 90 °C
Yes
USB, Bluetooth, Radio, App
LED RGB starry sky
6 kW, with thermostat, timer and
volcanic stone
Three-phase: Euro socket 400 V, 50
Hz, 3 x 16 A fuses
210 kg
Advertisement
Related Manuals for JJspa JF180
Summary of Contents for JJspa JF180
- Page 1 FINNISH SAUNA JF180 Specifications and assembly instructions SPECIFICATIONS Model JF180 Dimensions 1800x1400x2005 mm Number of persons Wood Hemlock, 48 mm Glass Transparent, tempered, 8 mm Hinges INOX Control Control panel with buttons Operating time Up to 90 min Temperature Up to 90 °C...
-
Page 2: Recommended Tools
COMPONENTS 1 Cover plate 7 Right side 2 Ceiling panel 8 Control panel 3 Left side 9 upper bench 4 Front page 10 Lower bench 5 Handle 11 Bottom 6 Back plate 12 Stove RECOMMENDED TOOLS Screwdriver Meter Screwdriver Screws Water scale Knife Imbus key... -
Page 3: Assembly Steps
ASSEMBLY STEPS 1. Back plate 2. Left side 3. Right side 4. Bottom 5. upper bench 6. Lower bench 7. Heater 8. Front panel 9. Handle... - Page 4 10. Ceiling panel 11. Cover plate 12. Composite sauna Installing the outer buckle Connecting electrical components Connect the blue UTP cable 2. Connect the power from the control panel to cables between the the sauna control unit.. control unit and the stove.
- Page 5 CONNECTING THE STOVE TO THE ELECTRICAL NETWORK AC out is connected to the stove without grounding. (GRND) AC in - conductor 5 x 2.5 mm² (supplied by customer) 230 V Schuko plug AC out – cable (included with purchase), Contact cable which goes along the between control side to the furnace.
