Specifications and assembly instructions
SPECIFICATIONS
INFRARED SAUNA JIC120
Model
Dimensions
Number of persons
Wood
Glass
Hinges
Control
Operating time
Temperature
Ventilation
Connectivity
Lighting
Heaters
Connection
Weight
JIC120
1200x1050x1900 mm
2
Pine, heat treated, 48 mm
Transparent, tempered, 8 mm
INOX
Control panel with buttons
Up to 90 min
Up to 50 °C
Yes
USB, Bluetooth, Radio, App
LED reading lights
2350 W
Schuko socket 230 V, 50 Hz,
16 A fuse
155 kg
Advertisement
Related Manuals for JJspa JIC120
Summary of Contents for JJspa JIC120
- Page 1 INFRARED SAUNA JIC120 Specifications and assembly instructions SPECIFICATIONS Model JIC120 Dimensions 1200x1050x1900 mm Number of persons Wood Pine, heat treated, 48 mm Glass Transparent, tempered, 8 mm Hinges INOX Control Control panel with buttons Operating time Up to 90 min Temperature Up to 50 °C...
- Page 2 COMPONENTS 1 Cover plate 7 Back plate 2 Ceiling panel 8 Right side 3 Left side 9 Bench 4 Control panel 10 Bench front panel 5 Front panel with glass 11 Bottom 6 Handle RECOMMENDED TOOLS Screwdriver Meter Screwdriver Screws Water scale Imbus key Knife...
- Page 3 ASSEMBLY STEPS 1. Bottom 2. Back plate 3. Left side 4. Front bench panel 5. Bench 6. Right side 7. Ceiling panel 8. Left glass panel 9. Right glass panel...
- Page 4 10 Glass door 11 Handle 12 Cover plate Installing the outer buckle Connecting electrical components Connect the power cable 2. Connect the blue UTP cable 3. Connect the power cables under the bench (for saunas from the control panel to the between the control unit and with lower and floor heaters).
