Specifications and assembly instructions
SPECIFICATIONS
INFRARED SAUNA JIC90
Model
Dimensions
Number of persons
Wood
Glass
Hinges
Control
Operating time
Temperature
Ventilation
Connectivity
Lighting
Heaters
Connection
Weight
JIC90
900x900x1900 mm
1
Pine, heat treated, 48 mm
Transparent, tempered, 8 mm
INOX
Control panel with buttons
Up to 90 min
Up to 50 °C
Yes
USB, Bluetooth, Radio, App
LED reading lights
1900 W
Schuko socket 230 V, 50 Hz,
16 A fuse
121 kg
Advertisement
Related Manuals for JJspa JIC90
Summary of Contents for JJspa JIC90
- Page 1 INFRARED SAUNA JIC90 Specifications and assembly instructions SPECIFICATIONS Model JIC90 Dimensions 900x900x1900 mm Number of persons Wood Pine, heat treated, 48 mm Glass Transparent, tempered, 8 mm Hinges INOX Control Control panel with buttons Operating time Up to 90 min Temperature Up to 50 °C...
- Page 2 COMPONENTS 1 Cover plate 7 Back plate 2 Ceiling panel 8 Right side 3 Left side 9 Bench 4 Control panel 10 Bench front panel 5 Front panel with glass 11 Bottom 6 Handle RECOMMENDED TOOLS Screwdriver Meter Screwdriver Screws Water scale Imbus key Knife...
- Page 3 ASSEMBLY STEPS 1. Bottom 2. Back plate 3. Left side 4. Front bench panel 5. Bench 6. Right side . Ceiling panel 8. Cover plate 9. Glass panels...
- Page 4 10 Handle Installing the outer buckle Connecting electrical components Connect the power cable 2. Connect the blue UTP cable 3. Connect the power cables under the bench (for saunas from the control panel to the between the control unit and with lower and floor heaters).
