Specifications and assembly instructions
SPECIFICATIONS
INFRARED SAUNA JIC150
Model
Dimensions
Number of
persons
Wood
Glass
Hinges
Control
Operating time
Temperature
Ventilation
Connectivity
Lighting
Heaters
Connection
Weight
JIC150
1500x1100x1900 mm
3
Pine, heat treated, 48 mm
Transparent, tempered, 8 mm
INOX
Control panel with buttons
Up to 90 min
Up to 50 °C
Yes
USB, Bluetooth, Radio, App
LED reading lights
2600 W
Schuko socket 230 V, 50 Hz,
16 A fuse
167 kg
Advertisement
Related Manuals for JJspa JIC150
Summary of Contents for JJspa JIC150
- Page 1 INFRARED SAUNA JIC150 Specifications and assembly instructions SPECIFICATIONS Model JIC150 Dimensions 1500x1100x1900 mm Number of persons Wood Pine, heat treated, 48 mm Glass Transparent, tempered, 8 mm Hinges INOX Control Control panel with buttons Operating time Up to 90 min Temperature Up to 50 °C...
- Page 2 COMPONENTS 1 Cover plate 7 Back plate 2 Ceiling panel 8 Right side 3 Left side 9 Bench 4 Control panel 10 Bench front panel 5 Front panel with glass 11 Bottom 6 Handle RECOMMENDED TOOLS Screwdriver Meter Screwdriver Screws Water scale Imbus key Knife...
- Page 3 ASSEMBLY STEPS 1. Bottom 2. Back plate 3. Left side 4. Right side 5. Front bench panel 6. Bench 7. Ceiling panel 8. Left glass panel 9. Right glass panel...
- Page 4 10 Glass door 11 Handle 12 Cover plate Installing the outer buckle Connecting electrical components Connect the power cable 2. Connect the blue UTP cable 3. Connect the power cables under the bench (for saunas from the control panel to the between the control unit and with lower and floor heaters).
