Specifications and assembly instructions
SPECIFICATIONS
FINNISH SAUNA JF120
Model
Dimensions
Number of persons
Wood
Glass
Courses
Management
Operating time
Temperature
Ventilation
Connectivity
Lighting
Oven
Connection
Weight
JF120
1200x1050x1900 mm
2
Finnish pine, 48 mm
Transparent, hardened, 8
mm
Stainless steel
Control panel with buttons
Up to 90 min
Up to 90 °C
Yes
USB, Bluetooth, Radio, App
LED RGB starry sky
3 kW, with thermostat, timer,
and volcanic stone
Schuko socket 230 V, 50 Hz,
16 A fuse
171 kg
Advertisement
Related Manuals for JJspa JF120
Summary of Contents for JJspa JF120
- Page 1 FINNISH SAUNA JF120 Specifications and assembly instructions SPECIFICATIONS Model JF120 Dimensions 1200x1050x1900 mm Number of persons Wood Finnish pine, 48 mm Transparent, hardened, 8 Glass Courses Stainless steel Management Control panel with buttons Operating time Up to 90 min Temperature Up to 90 °C...
-
Page 2: Recommended Tools
COMPONENTS 1 Cover plate 8 Bottom 2 Ceiling panel 9 Backplate 3 Left side 10 Right side 4 Control panel 11 Bench 5 Front panel with glass 12 Front side of the bench 6 Handle 13 Heater frame 7 Platform 14 Heater RECOMMENDED TOOLS Screwdriver... -
Page 3: Assembly Steps
ASSEMBLY STEPS 1. Bottom 2. Back plate 3. Left side - fasten the buckles 4. Right side - fasten the buckles 5. Front panel of the bench - insert 6. Bench into the grooves *after installing the ceiling, connect the electrical components as described in the paragraph "Connecting the electrical components"... - Page 4 Note: Insert the side glass panels by slightly lifting the roof panel. Push the glass panels into the grooves. Finally, screw the glass door onto the hinges and attach handle. See "Hinges, Handle and Cover Installation" 11. Handle and front panel with 10.
- Page 5 Installing the outer buckle Connecting electrical components Connect the blue UTP cable 2. Connect the power cables between the control unit and from the control panel to the the stove. sauna control unit. Installation of hinges, handle and cover Install the hinges - the soft parts 2.
