Specifications and assembly instructions
SPECIFICATIONS
FINNISH SAUNA JF122
Model
Dimensions
Number of
persons
Wood
Glass
Hinges
Control
Operating time Up to 90 min
Temperature
Ventilation
Connectivity
Lighting
Oven
Connection
Weight
JF122
1200x1300x1900 mm
3
Finnish pine, 48 mm
Transparent, tempered, 8 mm
INOX
Control panel with buttons
Up to 90 °C
Yes
USB, Bluetooth, Radio, App
LED RGB starry sky
3 kW, with thermostat, timer and
volcanic stone
Schuko socket 230 V, 50 Hz, 16 A
fuse
185 kg
Advertisement
Related Manuals for JJspa JF122
Summary of Contents for JJspa JF122
- Page 1 FINNISH SAUNA JF122 Specifications and assembly instructions SPECIFICATIONS Model JF122 Dimensions 1200x1300x1900 mm Number of persons Wood Finnish pine, 48 mm Glass Transparent, tempered, 8 mm Hinges INOX Control Control panel with buttons Operating time Up to 90 min Temperature Up to 90 °C...
- Page 2 COMPONENTS 1 Ceiling and cover plate 7 Back plate 2 Left side 8 Right side 3 Front panel with glass 9 Control panel 4 Handle 10 Upper bench 5 Stove 11 Lower bench 6 Stove frame 12 Bottom RECOMMENDED TOOLS Screwdriver Meter Screwdriver...
- Page 3 ASSEMBLY STEPS 1. Back plate 2. Bottom 3. Left side 4. Right side 5. Upper bench 6. Lower bench 7. Front side with glass 8. Handle 9. Stove and stove frame...
- Page 4 Installing the outer buckle Connecting electrical components Connect the blue UTP cable 2. Connect the power from the control panel to cables between the the sauna control unit. control unit and the stove. Installation of hinges, handle and cover Install hinges 2.
