XSA1000P Series Spectrum Analyzer
XSA1015P（TG）
XSA1032P（TG）
XSA1036P（TG）
XSA1075P（TG）
For product support, visit:www.owon.com.hk/download
※:The illustrations, interface, icons and characters in the user
manual may be slightly different from the actual product.
Please refer to the actual product.
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XSA1000P Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Owon XSA1000P Series

Summary of Contents for Owon XSA1000P Series

  • Page 1 XSA1000P Series Spectrum Analyzer User Manual XSA1015P（TG） XSA1032P（TG） XSA1036P（TG） XSA1075P（TG） For product support, visit:www.owon.com.hk/download ※:The illustrations, interface, icons and characters in the user manual may be slightly different from the actual product. Please refer to the actual product.
  • Page 2 LILLIPUT Company. Fujian LILLIPUT Optoelectronics Technology Co., Ltd. No. 19, Heming Road Lantian Industrial Zone, Zhangzhou 363005 P.R. China Tel: +86-596-2130430 Fax: +86-596-2109272 Web: www.owon.com E-mail: info@owon.com.cn...

  • Page 3: General Warranty

    General Warranty We warrant that the product will be free from defects in materials and workmanship for a period of 3 years from the date of purchase of the product by the original purchaser from our company. The warranty period for accessories is 12 months.

  • Page 4: Table Of Contents

    Table of Contents 1. General Safety Requirements ........1 2. Safety Terms and Symbols ........3 3. Document Overview ........... 4 4. User Notice ..............5 4.1 General Inspection ............5 4.2 Safety Precaution before Operation ......5 4.2.1 Check Power Supply ............5 4.2.2 Allowed Variation Range of Supply Power Parameters ..6 4.2.3 Power Cord Selection ............6 4.2.4 Electro-static Discharge (ESD) Protection ......
  • Page 5 5.11 [Source] ................42 5.12 [Mode] .................44 5.13 [Peak] ..................48 5.14 [Marker] ................50 5.15 [Marker→] ................52 5.16 [Marker Fctn]Marker Function ..........53 5.17 [Meas]Measurement ............54 5.18 [Meas Setup] ..............66 5.19 [System] ................67 5.20 [File] ..................71 5.21 [Preset] ................72 5.22 [Help] ..................

  • Page 6: General Safety Requirements

    1.General Safety Requirements 1. General Safety Requirements Before use, please read the following safety precautions to avoid any possible bodily injury and to prevent this product or any other connected products from damage. To avoid any contingent danger, ensure this product is only used within the ranges specified.
  • Page 7 1.General Safety Requirements Do not operate in an explosive atmosphere. In order to  avoid damages to the device or personal injuries, it is important to operate the device away from an explosive atmosphere. Keep product surfaces clean and dry. To avoid the influence ...

  • Page 8: Safety Terms And Symbols

    2.Safety Terms and Symbols 2. Safety Terms and Symbols Safety Terms Terms in this manual (The following terms may appear in this manual): WARNING Warning indicates conditions or practices that could result in injury or loss of life. CAUTION Caution indicates the conditions or practices that could result in damage to this product or other property.

  • Page 9: Document Overview

    3.Document Overview 3. Document Overview  Quick Start This chapter states the matters need to attention before first power on, how to power on at first time, introduces spectrum analyzer’s front/rear panel and user interface, explains how to use the instrument with a measurement example demonstration.

  • Page 10: User Notice

    4.User Notice 4. User Notice This chapter states the matters need to attention before first power on, and how to power on at first time, introduces spectrum analyzer’s front/rear panel and user interface, explains how to use the instrument with a measurement example demonstration. 4.1 General Inspection When you receive your new instrument, it is recommended that you check the instrument following these steps:...

  • Page 11: Allowed Variation Range Of Supply Power Parameters

    4.User Notice cord. 4.2.2 Allowed Variation Range of Supply Power Parameters The spectrum analyzer is compatible with 100V~240V, 50Hz-60Hz AC power, Table 4- 1 lists the power requirement to run the spectrum analyzer. Working Power Variation Range Table 4- 1 Power Supply Parameter Compatible Range Voltage...

  • Page 12: Electro-Static Discharge (Esd) Protection

    4.User Notice WARNING Make sure the supply power is stable before turning on the analyzer to protect it from damage. Refer to "First Time to Power on" section 3. 4.2.4 Electro-static Discharge (ESD) Protection ESD is an issue often ignored by users. Damage from ESD on the instrument is unlikely to occur immediately but will significantly reduce the reliability of it.

  • Page 13: Front Panel

    4.User Notice WARNING Check the power source before turning on the spectrum analyzer, to protect the device from damage. 1) Press the power switch on the bottom left of the front panel. 2) Self-initialization takes about 30 seconds, after the boot screen the spectrum analyzer will default to the scanning curve.

  • Page 14: Front Panel Function Key

    4.User Notice Description Description Numeric keypad ① ⑧ Tracking generator Menu softkeys ② ⑨ output connector Tracking generator Function keys ③ ⑩ output On/Off button Knob Earphone interface ④ ⑪ Arrow keys USB Host port ⑤ ⑫ Power key RF Input connector ⑥...
  • Page 15 4.User Notice Activates the frequency sweep span function, SPAN and set Full Span\Zero Span\Last Span. Activates the reference level function, and accesses the amplitude softkeys, with which AMPTD you set functions that affect data on the vertical axis. Searches the signal automatically within the AUTO full frequency range.
  • Page 16 4.User Notice Accesses the marker control keys that select Marker the type and number of markers and turns them on and off. Accesses the marker function softkeys that Marker allow you to set other system parameters based on the current marker value. Accesses the menu of special functions, such Marker as marker noise, N dB bandwidth measure...

  • Page 17: Parameter Input

    4.User Notice 4.4.2 Parameter Input Specific parameter values are able to be entered using the numeric keypad, knob, and directional keys. Numeric Keypad Figure 4- 3 Numeric Keypad 1. Numeric button Press this button under English mode to input corresponding letters;...
  • Page 18 4.User Notice English letters; press this button under number mode to enter negative number input state, which will display the parameter symbol “-”. Press this button again to return to return positive number input state. 5. Unit buttons Unit buttons include: GHz/dBm/s, MHz/dB/ms, kHz/dBmV/μs and Hz/mV/ns.

  • Page 19: Front Panel Connector

    4.User Notice Knob Figure 4- 4 The knob The knob function: During parameter editing, turn the knob clockwise to increase, or counterclockwise to decrease the parameter values at specified steps. Direction key Figure 4- 5 Direction keys The directional keys have following functions: 1) Increase or decrease the parameter value at specific steps while editing a parameter.

  • Page 20: Rear Panel

    4.User Notice receiver through an N type male connector, users can purchase this option if required. CAUTION Input voltage at RF input port must not be higher than 50 V DC to avoid damage to the attenuator and input mixer tracking generator.

  • Page 21: User Interface

    4.User Notice HDMI HDMI output, connect an external monitor ④ interface or projector. Through this interface, the analyzer can be connected to your local network for ⑤ interface remote control. This configurable USB port permits USB Device external devices. supports ⑥...
  • Page 22 4.User Notice Table 4- 5 User interface Description Name Description Related Key Set the reference Reference FREQ → [Freq frequency as Int (internal) ① frequency Ref] or Ext (external) input AMPTD→ Turn on/off the Preamplifier ② preamplifier [Preamplifier] 【Sweep】→ Set the sweep status to [Sweep Single] Sweep status Single or Cont...
  • Page 23 4.User Notice Function of current menu Menu title belongs to， Click to call the ⑮ shortcut menu Display the frequency value (time during zero scan span) and amplitude value of current frequency Marker standard. Display the ⑯ 【Marker】 readout frequency standard function of response when the frequency standard function can be enabled...

  • Page 24: Build-In Help

    4.User Notice Center 【FREQ】→ Display center frequency ㉘ frequency [Center Freq] Start 【FREQ】→ Display start frequency ㉙ frequency [Start Freq] Resolution Display resolution 【BW】 →[RBW] ㉚ bandwidth bandwidth Display current activated ㉛ Marker 【Marker】 marker Amplitude AMPTD → Display amplitude scale ㉜...
  • Page 25 4.User Notice by different gestures. Enable/disable touch control through [System] → [Setting ] → ＞ [Touch Control On Off ]. Access mouse via USB port. If arrow appears on the screen, operate with the mouse. Instructions for touch screen and mouse control are as below. Operation can also be realized via the buttons/knobs in bracket.
  • Page 26 4.User Notice Set reference level (AMPT → [Ref Level]): Hold it in trace display area and drag it up or down to decrease or increase the reference level in order to drag the trace up and down. Set center frequency (FREQ→ [Center Freq]): Press it in the trace display area and drag it to the left or right to modify the center frequency, in order to drag the trace to the left or right.
  • Page 27 4.User Notice Trace will suspend refreshing after pressing the trace area and will continue with refreshing after releasing. Set scan span (SPAN→ [Span]): Place two fingers on the touch screen in a horizontal direction in trace display area, and make them close to or separate from each other to decrease/increase scan span, so as to enlarge/reduce trace horizontally.

  • Page 28: External Keyboard Control

    4.User Notice touch screen in a vertical direction in trace display area, and make them close to or separate from each other to increase/decrease scale/cell, so as to enlarge/reduce trace scale vertically. 4.9 External Keyboard Control Insert the keyboard into the USB port on the front panel. Control and input can be realized by keyboard.

  • Page 29: Basic Measurement

    4.User Notice 【I】 Trig 【M】 Mode 【Y】 System 【Q】 Quick Save 【P】 Peak 【K】 Marker 【X】 File 【L】 Save/Recall 【E】 Marker Fctn 【C】 Marker To 【N】 Preset 【H】 Help 【J】 Measure 【U】 Measure Set 【F1~F7】 F1~F7 【F9】 GHz/dBm 【F10】 MHz/dB 【F11】...
  • Page 30 4.User Notice minutes to ensure measurement accuracy. 1. Equipment connection: Connect the output terminal of signal generator to the RF Input 50Ω terminal of spectrum analyzer. Set the parameters as follows: Frequency 100 MHz Amplitude -20 dBm 2. Setting parameters: 1) Press 【Preset】...
  • Page 31 4.User Notice Press 【BW】, set [resolution bandwidth] to manual, and input "30" and select kHz as its unit using the numeric keypad; or press 【↓】to decrease to 30kHz. Press 【Detector】, set the detection type to positive peak. Figure 4- 9 shows the signal at a higher resolution. Please note that resolution bandwidth, video bandwidth and frequency span are self-adapted.
  • Page 32 4.User Notice reduce to 10dB reference level to increase the dynamic range. Press 【AMPTD】, the amplitude setting menu will pop up, and the [reference level] soft key will be activated. The reference level can be input at the top left of the display grid. Input "-10" using the numeric keypad and set the unit to dBm.

  • Page 33: Menu Interpretation

    5.Menu Interpretation 5. Menu Interpretation This section provides you with the information on using the front panel of the spectrum analyzer. 5.1 [FREQ]Frequency The frequency range of a channel can be expressed by either of two groups of parameters: Start Frequency and Stop Frequency; or Center Frequency and Span.
  • Page 34 5.Menu Interpretation have influence on other system parameters. For more details, please refer to "Span".  In Zero Span mode, the start frequency, stop frequency and center frequency are always equal. If one is changed the others are updated to match. ...

  • Page 35: Span]

    5.Menu Interpretation Frequency step lends itself to detect the harmonic waves and bandwidths that are beyond the current span. For example, for order of harmonic of a 300 MHz signal, you can use set both the center frequency and frequency step to 300 MHz, and press the up direction key continuously to increase the center frequency to 600MHz, that is secondary harmonic.
  • Page 36 5.Menu Interpretation Sets the frequency range of the sweep. When pressed, the frequency mode is switched to Center Freq/Span. Key points:  The start and stop frequencies are changed with the span automatically.  In non-zero span mode, the span can be set down to 100 Hz. And up to the full span described in "Specification".

  • Page 37: Amptd]Amplitude

    5.Menu Interpretation Changes the span to the previous span setting. 5.3 [AMPTD]Amplitude Sets the amplitude parameters of the analyzer. Through these parameters, signals under measurement can be displayed at an optimal view with minimum error. The pop out amplitude menu includes [Ref Level], [Attenuation Auto Manual], [Scale/Div], [Scale Type Lin Log], [Ref Offset], [Ref Unit], and [Preamplifier On Off].
  • Page 38 5.Menu Interpretation Key points:  When the preamplifier is On, the input attenuation could be set up to 40 dB. You can adjust the reference level to ensure that the specified parameters meet the requirement.  Modifying the reference level may cause an automatic change in attenuation value;...
  • Page 39 5.Menu Interpretation select. Key points:  In Log scale type: the Y-axis denotes the logarithmic coordinates, the value shown at top of the grid is the reference level and the grid size is equal to the scale value. The unit of Y-axis will be automatically switched into the default "dBm"...

  • Page 40: Auto]Auto Tune

    5.Menu Interpretation Choose decibel equals to 1μV as amplitude unit. Choose Watts as amplitude unit. Choose Voltage as amplitude unit. 5.3.7 [Preamplifier On Off] Sets the status of preamplifier located at the front of the RF signal path. Turning on the preamplifier reduces the displayed average noise level in order to distinguish small signals from the noise when working with small signals.

  • Page 41: Trace]

    5.Menu Interpretation mode. 5.5.2 [VBW Auto Man] Sets the desired video bandwidth in order to remove the band noise. Set the video resolution displays in function area, ranging from 10Hz to 1MHz by sequence step. You can modify this parameter by numeric key, step key or knob. The underline under Auto or Manual means Auto mode or Manual mode.
  • Page 42 5.Menu Interpretation Refresh the current spectrum curve by collecting real-time scanned data at each point of the trace to display the analyzer trace. 5.6.2.2 [Max Hold] Maintains the maximum for each point of the trace. It continuously receive scan data and select positive peak value detect mode. 5.6.2.3 [Min Hold] Maintains the minimum for each point of the trace.

  • Page 43: Detector]

    5.Menu Interpretation 5.6.3.3 [2 ↔ 3] Exchange the trace stock 2 data with trace stock 3 and place them in display mode. 5.6.3.4 [1→3] Exchange the trace stock 1 data with trace stock 3 and place them in display mode. 5.6.3.5 [2→3] Exchange the trace stock 2 data with trace stock 3 and place them in display mode.
  • Page 44 5.Menu Interpretation Negative peak detector is used in most cases with the self-test of the spectrum Neg Peak analyzer and is rarely used in the measurement. It is able to restore the modulation envelope of the AM signal well. Display pos peak and neg peak alternately Normal when noise is detected, or it only display pos peak.

  • Page 45: Display]

    5.Menu Interpretation alternately displayed, otherwise only positive peaks are displayed. 5.7.5 [Voltage Avg] Set the detector to the Voltage Average detector mode. This mode calculates the average voltage of all the samples in the sample bucket. 5.7.6 [More＞] Detect more menus. 5.7.6.1 [RMS Avg] Set the detector to the RMS Average detector mode.

  • Page 46: Sweep]

    5.Menu Interpretation Turn on or Off amplitude scale function. 5.8.4 [Label On Off] Defines the content displayed or hidden in the comments that appear in the display grid area. 5.8.5 [Menu Hide On Off] Display and hide the menu at the right side of the screen. When the menu hiding is enabled, the menu will be hidden if there is no any button operation within the preset menu hiding time (optional menu hiding time: 5-50 s).

  • Page 47: Trig]

    5.Menu Interpretation 5.9.2 [Sweep Single] Press [Single Sweep] to set the sweep mode to Single. Press [Single Scan] to restart the scan when the next trigger signal arrives. 5.9.3 [Sweep Cont] Press [Continuous Scan] to activate the sweep scan mode.Allows you to set continuous scan mode.

  • Page 48: Output Level

    5.Menu Interpretation Level], [Network Meas>]. The source is turned off in the power-on and reset states. 5.11.1 [Track Gen On Off] Select the tracking generator to be on or off. 5.11.2 [Output Level] Set the output power of CW or TG source. 5.11.3 [Reference] After enabling normalization, adjust the vertical position of trace on the screen by adjusting the reference level value.

  • Page 49: Mode]

    5.Menu Interpretation 5.12 [Mode] Select the operating mode of spectrum analyzer from [spectrum analysis], [audio demodulation] and [demodulation analysis] to enter demodulation setting. This spectrometer supports audio demodulation and AM/FM analog demodulation. The functions of menus and buttons differ under different modes. 5.12.1 [Spectrum] Enter the operation mode of spectrum analysis..
  • Page 50 5.Menu Interpretation Set the demodulation bandwidth of the AM modulated signal. [Setup＞] Set the time axis, depth axis and AF trigger of AM modulation. a) [Time Axis＞] Set the time axis parameters.  [Ref.Value] Set the starting reference time on the time axis. [Position] Set the reference position of the waveform on the time axis.
  • Page 51 5.Menu Interpretation Set the trigger to rising or falling edge. [Trigger Mode] Set the triggering mode to single trigger or continuously trigger. [Trigger Level] Set the trigger level as a percentage of the depth.  [Trigger Delay] Set the trigger delay time. [Return] Return to the previous menu.
  • Page 52 5.Menu Interpretation Set the starting reference time on the time axis. [Position] Set the reference position of the waveform on the time axis.  [Scale/Div Auto Man] Automatically or manually set the grid division scale.  [Return] Return to the previous menu. b)[Deviation Axis＞] Set the depth axis parameters.

  • Page 53: Peak]

    5.Menu Interpretation Set the trigger delay time. [Return] Return to the previous menu. d)[Return] Return to the previous menu. [Data Reset] Set the maximum, minimum, and average data reset under the FM modulated signal. [Return] Return to the previous menu. 5.13 [Peak] Executes peak searching immediately and opens the Peak setting menu.
  • Page 54 5.Menu Interpretation 5.13.4 [Left Peak] Searches the nearest peak located to the left side of the current peak and meets the current peak and peak thresholds condition. The peak is then identified with a marker. 5.13.5 [Right Peak] Searches the nearest peak located to the right side of the current peak and meets the current peak and peak thresholds condition.

  • Page 55: Marker]

    5.Menu Interpretation 5.14 [Marker] The marker appears as a rhombic sign (shown below) for identifying the point on the trace. We can easily readout the parameters of the marked point on the trace, such as the amplitude, frequency and sweep time. Key points: The analyzer allows for up to three groups of markers to be displayed at one time, but only one pair or one single marker is...
  • Page 56 5.Menu Interpretation 5.14.4 [Delta] One of the marker types, which is used to measure the delta values of X (Frequency or Time) and Y (Amplitude) between the Reference point and certain point on the trace. When selected, a pair of markers appears on the trace, which are the Reference Marker and the Delta Marker.

  • Page 57: Marker→]

    5.Menu Interpretation 5.14.6 [All Off] Turns off all the opened markers and the related functions. The marker won’t show again. 5.14.7 [Marker Table On Off] Turns on or off the display of all marker table. 5.15 [Marker→] A soft menu associated with the marker function is popped out for setting the other system parameters (such as Center frequency, Reference level) by current marker readings.

  • Page 58: Marker Fctn]Marker Function

    5.Menu Interpretation  The function is invalid in Zero span mode. 5.15.4 [Mkr->Stop] Sets the stop frequency of the analyzer based on the frequency of the current marker.  If Normal is selected, the stop frequency will be set to the frequency of the current marker.

  • Page 59: Meas]Measurement

    5.Menu Interpretation located on both sides of the current marker while the amplitude falls off (N<0) or rises (N>0) N dB separately, Key points: When the measurement starts, the analyzer will search the  two points which are located at both sides of the current point and are N dB amplitudes smaller or greater than the current point, and display the frequency difference between the two points.
  • Page 60 5.Menu Interpretation soft menu, turn on or off the time spectrum, adjacent channel power measurement, channel power measurement, occupied bandwidth, Pass-Fail measurement menu. 5.17.1 [Measure off] You can directly close the currently running measurement function, you can also choose to close the measurement menu. 5.17.2 [Time Spec On Off] Turn on time spectrum measure mode.
  • Page 61 5.Menu Interpretation 5.17.6 [Pass-Fail>] Enter the pass / fail measurement function soft menu. Pass / fail measurement has two modes of window measurement and area measurement. 5.17.6.1 [Window Meas>] Enter Window measurement soft menu. 1) [Window Meas On Off] Turn on or off window measurement mode. 2) [Limit Line On Off] Turns the amplitude line on or off, and the amplitude line turns on when the window measurement is on.
  • Page 62 5.Menu Interpretation 3) [Line Low On Off] When the lower limit line is turned on or off, the lower limit line is opened by default when the area measurement is on. 4) [Shift X/Y Freq Ampt] Frequency: For the actual measurement, the edited area as a whole superimposed on a frequency, so that it can implement left or right shift, easy to measure.
  • Page 63 5.Menu Interpretation Harmonic The harmonic of the fundamental frequency Frequency A multiple of the fundamental frequency The amplitude of the harmonic frequency in Amplitude Harmonic distortion value, the amplitude of the harmonic frequency relative fundamental frequency Total harmonic distortion in % or dBc The frequencies listed in the table correspond to the amplitudes, with the number 1 representing the fundamental frequency and...
  • Page 64 5.Menu Interpretation automatic mode. Key points: Reducing the value of RBW will increase the frequency resolution, but may also cause sweeps to take longer (Sweep Time is effected by a combination of RBW and VBW when it is in Auto mode).
  • Page 65 5.Menu Interpretation realizes one-key signal search and auto setting of parameters. Key points: some parameters such as reference level, scale, and input attenuation may be changed during the auto tune. 3) [Carrier Freq] Set the carrier frequency, when the phase noise measurement mode is on, set the carrier frequency to the starting frequency in the spectrum mode.
  • Page 66 5.Menu Interpretation high and low third order intermodulation frequencies exceed the scan range, they will be displayed as *." 1) [TOI On Off] Enable or disenable the TOI measurement mode. 2) [Low Monophonic Freq] Press[Low Monophonic Freq Auto Man] and hold it until underline under Auto has been highlighted.
  • Page 67 5.Menu Interpretation indicates that this offset segment failed to pass the template. Channel Calculate the power value within the test main channel. Calculate the reference value based on the Total total power within the channel, the channel Power integrated bandwidth, channel resolution bandwidth.
  • Page 68 5.Menu Interpretation [Return] Return to the previous menu. b）[Offset Setup>] Set the frequency,power and other template parameters of selected offset. [Select Offset] Select the offset index. [Offset Limit] Enable or disenable the offset limit.If the offset is off or the start frequency is equal to the stop frequency when it is on, the offset segment trace and template are not displayed.
  • Page 69 5.Menu Interpretation 5) [Stationary Mask>] User can select stationary as spectrum emission template. a）[3GPP>] Set 3GPP as spectrum emission template. [3GPP] Enable or disenable the 3GPP template. [Channel Setup>] Please refer to 5.17.7.4[SEM>],4)[Userconfig Mask>]:a)[Channel Setup>] for detail. [Offset Setup>] Please refer to 5.17.7.4[SEM>],4)[Userconfig Mask>],b)[Offset Setup>] for detail.
  • Page 70 5.Menu Interpretation b）[802.11b>] Set 802.11b as the spectrum emission template. [802.11b] Enable or disenable the 802.11b template. [Channel Setup>] Please refer to 5.17.7.4[SEM>],4)[Userconfig Mask>]:a)[Channel Setup>] for detail. [Offset Setup>] Please refer to 5.17.7.4[SEM>],4)[Userconfig Mask>],b)[Offset Setup>] for detail. [Return] Return to the previous menu. c）[802.11g>] Set 802.11g as the spectrum emission template.

  • Page 71: Meas Setup]

    5.Menu Interpretation Set 802.16 as the spectrum emission template. [802.16] Enable or disenable the 802.16 template. [Channel Setup>] Please refer to 5.17.7.4[SEM>],4)[Userconfig Mask>]:a)[Channel Setup>] for detail. [Offset Setup>] Please refer to 5.17.7.4[SEM>],4)[Userconfig Mask>],b)[Offset Setup>] for detail. [Channelization>] The channelization parameter is chosen to be 10M or 20M. [Return] Return to the previous menu.

  • Page 72: System]

    5.Menu Interpretation 5.19 [System] A soft menu for system parameter settings pops up. Including [System ],[ Setting ],[Power On / Preset ]. For first time you ＞ ＞ ＞ use the spectrum analyzer, set the date and time, the system will store the settings, restart the machine after power off won’t change the settings.
  • Page 73 5.Menu Interpretation 5.19.2 [Setting>] A soft menu for setting the interface address of the spectrum analyzer, including [Network>]. The spectrum analyzer supports VGA, LAN and USB interface communication. 5.19.2.1[LAN>] Pop out the relative menu for network configuring. [IP] Used to set the IP address of the LAN port. [Mask] Set the subnet mask parameter.
  • Page 74 5.Menu Interpretation  [Time Set]  Set the display time for spectrum analyzer. Format is HH.MM.SS. E.g. 16:55:30 should display as 16.55.30.  [Return] Return to the previous menu. 5.19.3 [PowerOn/Preset > Used to set the analyzer power on parameters or reset parameters.
  • Page 75 5.Menu Interpretation Frequency Offset 0 Hz Frequency Reference Internal Scale Type SPAN 1.5G 1.500000000GHz 3.2G 3.200000000GHz Sweep 3.6G 3.600000000GHz 7.5G 7.500000000GHz AMPTD Reference Level 0.00 dBm Attenuator Auto 10 dB Scale/div 10.00 dB Scale Type Reference Offset 0.00 dB Unit Preamp Resolution Bandwidth Auto 1 MHz...

  • Page 76: File]

    5.Menu Interpretation Spectrurm Peak Peak Search Peak Excursion 10.00dB Peak Mode Sort Amplitude Peak List Marker Fctn Marker Noise Frequency Count Marker Marker Trace Marker List Meas Time Spectrum Adjacent Power Channel Power Occupied Bandwidth pass-fail Meas Setup Channel Bandwidth 1.000000 MHz Channel Gap 2.000000 MHz...

  • Page 77: Preset]

    5.Menu Interpretation 5.20.3 [First Page] Display first page of current directory. 5.20.4 [Prev Page] Display Previous page. 5.20.5 [Next Page] Display next page. 5.20.6 [Last Page] Display last page of current directory. 5.20.7 [Operations＞] Enter file operation soft menu, including [Sort ], [Delete ＞...
  • Page 78 5.Menu Interpretation screenshots to local or flash memory, the image file format is bmp, the lower left corner of the screen status display bar will display the saved screenshots information. 5.23.1.2 [Trace Data＞] Enter the trace data save soft menu, you can choose to save the trace data to the local or flash memory, trace data file format is csv, the bottom left corner of the screen status display trace data saving information.

  • Page 79: Quick/Save]

    5.Menu Interpretation Display the previous page. [Next Page] 5.23.2.5 Display the next page. [Load＞] 5.23.2.6 Load the relevant information of the selected file. [Return] 5.23.2.7 Return to the previous menu. 5.23.3 [Quick Save Set＞] Set the file type for quick save as screenshot, trace data or user state.

  • Page 80: Emi Measurement Mode

    6.EMI Measurement mode 6. EMI Measurement mode 6.1 EMI Measurement mode interface Press [Mode] to enter mode menu and select [EMI] to enter the EMI measurement mode interface,as shown in the below figure. Figure 6-1 EMI measurement interface 6.2 Basic Control 6.2.1 [FREQ] Press [FREQ] to enter frequency menu.
  • Page 81 6.EMI Measurement mode Parameter Description Default value 165MHz Range 0 Hz ~ Full Span Unit GHz 、MHz、kHz、Hz Knob step Step=Span/200;the minimum value is 1Hz The arrow Span/10 keys step Association None 6.2.1.2[Center Freq] Set the center frequency of the current sweep. Key points：...
  • Page 82 6.EMI Measurement mode Range 0 Hz ~ (full span - 100 Hz) Unit GHz 、MHz、kHz、Hz Knob step Step=frequency step/100 The arrow Frequency step keys step Center frequency, stop frequency and related Association parameters 6.2.1.4[Stop Freq] Set the stop frequency. Parameter Description Default value 300MHz...
  • Page 83 6.EMI Measurement mode 6.2.1.6[Freq Offset] Set the frequency offset. Parameter Description Default value Range -9 GHz ~ 9 GHz Unit GHz 、MHz、kHz、Hz Knob step 1MHz The arrow 1, 2, 5 multiple steps keys step Association Span and related parameters 6.2.1.7[Freq Ref] Set the reference frequency as internal or external input, this is regarded as whole device reference.
  • Page 84 6.EMI Measurement mode number of scan points represents the size of the frequency interval of one RBW/ RBW/Step Key points: Adjusting the span will automatically modify the start and stop frequency of the spectrum analyzer. When manually setting the span, the minimum setting is 100 Hz. Setting the span to the maximum value puts the spectrum analyzer into full span mode.
  • Page 85 6.EMI Measurement mode power/level that can be displayed on the current grid. This value is also shown in the top left corner of the screen. Changing the reference level will modify the front-end parameters, and its setting must satisfy the condition: Reference level ≤...
  • Page 86 6.EMI Measurement mode attenuation can be set to a maximum of 40dB. When the set parameters do not satisfy the above formula, it is guaranteed by adjusting the reference level. Parameter Description Default value 10 dB Range 0 dB ~ 40 dB Unit Knob step 1 dB...
  • Page 87 6.EMI Measurement mode The scale value is immutable under the linear scale, and the display range is 0% to 100% of the reference level.  In Log scale type: the Y-axis denotes the logarithmic coordinates, the value shown at top of the grid is the reference level and the grid size is equal to the scale value.

  • Page 88: Scan Settings

    6.EMI Measurement mode Sets the status of preamplifier located at the front of the RF signal path. Turning on the preamplifier reduces the displayed average noise level in order to distinguish small signals from the noise when working with small signals. When the preamplifier enable, the PA appears in the left status area of the screen.
  • Page 89 6.EMI Measurement mode 6.3.2.2[State>] 1) [Clear&Write] Each point of the trace takes the data after real-time scanning. 2) [Max Hold] Each point of the trace keeps displaying the maximum value of multiple scans, and updates the data display when a new maximum value is generated.

  • Page 90: Marker Settings

    6.EMI Measurement mode Press [Sweep] to enter sweep menu. 6.3.4.1[Scan>] 1) [Scan Mode>] The default is Sweep cont, sweep continuous only after Meas Setup-> Sequence -> Scan and then start measurement,the scanning process is performed sweep continuous. Single scan, the scan will stop after the completion of the number of scans.
  • Page 91 6.EMI Measurement mode so as to view the readouts of different points on the trace. 6.4.1 [Marker] 6.4.1.1[Marker] A total of eight different cursors can be set, and each trace can have multiple cursors. 6.4.1.2[Trace] Up to three traces can be displayed, corresponding to 1, 2, and 3. Each trace is colored differently (trace 1- yellow, trace 2- purple, trace 3- light blue).
  • Page 92 6.EMI Measurement mode displayed in the upper right corner of the scanning interface. Set the marker function for the current marker. 6.4.2.2 [Mkr→List] The frequency corresponding to the current marker is added to the peak list. 6.4.2.3 [Mkr→Meter] The frequency measured by the Meter is set to the frequency corresponding to the current marker.

  • Page 93: Measurement Settings

    6.EMI Measurement mode current peak value, and find the peak value that has the closest distance to it. Mark it with a cursor. 6.4.3.6[Cont Peak] Automatic research extreme amplitude. 6.5 Measurement Settings Press [Meas Setup] to enter measurement menu. 6.5.1 [Sequence>] Setting different processes results in variations in the measured content.
  • Page 94 6.EMI Measurement mode press the [Start] button to scan([Meas Setup]->[start]),according to the CISPR Band in the scan configuration, the test is started or stopped after selecting the process. When the scan is completed, enter the Meter for measurement. 6.5.3 [Scan Config>] 6.5.3.1[CISPR Band>] Enter the list of file,import CISPR file,a CISPR profile must be loaded before EMI scan, otherwise scanning is not allowed.
  • Page 95 6.EMI Measurement mode Unit GHz 、MHz、kHz、Hz Knob step Current segment span/200 The arrow Current segment span/10 keys step Association start frequency 4）[RBW] Set the RBW under the currently selected section. Parameter Description Default value CISPR configuration file Settings Range 200Hz、9kHz、120kHz、1MHz Unit MHz、kHz、Hz Knob step...
  • Page 96 6.EMI Measurement mode Parameter Description Default value CISPR configuration file Settings Range 1ms ~ 1s Unit s、ms、μs、ns Step = one-tenth of the current unit Knob step For example:120ms step=1ms*0.1 The arrow Step in integer multiples of 1, 2, and 5 keys step Association None...

  • Page 97: Measure Mode

    6.EMI Measurement mode Unit Knob step The arrow 10dB keys step Association None [Peak Number] Specify maximum peak number of current section. Set the peak number under the currently selected section. Parameter Description Default value CISPR configuration file Settings Range 1 ~ 20 Unit None...
  • Page 98 6.EMI Measurement mode line for positive peaks, 2 serves as the limit line for quasi-peaks, and 3 serves as the limit line for average values.Different CISPR configuration have different limit lines, and the user can also edit the limit lines for different detectors separately. 2）[Pos Peak Limit>] a）[Limit Edit>] Add, insert, delete, clear the list of limit lines, and modify the...
  • Page 99 6.EMI Measurement mode Please refer to 6.5.3 [Scan Config] for detail. 6.5.4.3[Peak Offset] Please refer to 6.5.3 [Scan Config] for detail. 6.5.4.4[Peak Number] Please refer to 6.5.3 [Scan Config] for detail. 6.5.5 [Meas Config>] 6.5.5.1[Meas Signal>] 1）[Current Signal] Only the currently signal in the peak list is measured, valid if and only if the process is a measurement.
  • Page 100 6.EMI Measurement mode Association None 3）[Return] Return to the previous menu. 6.5.6 [List Control>] 6.5.6.1[Select Signal] The default current signal is 1,the index is used as the current signal.When different signals are selected, the Meter Freq will change accordingly. 6.5.6.2[Marker Signal] Mark the current signal.
  • Page 101 6.EMI Measurement mode Difference result 3:Sort the magnitude of average effective voltage difference. d）[Return] Return to the previous menu. 5）[Sequence] The list of peak signals is sorted in ascending or descending order 6）[Return] Return to the previous menu. 6.5.7 [Meter Config>] 6.5.7.1[Meter Mode>] Set the scanning mode of Meter measurement, which is divided into single and continuous sweep.
  • Page 102 6.EMI Measurement mode All the detector interfaces in the Meter measurement are closed, and the measurement results are not displayed. 6.5.7.5[Detector Config>] 1）[Meter Select] The default choice is 1 as the current measurement. Set different metering parameters. 2）[Meter Switch] Enable or disenable the current selected meter detector. 3）[Meter Detector>] The default menu button list: Meter 1 corresponds to the positive peak detector, Meter 2 corresponds to the true RMS detector, and...

  • Page 103: Specification

    7.Specification 7. Specification This chapter lists the technical specifications and general technical specifications of the spectrum analyzer. Unless otherwise stated, the technical specifications apply to the following conditions: The instrument has been preheated for 30 minutes before use.  The instrument is in the calibration cycle and has been self-calibrated.
  • Page 104 7.Specification Marker frequency span / (number of sweep points - 1) resolution ±(frequency indication × reference frequency Marker frequency accuracy + 1% × span + 10% × resolution uncertainty bandwidth + marker frequency resolution) Frequency Counter Resolution 1 Hz, 10 Hz, 100 Hz, 1 kHz ±(frequency indication ×...
  • Page 105 7.Specification Residual FM (20℃ to 30℃, RBW = VBW = 1 kHz) < 50 Hz (nominal) Residual FM Bandwidth Resolution 1 Hz to 1 MHz (1-3-5-10 steps by sequence) Bandwidth(-3dB) RBW accuracy < 5%, typical Resolution Filter Shape < 5 typical Factor (60 dB : 3 dB) Video Bandwidth ( 10 Hz to 3 MHz(1-3-5-10 steps by sequence)
  • Page 106 7.Specification Max. damage level +30 dBm（1 W） Display Average Noise Level (attenuation = 0 dB, RBW = VBW = 100 Hz, sample detector, trace average ≥ 50, 20℃ to 30℃, input impendence = 50 Ω) -95 dBm (Typical), 9 kHz to 1 MHz <-88 dBm XSA1015P -140 dBm (Typical),...
  • Page 107 7.Specification -95 dBm (Typical), 9 kHz to 1 MHz <-88 dBm -140 dBm (Typical), 1 MHz to 500 MHz <-130dBm XSA1075P -138 dBm (Typical), 500 MHz to 3.6 GHz <-128dBm （TG） -134 dBm (Typical), 3.6 GHz to 6 GHz <-124dBm -129 dBm (Typical), 6 GHz to 7.5 GHz <-119dBm...
  • Page 108 7.Specification Linear level axis 0 to reference level Number of display points Number of traces positive-peak, negative-peak, normal, sample, RMS, voltage average Trace detectors quasi-peak clear write, max hold, min hold, average, view, Trace functions blank, trace math dBm, dBμW, dB μA , dBmV, dBμV, W, V Units of level axis Frequency response (20℃...
  • Page 109 7.Specification Absolute Amplitude Uncertainty fc = 50 MHz, peak detector, preamplifier off, attenuation = 10 dB, input signal level = Uncertainty -10dBm, 20℃ to 30℃ ＜0.4 dB RBW Switching Uncertainty relative to 10 kHz RBW Uncertainty ＜0.1 dB Reference Level Range -80 dBm to +30 dBm, in 1 dB step log scale...
  • Page 110 7.Specification Level Measurement Uncertainty ( 95% confidence level, S/N > 20 dB, RBW = VBW = 1 kHz, preamplifier off, attenuation = 10 dB, -50 dBm < input level ≤ 0 dBm, fc > 10 MHz, 20℃ to 30℃ ) Level Measurement ＜0.7 dB Uncertainty...
  • Page 111 7.Specification Distortion fc ≥ 50 MHz, Preamp off, signal input -20 Second harmonic dBm, attenuation = 10 dB distortion ＞+45 dBc fc ≥ 50 MHz, two -20 dBm tones at input Third-order mixer spaced by 200 kHz, attenuation = 0 dB intermodulation ＞+14 dBm 1 dB Gain Compression...
  • Page 112 7.Specification Spurious Response connect 50 Ω load at input port, 0 dB input attenuation, 20℃ to 30℃ Residual response <-90 dBm, typical Intermediate frequency ＜ -60 dBc referenced to local oscillators, referenced to A/D conversion, referenced to subharmonic System related of first LO, referenced to harmonic of first LO sidebands ＜...
  • Page 113 7.Specification Trigger Trigger source free run, video, external External trigger level 5 V TTL level Tracking Generator (Option) Tracking Generator Output XSA1015P 100 kHz to 1.5 GHz （TG） XSA1032P 100 kHz to 3.2 GHz （TG） Frequency Range XSA1036P 100 kHz to 3.6 GHz （TG）...
  • Page 114 7.Specification Connector N Type Female Internal reference Frequency 10 MHz Output level +3 dBm to +10 dBm, +8 dBm (typical) Impedance 50 Ω, typical Connector BNC female External reference Frequency 10 MHz ± 5 ppm Output level 0 dBm to + 10 dBm Impedance 50 Ω, typical Connector...
  • Page 115 7.Specification Size 10.4 inches Color 65536 Mass Memory Flash disk (internal storage 256 MByte), USB Mass memory storage device (not supplied) Power Supply Input voltage range, AC 100 V to 240 V AC supply frequency 50 Hz to 60 Hz Power consumption 28 W (nominal) Temperature...

  • Page 116: Warranty

    8.Warranty 8. Warranty 8.1 Troubleshooting Typical issues that may occur when using your spectrum analyzer:  Power on malfunction  No signal display  Wrong measurement results or poor frequency or amplitude precision. 1. Power on malfunction Power on malfunction can include a situation where the screen is still dark (no display) after switch on.

  • Page 117: Spectrum Analyzer Repair

    8.Warranty If signal amplitude readout is not precise, perform a calibration. If amplitude readout is still not precise, then it may be a problem with internal circuit, please contact us for service. 8.2 Spectrum Analyzer Repair When it is difficult to solve your spectrum analyzer’s problem, you can contact us by phone or fax.

  • Page 118: Appendix

    9.Appendix 9. Appendix Appendix A: Enclosure (The accessories subject to final delivery.) Standard Accessories Power Cord Quick Guide USB Cable CD Rom N-BNC joint Options N-SMA SMA-SMA SMA Adaptor N-SMA N-N Cable Cable Cable Adaptor Near Field Probe includes: Four near-field probes, N-SMA adapter, SMA-SMA cable ( Frequency range: 30 MHz –...

  • Page 119: Appendix C: Usb Disk Requirements

    9.Appendix require. To clean the instrument exterior, perform the following steps: Wipe the dust from the instrument surface with a soft cloth. Take care not to scratch the transparent LCD protection screen when cleaning. WARNING Before re applying power, ensure that the instrument is completely dry, avoiding any electric shock or electrical short circuit resulting from moisture.

This manual is also suitable for:
