Summary of Contents for Owon CMS061
- Page 1 Digital Oscilloscope&Multimeter Clamp Meter User Manual CMS061 For product support, visit:www.owon.com.hk/download ※：The illustrations, interface, icons and characters in the user manual may be slightly different from the actual product. Please refer to the actual product.
- Page 2 LILLIPUT will continue to improve products and reserves the rights to change specification at any time without notice. is the registered trademark of the LILLIPUT Company. Fujian LILLIPUT Optoelectronics Technology Co., Ltd. No. 19, Heming Road Lantian Industrial Zone, Zhangzhou 363005 P.R. China Tel: +86-596-2130430 Fax: +86-596-2109272 Web: E-mail: www.owon.com info@owon.com.cn...
-
Page 3: General Warranty
General Warranty We warrant that the product will be free from defects in materials and workmanship for a period of 1 years from the date of purchase of the product by the original purchaser from our company. This warranty only applies to the original purchaser and is not transferable to a third party. -
Page 4: Table Of Contents
Table of Contents Table of Contents 1. Safety Information ............1 General Safety Requirements ....................1 Measurement Category ......................3 Safety Terms and Symbols ......................4 2. Quick Start ..............5 General Inspection ........................5 Install the Battery ........................5 Power on/off ..........................6 Selecting the Range ........................ - Page 5 Table of Contents 6． Technical Specifications ........30 Multimeter Specification ......................30 Oscilloscope Specification ....................32 7． Appendix ..............34 Appendix A: List of Accessories ....................34 Appendix B: Maintenance and Cleaning .................. 34 General maintenance ......................34 Charging and Replacement of Battery ................. 35 Replacement of Lithium Battery ...................
-
Page 6: Safety Information
Safety Information 1.Safety Information (Be sure to read the safety information before using this product.) General Safety Requirements Before any operations, please read the following safety precautions to avoid any possible bodily injury and prevent this product or any other products connected from damage. In order to avoid any contingent danger, this product is only used within the range specified. - Page 7 Safety Information Do not operate in an explosive atmosphere. Keep product surfaces clean and dry. Do not apply more than the rated voltage (as marked on the digital clamp meter) between terminals, or between terminal and earth ground. ...
-
Page 8: Measurement Category
Safety Information Measurement Category The digital clamp meter has a safety rating of 1000 V,CAT III and 600V,CAT Measurement category definition Measurement CAT I applies to measurements performed on circuits not directly connected to the AC mains. Examples are measurements on circuits not derived from the AC mains and specially protected (internal) mains- derived circuits. -
Page 9: Safety Terms And Symbols
Safety Information Safety Terms and Symbols Safety Terms Terms in this Manual. The following terms may appear in this manual: Warning: Warning indicates the conditions or practices that could result in personal injury or death. Caution: Caution indicates the conditions or practices that could result in damage to this product or other property. -
Page 10: Quick Start
Quick Start 2.Quick Start General Inspection After you get a new digital clamp meter, make a check on the instrument according to the following steps: 1. Check whether there is any damage caused by transportation. If it is found that the packaging carton or the foamed plastic protection cushion has suffered serious damage, do not throw it away first till the complete device and its accessories succeed in the electrical and mechanical property tests. -
Page 11: Power On/Off
Quick Start battery type. Use the following procedure to install the battery： (1) Power off, remove test leads and any connectors from the input terminals. (2) Loosen the screws with a suitable Phillips screwdriver and remove the battery cover. (3) Observe the battery polarity indicated inside the battery compartment, Insert the battery. -
Page 12: Instrument Panel
Instrument Panel 3.Instrument Panel Front Panel and Keys The front panel and keys of the digital clamp meter are shown in Figure 3-1: Figure 3- 1：Front panel Description: Illustration in multimeter mode Illustration in oscilloscope mode NCV measurement. - Page 13 Instrument Panel Safety level. Maximum current allowed to be measured. Operation indicator light. Reading hold button. Run/Stop button. Display area. The F1 - F4 keys are multi-function keys. In each menu mode, press the corresponding key to select the corresponding menu item. Function of direction keys Function of direction keys : used for changing range.
-
Page 14: How To Use The Multimeter
How to Use the Multimeter 4.How to Use the Multimeter About This Chapter This chapter introduces the multimeter function and provides some basic examples of basic operations and how to use the menu. Instrument Interface The digital clamp meter uses four 2 safety banana plug input ends:COM and Multimeter interface: Figure 4- 1:Multimeter interface Description:... -
Page 15: Measurement Units
How to Use the Multimeter Resistance measurement Cont On/Off measurement Diode Diode measurement Capacitance measurement Freq Frequency measurement Non-contact AC voltage sensing Range indication: Manu means manual range; Auto means automatic range. Current measurement range. Automatic shutdown sign: Display the flag when enabled. Closing will hide the identity. -
Page 16: Input Terminals
How to Use the Multimeter Ampere Current Resistance Hertz Frequency Percent Duty cycle Farad Capacitance Input terminals The terminal connections for the different measurement functions of the digital clamp meter are described in the table below. Warning: Before starting any measurement, observe the rotary switch position of the digital clamp meter, and then connect the test leads to the correct terminals. - Page 17 How to Use the Multimeter correct input terminals, function settings, and range are used for the measurement. The current measurement function must be operated between 0°C and 40°C. Avoid suddenly releasing the trigger; the Hall effect sensor is sensitive not only to magnetic fields but also to heat and mechanical stress.
-
Page 18: Measuring Ac Or Dc Voltage
How to Use the Multimeter Read the display. Press to enable and cycle through the manual ranges. If "OL" is displayed, it indicates the input exceeds. In AC current mode, press the key to switch to the second page of the menu, then press the key to enable the surge current measurement mode. - Page 19 How to Use the Multimeter into mV、V measurement function, press to up and down measurement scales. Connect the black test lead to the terminal and the red test lead to terminal. Probe the test points and read the display,this is shown in the figure below. Press to enable and cycle through the manual ranges.
-
Page 20: Measuring Resistance
How to Use the Multimeter Measuring Resistance Caution: To avoid possible damage to your digital clamp meter or to the equipment under test, disconnect the circuit power and discharge all high-voltage capacitors before measuring resistance. to enter resistance testing mode, Res will be displayed in Press the upper left corner. -
Page 21: Measuring Continuity
How to Use the Multimeter Measuring Continuity Caution: To avoid possible damage to your digital clamp meter or to the equipment under test, disconnect the circuit power and discharge all high-voltage capacitors before testing for continuity. Press to enter continuity testing mode, Cont will be displayed in the upper left corner. -
Page 22: Measuring Diodes
How to Use the Multimeter Measuring Diodes Caution: To avoid possible damage to your digital clamp meter or to the equipment under test, disconnect the circuit power and discharge all high-voltage capacitors before testing diodes. Press to enter diode testing mode, Diode will be displayed in the upper left corner. -
Page 23: Measuring Capacitance
How to Use the Multimeter Read the diode forward bias. If the test lead connection is reversed, the digital clamp meter will display "OL". Measuring Capacitance Caution: To avoid possible damage to the digital clamp meter or to the equipment under test, disconnect circuit power and discharge all high-voltage capacitors before measuring capacitance. -
Page 24: Measuring Frequency
How to Use the Multimeter Measuring Frequency to enter frequency measurement mode, Freq will be Press displayed in the upper left corner. Connect the black test lead to the terminal and the red test lead to terminal. Probe the test points to measure the frequency in the circuit, as shown in the image. -
Page 25: Measuring Ncv
How to Use the Multimeter Press to the second page menu and press to switch between the frequency and duty cycle measurements. Measuring NCV to enter capacitance testing mode, NCV will be displayed in Press the upper left corner. Bring the front end of the clamp head close to the measured conductor for AC voltage detection. -
Page 26: Multimeter Features
How to Use the Multimeter Multimeter Features Setting Scale Press to enter automatic gear mode. In the automatic gear mode, press to enter manual gear mode. Setting Range 1. Press to switch into DC current measurement and press to up and down measurement scales. 2. -
Page 27: Making Max/Min Measurements
How to Use the Multimeter function, and then press to up and down measurement scales. 3. Press to switch into DC voltage measurement, press switch into mV 、 V, and then press to up and down measurement scales. 4. Press to switch into AC voltage measurement, press switch into mV 、... -
Page 28: Value Hole Mode
How to Use the Multimeter stored reference value and the input signal. 1. Press switch into the second page menu and press enter the relative mode, △ will be shown on the display. The measurement value when pressing is stored as the reference value.In this mode,△(current reading) = input value - reference value. - Page 29 How to Use the Multimeter...
-
Page 30: How To Use The Oscilloscope
How to Use the Oscilloscope How to Use the Oscilloscope Introduction to the User Interface of the Oscilloscope Figure 5- 1：Oscilloscope Interface Description: 1. Time base display (In the horizontal direction, each grid represents a specific time interval.). 2. Scale (In the vertical direction, each grid represents a specific voltage or current value.) 3. -
Page 31: Measuring System
How to Use the Oscilloscope 5. Bluetooth sign: Displays the flag when enabled. Closing will hide the identity. 6. Battery power and external power supply indication. 7. Rms value. 8. Trigger horizontal displacement. 9. Trigger level position. 10. Measurement value. 11. -
Page 32: System Settings
How to Use the Oscilloscope Rms：The true Root Mean Square voltage over the entire waveform. Max:The most positive peak voltage measured over the entire waveform. Min:The most negative peak voltage measured over the entire waveform. Measurement： 1. Press to switch into oscilloscope mode. 2. -
Page 33: How To Use Bluetooth
How to Use the Oscilloscope When the function is turned on, it will automatically shut down after a specified period of time. However, When the function is turned off, manual shutdown is required. 3. Theme setting: Press to change the display theme. How to use Bluetooth (1) On the mobile device, scan the QR code below and follow the instructions to install the free multimeter app. - Page 34 How to Use the Oscilloscope (5) Click the "+" icon in the upper left corner to begin searching for devices and list out the multimeters found. (6) If the Bluetooth of the mobile device is not enabled, a prompt box will pop up at the bottom, indicating "Bluetooth is not turned on".
-
Page 35: 6．Technical Specifications
Technical Specifications 6．Technical Specifications Standard conditions: The environment temperature is 18℃ to 28℃,the relative humidity is less than 80%. Note: When measuring AC voltage, AC current, accuracy guarantee range is 10% to 100% of the range. When measuring DC voltage, DC current or capacitance, accuracy guarantee range is 5% to 100% of the range. - Page 36 Technical Specifications 0.0001MΩ 2.0000MΩ 0.001MΩ 20.000MΩ ±（0.5%+5dig） 100.00MΩ 0.01MΩ ±（5.0%+10dig） 2.000nF 0.001nF ±（5.0%+10dig） 20.00nF 0.01nF 200.0nF 0.1nF 2.000μF 0.001μF Capacitance 20.00μF 0.01μF ±（3.0%+10dig） 200.0μF 0.1μF 2.000mF 0.001mF 20.00mF 0.01mF 200.00Hz 0.01Hz 2.0000kHz 0.0001kHz 20.000kHz 0.001kHz (Hz) ±（0.1%+5dig） Frequency 200.00kHz 0.01kHz 2.0000MHz 0.0001MHz 20.000MHz...
-
Page 37: Oscilloscope Specification
Technical Specifications Oscilloscope Specification Characteristics Instruction Voltage: 1MHz Analog bandwidth Current: 1KHz Sample mode Real-time sample Real-time 5.0 MSa/s sampling rate Channel Input impedance ≥10 MΩ Maximum input Maximum peak voltage 1000V voltage Maximum sample Maximum peak current 600.0A current Scan speed 2.5 us/div - 10 s/div Time base... - Page 38 Technical Specifications measurement Input protection √ Digital hold √ Power Single section 18650 3.7V When the power is low, there will be a low power Low battery window, and wait for a period of time to shut down display automatically. Backlight function √...
-
Page 39: 7．Appendix
Appendix 7．Appendix Appendix A: List of Accessories 1 set of probes 1 quick guide 1 USB-TYPE C line Appendix B: Maintenance and Cleaning General maintenance Do not store or place the instrument in a place where the LCD screen will be exposed to direct sunlight for a long time. -
Page 40: Charging And Replacement Of Battery
Appendix Charging and Replacement of Battery During the long-term storage of the device, the battery may be too low due to the self-discharge of the lithium battery and the device cannot be turned on. T his is a normal phenomenon. Please use the attached adapter to pre-charge the device for 0.5 to 1 hour ( depending on the storage time) before turning it on.
