- Page 1 Three Seasons Door 3.0 OWNER'S MANUAL...
-
Page 2: Table Of Contents
Removing and Replacing Glass Panels Introduction The Three Seasons Door 3.0 is designed for use on all trailers with with ramp doors. Partly open, it provides plenty of outdoor air. An ATV, motorcycle or other small vehicle can be driven through the opening. -
Page 3: Operation
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury and/or product or property damage if not safely adhered to and within the parameters set forth in this manual. The Three Season Door 3.0 is not waterproof. Ramp door must be closed during inclement weather. Operation Moving parts can pinch, crush or cut. -
Page 4: Full Door Opening
Full Door Opening Release the door stop plunger on both doors (Fig. 2A) by pressing the release button (Fig. 2B). NOTE: To engage the door stop plunger, press the top button (Fig. 2C). Open the center door until it contacts the outer door (Fig. 3). Release plunger latches located on the top of the interior panels (Fig. -
Page 5: Removing And Replacing Glass Panels
Removing and Replacing Glass Panels Push the latch springs inward (Fig. 5 Detail), then pull outward on the glass panel (Fig. 6). Tilt the panel to one side the so the panel detaches from the door groove (Fig. 7), then lift the panel away from the door frame. - Page 6 Lippert representative has been provided. Any unauthorized use shall void any applicable warranty. The information contained in this manual is subject to change without notice and at the sole discretion of Lippert. Revised editions are available for free download from lippert.com.
