Summary of Contents for Charvet GMC 850
- Page 1 Description GMC0020 MODULE 850 GMC0079 Installer’s Instructions CHARVET F-38850 – CHARAVINES MANUAL: GMC 850 PAËLLA BURNER Tel.: +33 (0) 476 066 422 ind. A – Created on: 17.12.09 Fax: +33 (0) 476 557 875 Updated on: E-mail : info@charvet.fr E-mail :...
-
Page 2: Table Of Contents
GMC 850 PAELLA BURNER SUMMARY 1. INSTALLATION ..........................3 1.1. G ..........................3 ENERAL POINTS 1.2. H ............................3 ANDLING 1.3. I ..........................3 NSTALLATION 1.4. D ............................ 4 ATA PLATE 2. GAS CONNECTIONS ........................4 2.1. C ......................4 HECKS BEFORE CONNECTION 2.2. -
Page 3: Installation
GMC 850 PAELLA BURNER INSTALLATION General points 1.1. Installation must be undertaken in compliance with the following instructions and with local codes and bylaws. Ensure you have a suitable and sufficient risk assessment in place. This appliance is of A-type and shall not be connected to a flue gas pipe. -
Page 4: Data Plate
GMC 850 PAELLA BURNER Data plate 1.4. Each appliance has is own data plate. Transfer all the information written on the data plate to the part of the user’s manual reserved for it. This will ease the communication between you and your client for better service. -
Page 5: Connecting The Appliance To The Gas Mains
Adjusting nuts Remove the control knobs, ((1) screwed). Unscrew the 2 screws (2) located under the Charvet’s logo. Unscrew (3) and pull the bottom of the panel up and out. Connect to connection 20/27. Note: the technical space is behind the control panel. -
Page 6: Conversion To Other Types Of Gas
GMC 850 PAELLA BURNER CONVERSION TO OTHER TYPES OF GAS Change of gas upon installation: After having replaced the injectors, ensure of the watertightness of the connection between the injector and its support. Changing the injectors and adjusting the air 3.1. -
Page 7: Gas Adjustment Charts
GMC 850 PAELLA BURNER Gas adjustment charts 3.3. Paella burner Gas type Mark Nominal & operating engraved adjustment calorific pressure d (mm)*2 output the injector (kW)*1 G20: Pn = 20 mbar G 25: Pn = 20 mbar G 25: Pn = 25 mbar 10.5... -
Page 8: Power Connection
GMC 850 PAELLA BURNER POWER CONNECTION Warning The appliance must be earth wired. It is dangerous to connect the appliance unless it is earthed. We cannot be held responsible for accidents due to non existent or incorrect earth link connection. -
Page 9: Adapting The Appliance To The Various Electrical Supply Voltages
3~230V + E 3~400V + E Voltage of appliance Wiring diagrams # S = standard coupling Hot cupboard TR0038 Electric ignition TR0087 Electric oven TR0101 A → Coupling possible B→ Please consult Charvet C → Coupling impossible D → No voltage available... -
Page 10: Wiring Diagrams
GMC 850 PAELLA BURNER WIRING DIAGRAMS Hot cupboard 2/1 Hot cupboard1/1 1~230V + E = TR0038 NOMENCLATURE: Hot cupboard – single phase 230 V Mark Code Description Quantity ELE0304 Regulation thermostat ELE0434 230V heating indicator ELE0231 Heating element 230V 600W... - Page 11 GMC 850 PAELLA BURNER TR0101 Wiring diagram valid for switches having a rod with meplat up (set at 0). For switches having a rod with meplat down below (set at 0), reverse: - 107 and 108 - 109 and 110...
- Page 12 GMC 850 PAELLA BURNER The unused ignition points must be earth wired. (or connected to a second spark plug) NOMENCLATURE: Electric ignition of the burners TR0087 Mark Code Description Quantity ELE0018 Electric ignition push button GAZ0002 2-point or 4-point ignitor...
-
Page 13: Basic Spare Parts List
GMC 850 PAELLA BURNER BASIC SPARE PARTS LIST Description / Code Description / Code Photograph Photograph Gas tap Gas tap 08094A 08369A Gas injector for cast iron solid top G20/G25 Ø 2.40 Natural Burner kit Gaz0232 00208A Ø 1.35 Propane... -
Page 14: Maintenance
GMC 850 PAELLA BURNER MAINTENANCE Electric oven: changing the heating element 8.1. Fixing screw Removing the heating element: Open the oven door. Remove the enameled vaults from the oven (A), the oven shelves (B) and the mild steel bases (C). - Page 15 EXTEND CONCEPT Description GMC0020 MODULE 850 GMC0079 User’s Instructions CHARVET F-38850 – CHARAVINES MANUAL: GMC 850 PAELLA BURNER Tel.: +33 (0) 476 066 422 ind. A – Created on: 17.12.09 Fax: +33 (0) 476 557 875 Updated on: E-mail: info@charvet.fr E-mail:...
- Page 16 GMC 850 PAELLA BURNER SUMMARY 1. INTRODUCTION..........................3 2. PRIOR TO STARTING UP ........................ 3 3. STARTING UP ..........................3 3.1. P ..........................3 AELLA BURNER 3.2. E ..........................4 LECTRIC OVEN 3.3. E ........................ 4 LECTRIC HOT CUPBOARD 4. SWITCHING OFF..........................5 5.
-
Page 17: Introduction
GMC 850 PAELLA BURNER INTRODUCTION Our equipment is for professional use only and must be used by qualified staff. The equipment must be installed in compliance with local codes and bylaws. It must be installed in a kitchen equipped with an adequately sized mechanical extraction system. -
Page 18: Electric Oven
GMC 850 PAELLA BURNER Electric oven 3.2. • Turn control knob to the desired position (vault/vault-mild steel base/mild steel base); the heating indicator is alight. • Turn thermostat to the desired temperature; the heating indicator is illuminated. • When the desired temperature is reached, the regulation indicator is darkened. The regulation thermostat will constantly adjust the temperature of the oven. -
Page 19: Switching Off
GMC 850 PAELLA BURNER SWITCHING OFF At the end of the day, cut off gas supply or/and switch off electricity at the mains. MAINTENANCE Before doing anything on the appliance, wait until cooking areas has cooled down. Cleaning the stainless steel surfaces 5.1. -
Page 20: Electric Hot Cupboard
GMC 850 PAELLA BURNER Electric hot cupboard 5.4. • Open the door and remove the removable shelves (A). • Push them up before pulling them to the middle (B), • Clean the parts in hot soapy water. For best results, have your equipment serviced and cleaned on a regular basis by a qualified installer. - Page 21 GMC 850 PAELLA BURNER This will help you with maintenance problems and spare parts.
