- Page 1 Model: AV-2025 20X HDMI & USB PTZ Camera User Manual V1.0 Please read this user manual thoroughly before using. www.avipas.com...
- Page 2 Preface Thank you for selecting AViPAS AV-2025 HDMI & USB PTZ Camera. This manual provides comprehensive information on the camera’s features, installation procedures, and operational guidelines. Please ensure you read this manual thoroughly before proceeding with the installation and use of the camera.
-
Page 3: Table Of Contents
Table of Contents Safety Guides ................................1 Camera Overview ................................ 2 Product Highlights ............................... 2 Specifications ............................... 3 Camera Interface ................................5 Camera Installation ..............................6 Camera Dimension (mm) ............................ 6 Mounting Brackets............................... 7 IR Remote Guide ................................. 9 Camera OSD (On-Screen Display) Menu ......................... 10 System Setting .............................. -
Page 4: Safety Guides
Safety Guides • Electric Safety: Installation and operation must accord with electric safety standards. • Use caution to transport: Avoid stress, vibration or soakage in transport, storage, and installation. • Polarity of power supply: The power supply of this product is +12V, the max electrical current is 2A. The polarity of the power supply plug is shown in the drawing below. -
Page 5: Package Included
Package Included When unpacked, check if all supplied accessories are included: Camera ------------------------------------------------------------------------------- 1pc Power Adapter (US standard) ------------------------------------------------------1pc Power Cord (US standard) ----------------------------------------------------------1pc RS232 Cable (9-Pin DB-9 Female to 8-Pin Mini-Din Male) ------------------1pc USB 2.0 Cable (Type-A to Type-C) -----------------------------------------------1pc IR Remote Control-------------------------------------------------------------------1pc User Manual ------------------------------------------------------------------------- 1pc Camera Overview... -
Page 6: Specifications
Specifications Camera AV-2025B(Black) / AV-2025W(White) Sensor 1/2.8-inch Sony CMOS sensor, 2.4MP Zoom 20x Optical Zoom, 2x Digital Zoom Lens f4.9~98mm, F1.5~3.0 Minimum Illumination 0.1 Lux ( F1.5) Horizontal Viewing Angle View angle: 60°(Far)~3.23°(Near) HDMI： 1920*1080P60/59.94/50/30/29.97/25/24/23.98 ; 1920*1080I60/59.94/50 ; 1280*720P60/59.94/50/30/29.97/25 IP Streaming: Main Stream: 1920*1080@3~60;... - Page 7 1x RS485 (shared with RS232-in port) 1x USB-C Control Protocol ONVIF / VISCA / Pelco-D / Pelco-P/ UVC1.1/ VISCA-Over-IP Audio Input Interface 3.5mm TRS Line-in input, embedded audio out via IP streaming DC Input DC12V RS232 Daisy Chain Supported up to 7 cameras under VISCA protocol IP Networking Specification Video Encoding Standard H.264 / H.265...
-
Page 8: Camera Interface
14. 3.5mm TRS Audio Input (Line-in) * 4. Normal working Mode: Solid Blue color light ** 5. Dial Switch Indication Note: Cameras are set to working mode by default. Please do not adjust the switch unless instructed by AViPAS. Mode SW-1... -
Page 9: Camera Installation
Camera Installation Camera Dimension (mm) Figure 1.2 Dimension Diagram Note: mm to inch unit conversion for figure 1.2 143.5mm=5.60 inch 177.4mm=6.98 inch 162.4mm=6.39 inch 137.4mm=5.41 inch 167.5mm=5.60 inch 168.0mm=6.60 inch 84.00mm=3.31 inch 80mm=3.15 inch... -
Page 10: Mounting Brackets
1) Wall Mount Installation ( Wall Mount Sold Separately) Note: Customers may select any wall mount bracket that is compatible with the installation requirements. Or choose from AViPAS wall mount brackets: AV-W22G (Black) or AV-W22W (White). Figure 1.3 Wall Mount Image Instructions: 1. -
Page 11: Ceiling Mount Installation
2) Ceiling Mount Installation ( Ceiling Mount Sold Separately) Note: Customers may select any wall mount bracket that is compatible with the installation requirements. Or choose from AViPAS wall mount brackets: AV-C20G (Black) or AV-C20W (White). Figure 1.4 Ceiling Mount Image Instructions: 1. -
Page 12: Ir Remote Guide
IR Remote Guide POWER Button Under working status, press the POWER button to enter standby mode. Press it again to switch to working mode. FREEZE （NOT supported through USB output） Press FREEZE to freeze/ unfreeze the view of image on display. IRT (IR Transfer/IR Pass) Open / close the IR pass function. -
Page 13: Camera Osd (On-Screen Display) Menu
AF: Auto focus MF: Manual focus RESET: Long press to reset back to factory default settings MENU: to open/ close the OSD menu; to enter/ exit the OSD menu, or to return to the previous submenu F1: Reserved F2: Reserved F3: Reserved F4: Reserved BLC OFF: Not available... -
Page 14: System Setting
System Setting MAIN MENU SUB MENU DESCRIPTIONS /VALUE DEFAULT LAUGUAGE English English PROTOCOL Optional: VISCA/ PELCO-P/ PELCO-D VISCA ADDRESS VISCA: 1~7, PELCO-P/D: 0~255 SYSTEM BAUDRATE 2400/ 4800/ 9600/ 115200 9600 PTZ SPEED Pan Tilt speed: 5~24 RETURN Return to previous menu Focus Setting MAIN MENU SUB MENU... -
Page 15: Quality Setting
Quality Setting MAIN MENU SUB MENU DESCRIPTION/VALUE DEFAULT 2D NR ON/OFF OFF/AUTO/1~4, Higher value: Reduces motion noise in the image, slightly lower resolution; Lower 3D NR AUTO value: Preserves higher resolution, more motion noise in the image. SHARPNESS 0~15 QUALITY CONTRAST 0~15 SATURATION... -
Page 16: Video Format
Network Setting MAIN MENU SUB MENU DESCRIPTION NOTE DHCP ON/OFF (default: OFF) Use the up, down, left, and right ADDRESS 192.168.001.188 navigation keys to select an item. Enter parameters using the numeric NETWORK NETMASK 255.255.255.000 keys. GATEWAY 192.168.001.001 RETURN Return to previous menu When DHCP is “OFF,”... -
Page 17: Camera Web Ui
Camera Web UI Access Camera via IP (computer) Prerequired: The camera and PC must be in the same Local Area Network (LAN). It required the first three segments of their IP addresses to be identical, while the fourth segment is unique. •... -
Page 18: Web Ui Login
Note: For more detailed tech support, please refer to: avipas.com-> SUPPORT -> “HOW TO” MATERIALS -> “Access camera via IP.” Web UI Login Open a web browser, input Camera IP address. In this case, take AV-2025 as an example, the default AV-2025 IP address is 192.168.1.188. -
Page 19: Preview
Preview Top-right corner: Navigation bar for "Preview," "Settings," and "Logout”. Right-side panel: PTZ (Pan-Tilt-Zoom) control panel with options for pan, tilt, zoom movements, focus mode selection, preset controls, and speed adjustments for PTZ and focus functions. Bottom-right corner of the preview area: Users can switch between Main-Stream and Sub-Stream video previews. Settings Click “Settings”... -
Page 20: Rtmp/Srt/Rtp Streaming Settings
Note: stream name is: 554/stream/main For example: The default IP address of the camera is 192.168.1.188. To obtain video via RTSP stream, please use the URL below: Main stream: rtsp://192.168.1.188:554/stream/main Sub stream: rtsp://192.168.1.188:554/stream/sub 2). Video Transmission Settings (RTMP/SRT/RTP multicast streaming) Set RTMP/SRT/RTP Multicast streaming parameters. -
Page 21: Audio Settings
For more information regarding streaming settings, please refer to: www.avipas.com-> SUPPORT -> “HOW TO” MATERIALS -> How to live stream via RTMP(S), SRT, RTSP. Or contact us at service@avipas.com 3). Audio Settings Audio State: To enable/disable embedded audio. Audio encoding mode can be selected (AAC or LPCM). -
Page 22: Image Settings
4). Image Settings Image Adjust: set focus, exposure, white balance, image, image quality, noise-reduction, as the following picture: Focus: focus mode options, focus sensitivity & digital zoom. Exposure includes exposure mode, shutter speed, gain, iris, brightness & anti-flicker options. White Balance: white balance mode, red gain, blue gain, color temperature. Image: settings for image flip (mirror and vertical flip), backlight compensation, image freeze, Gamma, WDR (wide dynamic range). -
Page 23: Network Configuration
Image Quality: adjustment for brightness, sharpness, contrast, saturation. Noise reduction: 2D/3D reduction. There is on/off option for 2D, and off/auto/1~4 selections. Network Configuration: For setting up DHCP mode, change IP address, subnet mask, default gateway, http port, web port, main stream port and sub stream port. -
Page 24: System Configuration
Default IP settings are as follows: DHCP: OFF Gateway: 192.168.1.1 RTSP Port: 554 IP Address: 192.168.1.188 DNS: 192.168.1.1 RTSP Encrypt: OFF Netmask: 255.255.255.0 HTTP Port: 80 VISCA OVER IP Port: 52381 ONVIF Port: 8000 Username/PSW: admin/admin System Configuration 1). Firmware Upgrade... - Page 25 2). System Control Reset Options: To reset the camera to default settings. • Reset: reset camera image settings to default values. • Reset/Reboot: reset all camera settings back to factory default settings (including IP configurations, image settings, tracking settings and protocol), and reboot camera. Device Control: •...
-
Page 26: Uvc Control
0Z 0Z 0Z 0Z F CT_PANTILT_RELATIVE_CONTROL 8x 01 06 01 pp qq rr ss FF CT_ZOOM_RELATIVE_CONTROL 8x 01 04 07 pp FF Serial Control AV-2025 could be controlled through RS232 and RS485 interface. Serial parameters are as below: Parameter Value Parameter Value Baud rate... - Page 27 2). Camera Mini-Din 8-pin RS-232 Port Definition Port Definition Data Terminal Ready Data Set Ready Transmit Data Signal Ground Receive Data Signal Ground IR OUT IR Commander Signal No Connection 3). Connection illustration: Camera RS232 with DB-9 Connection Camera Daisy Chain Control Camera RS232 IN Windows DB-9 Camera RS232 IN...
-
Page 28: Protocol Commands
Protocol Commands VISCA Protocol Commands Part1 Camera Return Commands Ack/Completion Message Command Packet Note z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. z = camera adderss+8 Error Messages Command Note Packet... - Page 29 Command type function command Near (Standard) 8x 01 04 08 03 FF Far (Variable) 81 01 04 08 2p FF p=0 (Low) to 7 (High) Near (Variable) 81 01 04 08 3p FF p=0 (Low) to 7 (High) Direct 8x 01 04 48 0p 0q 0r 0s FF pqrs: focus position Auto Focus 81 01 04 38 02 FF...
- Page 30 Command type function command Down 8x 01 04 0D 03 FF Direct 8x 01 04 4D 00 00 0p 0q FF pq: Bright l Positon (0~0x1B) CAM_OverallBr pq: Bright l Positon (0~0x0F) Direct 8x 01 04 A4 00 00 0p 0q FF ight different with AE BRIGHT 8x 01 04 3D 02 FF...
- Page 31 Command type function command 1080P60 0x2E 1080P50 0x2F 1080I60 0x01 1080I50 0x04 1080P30 0x06 1080P25 0x08 720P60 0x09 720P50 0x0C 720P30 0x0E 720P25 0x11 CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF pqrs: Camera ID (=0000 to FFFF) 8x 01 04 AB 0p 0q 0r 0s 0m 0n Set ip to: pq.rs.mn.xy IP set...
- Page 32 CAM_DZoomPosiInq 8x 09 04 46 FF y0 50 0p 0q 0r 0s FF pqrs: Zoom Position CAM_SpeedByZoomInq 8x 09 06 A0 FF y0 50 0p FF p 2: ON 3: OFF CAM_PTSpeedInq(IR) 8x 09 04 C1 FF y0 50 pp FF pp: 0x05~0x18 CAM_ZoomSpeedInq(IR) 8x 09 04 D1 FF...
-
Page 33: Visca Protocol Commands
y0 50 02 FF IR_Transfer 8x 09 06 1A FF y0 50 03 FF y0 50 02 FF IR_Receive 8x 09 06 08 FF y0 50 03 FF y0 07 7D 01 04 00 Power ON/OFF y0 07 7D 01 04 07 Zoom tele/wide y0 07 7D 01 04 38 AF On/Off... -
Page 34: Pelco-D Protocol Command List
Pelco-D Protocol Command List Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 0xFF Address 0x00 0x08 Pan Speed Tilt Speed Down 0xFF Address 0x00 0x10 Pan Speed Tilt Speed Left 0xFF Address 0x00 0x04 Pan Speed Tilt Speed Right 0xFF Address 0x00 0x02... -
Page 35: Pelco-P Protocol Command List
Pelco-P Protocol Command List Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 0Xa0 Address 0x00 0x08 Pan Speed Tilt Speed 0Xaf Down 0Xa0 Address 0x00 0x10 Pan Speed Tilt Speed 0Xaf Left 0Xa0 Address 0x00 0x04 Pan Speed Tilt Speed 0Xaf Right 0Xa0... -
Page 36: Maintenance And Troubleshooting
Check if the computer is set to the same local network segment that consistent with the IP address of the camera. For details, please refer to: avipas.com-> SUPPORT -> HOW TO MATERIALS -> “Access camera via IP.” Or see page 14 & 15 for the instructions on how to login camera. -
Page 37: Warranty And Support
This Limited Warranty does not cover problems including but not limited to improper handling, malfunction or damage not resulting from defects in material. To receive warranty service, please contact AVIPAS Inc. first. We will decide whether a repair or replacement is needed and will advise you of the cost of such repair or replacement. -
Page 38: Company Contact Info
VER: 2025-05-06 (EN) Contact Details: AViPAS Inc. Address: 1700 Wyatt Drive, Suite #3, Santa Clara, CA 95054 USA Phone: 1-844-228-4727 Fax: (408) 228-8438 Email: info@avipas.com Website: http://www.avipas.com...
